VEN200.V3 Portable Ventilator
Product Information:
Product Name: Portable Ventilators with Ducting
Model Number: VEN200.V3
Manufacturer: Sealey
This product is designed and manufactured to a high standard,
ensuring reliable and trouble-free performance when used correctly
and maintained properly.
Please read the following instructions carefully, noting the
safe operational requirements, warnings, and cautions. It is
essential to use the product correctly and with care for its
intended purpose to prevent damage, personal injury, and to
maintain the warranty. Keep these instructions safe for future
reference.
Product Usage Instructions:
1. Safety
1.1 Electrical Safety
It is the user’s responsibility to ensure electrical safety by
following these guidelines:
- Inspect all electrical equipment and appliances for safety
before use. - Check power supply leads, plugs, and connections for wear or
damage. - Sealey recommends using a Residual Current Device (RCD) with
all electrical products. - If using the product for business purposes, maintain it in a
safe condition and routinely perform Portable Appliance Testing
(PAT). - Before connecting the appliance to the power supply, ensure the
insulation on all cables and the appliance is safe. - Regularly inspect power supply cables, plugs, and connections
for wear or damage. - Ensure the voltage rating on the appliance matches the power
supply and the plug has the correct fuse rating. - Avoid pulling or carrying the appliance by its power
cable. - Avoid pulling the plug from the socket by the cable.
- Do not use worn or damaged cables, plugs, or connectors. Repair
or replace any faulty items immediately with the help of a
qualified electrician. - This product is fitted with a BS1363 3 pin plug.
- If the cable or plug is damaged during use, switch off the
electricity supply and discontinue use. Seek repairs from a
qualified electrician. - Replace a damaged plug with a BS1363 3 pin plug. If unsure,
consult a qualified electrician. - When connecting the appliance, follow these guidelines:
- Connect the GREEN/YELLOW earth wire to the earth terminal
`E’. - Connect the BROWN live wire to the live terminal `L’.
- Connect the BLUE neutral wire to the neutral terminal `N’.
- Ensure the cable’s outer sheath extends inside the cable
restraint and is tight. Sealey recommends repairs by a qualified
electrician.
- Connect the GREEN/YELLOW earth wire to the earth terminal
- Replacement fuse rating: 3A
1.2 General Safety
Follow these general safety instructions when using the
ventilator:
- Disconnect the ventilator from the mains power when not in use
or before servicing/maintenance. - Use the fan in dry areas only and avoid wet or high
condensation locations like bathrooms, showers, or pools. - If the ventilator falls into water, immediately switch off and
disconnect from the mains power supply. Do not touch the ventilator
until disconnected. - Always disconnect the ventilator from the power supply when
moving it between locations.
PORTABLE VENTILATORS WITH DUCTING
MODEL Nos: VEN200.V3
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to instruction
manual
1. SAFETY
1.1.
1.1.1. 1.1.2. 1.1.3.
8 8 8
1.1.4.
1.2 9 9 8 9 9 9 8 8 8 8 8 8 8 9
ELECTRICAL SAFETY
WARNING! It is the user’s responsibility to check the following:
Check all electrical equipment and appliances to ensure that they are safe before using. Inspect power supply leads, plugs and all
electrical connections for wear and damage. Sealey recommend that an RCD (Residual Current Device) is used with all electrical
products.
If the product is used in the course of business duties, it must be maintained in a safe condition and routinely PAT (Portable Appliance
Test) tested.
Electrical safety information: it is important that the following information is read and understood.
Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
Regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that they are secure.
Important: Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is fitted with the correct
fuse – see fuse rating in these instructions.
DO NOT pull or carry the appliance by the power cable.
DO NOT pull the plug from the socket by the cable.
DO NOT use worn or damaged cables, plugs or connectors. Ensure that any faulty item is repaired or
replaced immediately by a qualified electrician.
This product is fitted with a BS1363 3 pin plug.
If the cable or plug is damaged during use, switch the electricity supply and remove from use.
Ensure that repairs are carried out by a qualified electrician.
Replace a damaged plug with a BS1363 3 pin plug. If in doubt contact a qualified electrician.
A) Connect the GREEN/YELLOW earth wire to the earth terminal `E’.
B) Connect the BROWN live wire to the live terminal `L’.
C) Connect the BLUE neutral wire to the neutral terminal `N’. Ensure that the cable outer sheath extends inside the cable restraint and that the restraint is tight. Sealey recommend that repairs are carried out by a qualified electrician.
Replacement fuse rating: 3A
GENERAL SAFETY
Disconnect the ventilator from the mains power when not in use, and before servicing or performing any maintenance.
Use the fan in dry areas only. Do not use in wet or high condensation locations such as bathrooms, showers, or pools.
WARNING! If a ventilator falls into water, immediately switch off at the mains and disconnect from the mains power supply.
DO NOT touch the ventilator until the mains power supply has been disconnected.
Always disconnect the ventilator from the power supply when moving it from one location to another.
Keep the ventilator clean and maintain in good condition (use an authorised service agent).
Use recommended parts only (unauthorised parts may be dangerous, and will invalidate your warranty).
DO NOT stand the ventilator where it may be knocked over or off a surface, or where the lead may cause a trip hazard.
DO NOT use an extension cord unless it has been approved by an electrical authority.
DO NOT insert any objects through the fan guard.
DO NOT allow children to operate the ventilator.
DO NOT immerse the ventilator in water or any other liquid.
DO NOT use the ventilator outdoors.
DO NOT cover the ventilator.
When not in use store in a safe, dry, childproof location.
2. INTRODUCTION
Ideal for use where high-volume clean air delivery is required. Especially designed to easily ventilate hot or fume laden work areas, creating a cleaner and more pleasant working environment. Supplied with 5m ducting (VEN200AK1). Optional 10m ducting (VEN200AK2) available, but not supplied. The air mover/ventilator can be used across multiple industries including, but not exclusive to; marine, roof spaces and building sites, cable/pipe ducts and workshops. Light weight in construction with large carry handle makes it easily portable. Fitted with 2m cable and 3-pin plug. Ducting supplied is compatible with other leading manufacturers products with Ø200mm.
© Jack Sealey Limited
Original Language Version
VEN200.V3 Issue: 2 01/03/23
3. SPECIFICATION
Model no……………………………………………………..VEN200.V3 Fan diameter………………………………………………………200mm Fan speed………………………………………………………..2800rpm IP rating………………………………………………………………..IPX4 Power…………………………………………………………………..115W Replacement parts…………………….VEN200AK1/VEN200AK2 Static pressure…………………………………………………..3.1mbar Supply…………………………………………………………………..230V
4. OPERATION
4.1.
Decide on the direction of air flow, depending on your requirement (ventilate or extract). See fig 1 for direction of air flow.
4.2.
Ducting can be attached to either end of the ventilator depending on whether you wish to remove/extract fumes or deliver
fresh air into a work space.
4.3.
To change direction of air flow rotate the unit 180° as the air flow is a fixed direction.
4.4.
Secure ducting by pulling the string tight then move the toggle switch to start the unit; select a low or high fan speed as required.
NOTE: The ducting has locating lugs attached to it; these can be used to suspend the ducting if required.
DIAGRAM SHOWS VENTILATION OPERATION
Air Flow
Extraction side
Ventilation side
fig.1
ENVIRONMENT PROTECTION Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids according to local regulations.
REGISTER YOUR PURCHASE HERE
WEEE REGULATIONS Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment (WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please email or call our technical team on [email protected] or 01284 757505. Important: No Liability is accepted for incorrect use of this product. Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500
www.sealey.co.uk
© Jack Sealey Limited
Original Language Version
VEN200.V3 Issue: 2 01/03/23
