JMB-25H Electric Rebar Bender
Product Information
The JMB-25H Electric Rebar Bender is a table-style bending
machine designed for bending rebar. It comes with a heavy-duty
stand, bending rollers, steel carrying case, tool kit, standard
foot pedal control switch, and a one-year limited manufacturer
warranty. The machine is manufactured by BN Products-USATM.
The product parts guide provides a list of all the components
included with the JMB-25H Electric Rebar Bender. It includes
various bearings, oil seals, carbon brushes, gears, switches,
connectors, and other necessary parts for the machine’s
operation.
Product Usage Instructions
- Place the JMB-25H Electric Rebar Bender on a sturdy surface or
use the included heavy-duty stand for stability. - Ensure that all necessary parts are properly installed and in
working condition. - Connect the machine to a power source using a suitable power
cord. - Turn on the machine using the on/off switch located on the
control box panel. - To bend rebar, follow these steps:
- Position the rebar in the machine’s bending rollers, ensuring
it is aligned correctly. - Use the foot pedal control switch to activate the bending
process. Press and hold the pedal to bend the rebar to the desired
angle. - Release the foot pedal to stop the bending process.
- Position the rebar in the machine’s bending rollers, ensuring
- After use, turn off the machine using the on/off switch.
- Clean and maintain the machine regularly according to the
instructions provided in the user manual.
Note: For more detailed instructions on specific parts or
troubleshooting, refer to the user manual provided with the JMB-25H
Electric Rebar Bender.
JMB-25H Electric Rebar Bender
BN Customer Service (800) 992-3833
115V / 15A | Bend up to #8 (1″ – 25.4 mm) Grade 60 Rebar | 0-180° Angle Bends | Angle Preset Control
Rebar Bender with Stand & Control Pedals
JMB-25H
The JMB-25H is a table-style electric rebar bending machine. The unit ships with a heavy-duty stand for the machine, bending rollers, steel carrying case, tool kit, standard foot pedal control switch, and includes a one-year limited manufacturer warranty.
BN Products-USATM
3450 N Sabin Brown Road | Wickenburg, AZ 85390 (800) 992-3833 | www.BNProducts.com
PRODUCT PARTS GUIDE
Page | 1
Exploded View Drawing
JMB-25H Electric Rebar Bender
BN Customer Service (800) 992-3833
JMB-25H Roller Selection Table
BN Products-USATM
Page | 2
No. Part No. 1 JMBP-00001 2 JMBP-00002 3 JMBP-00003 4 JMBP-00004 5 JMBP-00005 6 JMBP-00006 7 JMBP-00007 8 JMBP-00008 9 JMBP-00009 10 JMBP-00010 11 JMBP-00011 12 JMBP-00012 13 JMBP-00013 14 JMBP-00014 15 JMPB-00015 16 JMBP-00016 17 JMBP-00017 18 JMBP-00018 19 JMBP-00019 20 JMBP-00020 21 JMBP-00021 22 JMBP-00022 23 JMBP-00023 24 JMBP-00024 25 JMBP-00025 26 JMBP-00026 27 JMBP-00027 28 JMBP-00028 29 JMBP-00029 30 JMBP-00030 31 JMBP-00031 32 JMBP-00032 33 JMBP-00033 34 JMBP-00034 35 JMBP-00035
JMB-25H Electric Rebar Bender
BN Customer Service (800) 992-3833
Qty Description
No.
1 Oil Seal Jmb-25h
36
1 6002ZZ Bearing
37
2 6003ZZ Bearing
38
3 6005ZZ Bearing
39
1 6008ZZ Bearing
40
1 6011DD Bearing
41
2 6014ZZ Bearing
42
1 6005ZZ Bearing
43
2 6204ZZ Bearing
44
1 6305ZZ Bearing
45
2 6804ZZ Bearing
46
1 6912ZZ Bearing
47
1 Amature JMB-25H
48
1 AN11 Lock Nut
49
1 AW11 Washer
50
2 Carbon Cap
51
2 Carbon Holder
52
2 Carbon Brush
53
1 Center Shaft Assy JMB-25H 54
1 Chain
55
1 Clutch Assy. Jmb-25h
56
1 On/Off Switch
57
1 Emergency Switch
58
1 Foot S/W Connector
59
1 Fuse
60
1 Start Button
61
1 Control Box Panel
62
1 Frame JMB-25H
63
1 Adjustable Nut
64
1 Modulator Handle
65
1 Bar Stopper
66
1 Gear Box Bottom Housing 67
1 7th Gear (Clutch Gear)
68
1 6th Gear (Clutch Shaft Gear) 69
1 9th Gear (69phi Gear)
70
Part No. JMBP-00036 JMBP-00037 JMBP-00038 JMBP-00039 JMBP-00040 JMBP-00041 JMBP-00042 JMBP-00043 JMBP-00044 JMBP-00045 JMBP-00046 JMBP-00047 JMBP-00048 JMBP-00049 JMBP-00063 JMBP-00050 JMBP-00051 JMBP-00052 JMBP-00053 JMBP-00054 JMBP-00055 JMBP-00056 JMBP-00057 JMBP-00058 JMBP-00059 JMBP-00060 JMBP-00061 JMBP-00062 JMBP-00064
*See Roller Part Numbers (p.4)
JMBP-00072 JMBP-00073 JMBP-00074 JMBP-00075
Qty Description
1 8th Gear (28phi Gear)
1 5th Gear (98phi Gear)
1 4th Gear (34phi Gear)
1 3rd Gear (123 Phi Gear)
1 6003ZZ Bearing
1 Gear Box Top Housing
1 Spring Bracket
1 Spring Holder
3 Shaft For Chain Gear
3 Chain Sprocket
1 Handle
1 Front Pannel
1 Large Gear (1st Gear)
1 Top Plate
1 Urethane Bumper
1 Moving Roller Shaft
1 Top Dust Cover
1 Top Center Plate
2 Side Cover
1 Roller Stoper
1 Sensor Detector
1 Dust Cover For Gear Box
1 Rear Cover
1 2nd Gear (Center Shaft Gear)
1 Key 6*15*2r
1 Key 8*15*2r
1 Limit Switch
1 Motor Housing
1 Angle Sensor
1 Moving Roller
1 Center Roller
3 Snap ring
3
Tension spring
1
Stator
1 Flange unit UCFL205
Page | 3
No. Part No. 71 JMBP-00076 72 JMBP-00077 73 JMBP-00078 74 JMBP-00086 75 JMBP-00087 76 JMBP-00088 77 JMBP-00131 78 JMBP-00132 79 JMBP-00133 80 JMBP-00134 81 JMBP-00135 82 JMBP-00136 83 JMBP-00137 84 JMBP-00138 85 JMBP-00139 86 JMBP-00140 87 JMBP-00141 88 JMBP-00142 89 JMBP-00143 90 JMBP-00144 91 JMBP-00145 92 JMBP-00146 93 JMBP-00147
JMB-25H Electric Rebar Bender
BN Customer Service (800) 992-3833
Qty Description 1 Urethane Bumper 1 AN04 Lock nut 1 AW04 Lock washer 1 Center Shaft holder 1 Control Panel guard 1 Foot switch 4 M12 spring washer 2 M14 spring washer 8 Countersunk bolt M10 X 25 3 Countersunk bolt M10 X 35 8 Countersunk bolt M10 X 30 2 Socket bolt M10 X 40 2 Socket bolt M10 X 65 3 Countersunk bolt M8 X 35 9 M10 Nut 4 Socket bolt M12 X 20 1 Socket bolt M12 X 30 2 Socket bolt M12 X 25 2 Hex bolt M14 X 1.5 1 Socket bolt M6 X 15 4 Truss bolt M5 X 10 4 Truss bolt M4 X 10 28 Flange bolt M5 X 10
No. Part No. 94 JMBP-00148 95 JMBP-00149 96 JMBP-00150 97 JMBP-00151 98 JMBP-00152 99 JMBP-00153 100 JMBP-00154 101 JMBP-00155 102 JMBP-00156 103 JMBP-00157 104 JMBP-00158 105 JMBP-00159 106 JMBP-00160 107 JMBP-00161 108 JMBP-00162 109 JMBP-00163
Qty Description 1 Countersunk bolt M5 X 10 9 Socket bolt M6 X 8 4 Socket bolt M6 X 15 8 Socket bolt M8 X 20 3 Socket bolt M10 X 55 4 Socket bolt M10 X 30 4 Socket bolt M8 X 25 2 Socket bolt M8 X 20 2 Roller washer 3 M12 Plate washer 2 M14 Plate washer 2 M5 Spring washer 4 M8 Plate washer 4 M8 Spring washer 2 Spring pin 6X15 2 Round bolt M5 X 80
Ordering Information BN Products-USATM Customer Service
Telephone: Email: Company Information:
(800) 992-3833 [email protected]
www.BNProducts.com
JMB-25H Roller Part Numbers
BN Products-USATM
Page | 4
