JMB-22 Electric Rebar Bender
JMB-22 Electric Rebar Bender
BN Customer Service (800) 992-3833
Rebar Bender with Stand & Control Pedals
The JMB-22 is a table-style electric rebar bending machine. The
unit ships with a heavy-duty stand for the machine, bending
rollers, steel carrying case, tool kit, standard foot pedal control
switch, and a one-year limited manufacturer warranty.
BN Products-USATM
3450 N Sabin Brown Road | Wickenburg, AZ 85390 (800) 992-3833 |
www.BNProducts.com
PRODUCT PARTS GUIDE
Page 1
JMB-22 Parts View
Page 2
| No. | Part No. | Qty | Description |
|---|---|---|---|
| 1 | JMBP-00089 | 1 | Adjustable Nut |
| 35 | JMBP-00110 | 1 | Right Cover (JMB-22) |
Page 3
| No. | Part No. | Qty | Description |
|---|---|---|---|
| 71 | JMBP-00124 | 1 | Stator |
| 85 | JMBP-00139 | 1 | Bumper-Urethane Absorber |
Roller Selection Table
| Roller Number | Part Number |
|---|---|
| 1 | JMBP-00081 |
| 5 | JMBP-00085 |
* Roller Sizes / Part Numbers:
1 – 55mm (JMBP-00081)
2 – 79mm (JMBP-00082)
3 – 96mm (JMBP-00083)
4 – 120mm (JMBP-00084)
5 – 150mm (JMBP-00085)
Product Usage Instructions
- Ensure that the JMB-22 Electric Rebar Bender is placed on the
heavy-duty stand for stability. - Connect the bending rollers to the machine according to the
roller sizes needed for the specific rebar bending task:
- For 55mm roller, use part number JMBP-00081.
- For 79mm roller, use part number JMBP-00082.
- For 96mm roller, use part number JMBP-00083.
- For 120mm roller, use part number JMBP-00084.
- For 150mm roller, use part number JMBP-00085.
additional parts required for the specific rebar bending task.
needed.
and carefully store the machine, bending rollers, and all
components in the steel carrying case provided.
Service contact details provided in the manual for assistance.
JMB-22 Electric Rebar Bender
BN Customer Service (800) 992-3833
115V / 15A | Bend up to #7 (7/8″ – 22mm) Grade 60 Rebar | 0-180° Angle Bends | Two Angle Presets
Rebar Bender with Stand & Control Pedals
The JMB-22 is a table-style electric rebar bending machine. The unit ships with heavy-duty stand for the machine, bending rollers, steel carrying case, tool kit, standard foot pedal control switch,
and a one-year limited manufacturer warranty.
BN Products-USATM
3450 N Sabin Brown Road | Wickenburg, AZ 85390 (800) 992-3833 | www.BNProducts.com
PRODUCT PARTS GUIDE
Page | 1
JMB-22 Parts View
JMB-22 Electric Rebar Bender
BN Customer Service (800) 992-3833
BN Products-USATM
Page | 2
No. Part No. 1 JMBP-00089 2 JMBP-00090 3 JMBP-00002 4 JMBP-00003 5 JMBP-00004 6 JMBP-00005 7 JMBP-00091 8 JMBP-00009 9 JMBP-00092 10 JMBP-00093 11 JMBP-00010 12 JMBP-00011 13 JMBP-00012 14 JMBP-00094 15 JMBP-00095 16 JMBP-00096 17 JMBP-00097 18 JMBP-00098 19 JMBP-00099 20 JMBP-00100 21 JMBP-00101 22 JMBP-00102 23 JMBP-00026 24 JMBP-00022 25 JMBP-00024 26 JMBP-00103 27 JMBP-00025 28 JMBP-00104 29 JMBP-00023 30 JMBP-00105 31 JMBP-00106 32 JMBP-00107 33 JMBP-00108 34 JMBP-00109 35 JMBP-00110
Qty Description 1 Oil Seal (JMB-22) 1 Moving Roller Shaft 1 6002ZZ Bearing 2 6003ZZ Bearing 3 6005ZZ Bearing 2 6008ZZ Bearing 1 6200DD Bearing 3 6204ZZ Bearing 1 6211DD Bearing 1 6211ZZ Bearing 1 6305ZZ Bearing 4 6804ZZ Bearing 1 6912ZZ Bearing 1 Armature (JMB-22) (120V) 1 AN08 Lock Nut 1 Frame Body (JMB-22) 1 AN08 Washer 2 Carbon Cap (JMB-22) 2 Carbon Holder (JMB-22) 2 Carbon Brush (JMB-22) 1 Chain (JMB-22) 1 Clutch Assy. (JMB-22) 2 Start Button 1 On/Off Switch 2 Foot S/W Connector 2 Led Light 1 Fuse 2 Degree Knob 1 Emergency Switch 2 Handle (Jmb-22) 2 Degree Indicator 4 Degree Indicator Washer 2 Degree Indicator Washer 2 Degree Indicator Bracket 1 Top Plate (JMB-22)
JMB-22 Electric Rebar Bender
BN Customer Service (800) 992-3833
No. Part No. 36 JMBP-00111 37 JMBP-00112 38 JMBP-00031 39 JMBP-00113 40 JMBP-00114 41 JMBP-00115 42 JMBP-00033 43 JMBP-00034 44 JMBP-00035 45 JMBP-00036 46 JMBP-00037 47 JMBP-00038 48 JMBP-00039 49 JMBP-00041 50 JMBP-00043 51 JMBP-00044 52 JMBP-00045 53 JMBP-00116 54 JMBP-00117 55 JMBP-00054 56 JMBP-00118 57 JMBP-00119 58 JMBP-00120 59 JMBP-00055 60 JMBP-00048 61 JMBP-00058 62 JMBP-00059 63 JMBP-00060 64 JMBP-00061 65 JMBP-00121 66 JMBP-00064 67 JMBP-00122 68 Moving Roller 69 Center Roller 70 JMBP-00123
Qty Description
1 Adjustable Nut
1 Modulator Handle
1 Bar Stopper
1 Bearing Housing
1 Center Shaft (JMB-22)
1 Gear Box Bottom Housing
1 7th Gear (Clutch Gear)
1 6th Gear (Clutch Shaft Gear)
1 9th Gear (69phi Gear)
1 8th Gear (28phi Gear)
1 5th Gear (98phi Gear)
1 4th Gear (34phi Gear)
1 3rd Gear (123 Phi Gear)
1 Gear Box Top Housing
1 Spring Holder
1 Shaft For Chain Gear
1 Chain Sprocket
1 Front Pannel
1 Control Box Assembly
1 Roller Stoper
1 Bearing Housing
1 Top Dust Cover
1 Top Dust Cover
1 Sensor Detector
1 Large Gear (1st Gear)
1 2nd Gear (Center Shaft Gear)
1 Key 6*15*2r
1 Key 8*15*2r
1 Limit Switch
1 Motor Housing (JMB-22)
2 Angle Sensor
1 Rear Cover
1
* Roller Sizes / Part Numbers:
1
See Roller Selection Table
1 Left Cover (JMB-22)
Page | 3
No. Part No. 71 JMBP-00124 72 JMBP-00125 73 JMBP-00126 74 JMBP-00127 75 JMBP-00075 76 JMBP-00088 77 JMBP-00159 78 JMBP-00161 79 JMBP-00131 80 JMBP-00133 81 JMBP-00135 82 JMBP-00153 83 JMBP-00136 84 JMBP-00164 85 JMBP-00139
JMB-22 Electric Rebar Bender
BN Customer Service (800) 992-3833
Qty Description
No. Part No.
1 Right Cover (JMB-22)
86 JMBP-00142
4 Snap Ring
87 JMBP-00141
3 Tension Spring (JMB-22)
88 JMBP-00146
1 Stator
89 JMBP-00145
1 Bumper-Urethane Absorber 90 JMBP-00147
2 Foot Pedal Assembly
91 JMBP-00148
2 M5 SPRING WASHER
92 JMBP-00163
4 M8 SPRING WASHER
93 JMBP-00149
1 M12 SPRING WASHER
94 JMBP-00150
6 CS BOLT M10X25
95 JMBP-00165
9 CS BOLT M10X30
96 JMBP-00154
4 SOCKET BOLT M10X30
97 JMBP-00156
2 SOCKET BOLT M10X40
98 JMBP-00160
5 SOCKET BOLT M10X50
99 JMBP-00162
6 M10 Nut
Qty Description 2 SOCKET BOLT M12X25 1 SOCKET BOLT M12X30 4 TRUSS BOLT M4X10 1 TRUSS BOLT M5X10 28 FLANGE BOLT M5X10 4 CS BOLT M5X10 2 ROUND BOLT M5X80 9 SOCKET BOLT M6X8 11 SOCKET BOLT M6X15 8 SOCKET BOLT M8X15 4 SOCKET BOLT M8X25 2 ROLLER WASHER 4 M8 PLATE WASHER 2 SPRING PIN 6X15
Roller Selection Table
Roller Part Numbers
Roller Number 1 – 55mm 2 – 79mm 3 – 96mm 4 – 120mm 5 – 150mm
Part Number JMBP-00081 JMBP-00082 JMBP-00083 JMBP-00084 JMBP-00085
BN Products-USATM
Page | 4
BN Products-USA, LLC - Professional Contractor Tools
