ELT10 Emergency Lighting Test Switch
ELT10 Emergency Lighting Test Switch
The ELT10 Emergency Lighting Test Switch is a device designed to
test the function of emergency luminaires by interrupting the
permanent live mains supply for pre-programmed time periods. It
ensures a well-managed battery discharge, reducing the risk of
depleting the battery life and performance. The device has three
pre-programmed test intervals: 10 minutes, 1 hour (60 minutes), and
3 hours (180 minutes).
Product Dimensions
- Length: [Insert Length]
- Width: [Insert Width]
- Height: [Insert Height]
Wiring
When wiring the ELT10, follow the instructions below:
- Isolate the mains supply to the circuit at the main
distribution board. - Wire the ELT10 according to the provided diagram.
- Connect to the Emergency lighting test switch via the terminal
block:- Live (Permanent Live) supply to the L terminal
- Neutral supply to the N terminal
- For standard operation, connect the emergency lighting load to
the NC terminal and loop the incoming permanent live to the COM
terminal. - When using the ELT-REL relay unit, connect the relay to the NO
terminal and loop the incoming permanent live to the COM
terminal.
- This device has a voltage-free changeover contact output.
- Screw the unit to the wall.
- Switch on the mains supply to the circuit at the main
distribution board.
Operations
To test the emergency luminaires using the ELT10, follow these
steps:
- The unit will power up with the SUPPLY ON lamp illuminated,
connecting the supply to the NC output and energizing the connected
emergency luminaire loads. - To select a test time, turn and release the key switch:
- Turn and release once to select the 10 minutes test
interval. - Turn and release again to select the next test interval.
- Turn and release once to select the 10 minutes test
- The supply will be disconnected from the NC output and
connected to the emergency luminaire loads for the duration of the
test. - During the test, the LED light adjacent to the selected test
interval will indicate the time left. The SUPPLY ON LED will light
up once the test is complete. - To cancel a test, turn and release the key switch until the
SUPPLY ON LED illuminates.
Warning: This device works at mains potential.
Be sure to take care when working with electricity.
Key Legend:
- L – LIVE (Permanent Live)
- N – NEUTRAL
- NC – NORMALLY CLOSED
- COM – COMMON
- NO – NORMALLY OPEN
Installation
IMPORTANT NOTICE! This device should be
installed by a qualified electrician in accordance with the latest
edition of the IET wiring regulations.
ELT10 INSTALLATION GUIDE
Emergency Lighting Test Switch
Product Dimensions
Wiring
Overview
The ELT10 Emergency Lighting Test Switch, is designed to test the function of emergency luminaires by interrupting the
permanent live mains supply by pre-programmed time peri-
ods. For security of operation a key switch is used. At the end of the selected time period the permanent live supply to
the emergency luminaires is automatically re-instated. This results in a well-managed battery discharge, reducing the
risk of depleting the battery life and performance.
Three pre-programmed test intervals are available:
·
10 minutes
·
1 hour (60 minutes)
·
3 hours (180 minutes)
Warning. This device works at mains potential. Be sure to take care when working with electricity.
1.
Isolate the mains supply to the circuit at the main distribution board.
2.
Wire the ELT10 as in the diagram above.
3.
Connect to the Emergency lighting test switch via the terminal block.
a.
Live (Permanent Live) supply to the L terminal
b.
Neutral supply to the N terminal
c.
For standard operation connect the emergency lighting Load
the NC terminal and Loop the incoming permanent live to the
COM terminal
d.
When using the ELT-REL relay unit, connect the relay to the
NO terminal and Loop the incoming permanent live to the COM
terminal
4.
This device has a voltage free changeover contact output.
5.
Screw unit to the wall.
6.
Switch on the mains supply to the circuit at the main distribution board.
7.
The SUPPLY ON lamp will light up (see the adjacent image).
Key Legend
L N
NC COM
NO
— LIVE (Permanent Live) — NEUTRAL
— NORMALLY CLOSED — COMMON
— NORMALLY OPEN
Installation
IMPORTANT NOTICE! This device should be installed by a qualified electrician in accordance with the latest edition of the IET wiring regulations.
Supply On 10 minutes
1 hour 3 hours
Operations
Testing
1.
The unit will power up with the SUPPLY ON lamp illuminated — NOTE the supply will be connected to the NC output energising the connected
emergency luminaire loads.
2.
To select a test time turn and release the key switch to select the 10 minutes test interval. Turn and release again to select the next test inter-
val – the supply will be disconnected from the NC output and connected emergency luminaire loads for the duration of the test.
3.
10 minute test – The LED light adjacent to the 10 minutes will keep blinking during the test time. Once the test is complete the SUPPLY ON
LED will light up.
4.
1 Hour test – The LED light adjacent to the 10 minutes will light up, and the 1 hour LED will keep blinking during the test time. On 10 minutes
left to test the 10 minutes LED will start blinking. Once the test is complete the SUPPLY ON LED will light up.
5.
3 Hour test – The LED light adjacent to the 10 minutes and the 1 hour LED will light up and the 3 Hour LED will keep blinking during the test
time. On 1 hour left to test the 1 hour LED will start blinking, on 10 minutes left to test the 10 minutes LED will start blinking. Once the test is
complete the SUPPLY ON LED will light up.
6.
The blinking of the LED denotes the test time left.
7.
To cancel a test, turn and release the key switch until the SUPPLY ON LED illuminates.
Supply On 10 minutes
1 hour 3 hours
Supply On 10 minutes
1 hour 3 hours
Supply On 10 minutes
1 hour 3 hours
Supply On 10 minutes
1 hour 3 hours
Supply On 10 minutes
1 hour 3 hours
LOAD 10 Amp incandescent lighting
6 Amp fluorescent lighting
3 Amp compact fluorescent lighting 3 Amp LED lighting
3 Amp low voltage lighting Fluorescent lighting (max 6 fittings recommended)
For fluorescent lighting total power factor correction capacitance must not exceed 40F
SUPPLY VOLTAGE TIMING PERIOD FIXING METHOD
220-240 Volts AC 50 Hz 10 minutes, 1 hour, 3 hours
Surface fixing 25mm deep plastic surface mount moulded box. Flush fixing 25mm steel wall box or 32mm deep cavity wall box.
TERMINAL CAPACITY CONTACTS MATERIAL TYPE TEMPERATURE CONFORMITY
2.5mm2
Microgap µ Flame retardant ABS
Class 2 -10°C to 35°C
EMC-2014/30/EU
LVD-2014/35/EU
For further compliance information visit www.cpelectronics.co.uk/compliance
Cancel Test
Specification
C.P. Electronics Ltd Brent Crescent
London
NW10 7XR United Kingdom
Tel: + 44 (0) 333 900 0671 Fax: + 44 (0) 333 900 0674
www.cpelectronics.com [email protected]
Due to our policy of continual product improvement CP Electronics reserves the right to alter the specification of this product without prior notice.
Ref: #WD004 Issue 11
