ColorKey CKU-3050 StageBar HEX 12
Please read these instructions carefully before use. Operating this fixture according to these instructions is important to avoid any possible damage or accidents caused by misuse.
Introduction
Package Contents
- StageBar HEX 12
- PowerCon Locking Power Cable
- IR Remote
- User Manual
Safety
Caution! Opening this unit voids warranty. Contact ColorKey for any service requests.
Warning! To avoid electrical shock, be sure to disconnect power before any service or when moving or setting up the fixture.
Caution! Avoid direct eye exposure with the fixture when on.
- This fixture is for indoor use only.
- This fixture must be installed a minimum distance of 5 meters (16’4”) away from any lighted objects.
- Do not install or operate this fixture near flammable materials.
- This device must be installed, operated, and maintained by a qualified professional.
- Please check if the voltage is in accordance with the rated power before installing.
- Do not operate this fixture if the power cord has been damaged. Turn off fixture and replace with a power cord of similar rating.
Service & Support
Your ColorKey product includes a 2-year warranty. For technical support or to register your product, please visit https://www.colorkeyled.com/support/
You can also reach us by phone Monday thru Friday, 8:30am – 5pm PST at (818) 578-4030.
Display Operation
- MENU: Access the menu/Scroll through menu options
- UP: Scroll through menu selection or increase parameter
- DOWN: Scroll through menu selection or parameters decrease
- ENTER: Open/Select the current menu option
| Menu Item | Values | Function |
| A001 | 001-512 | DMX Address Seting |
| 06CH | 6 / 8 / 11 / 72 | Channel Select |
| CC50 | 00-99 | Color Jump Mode |
| Ed50 | 00-99 | Color Pulse Mode |
| Er50 | 00-99 | Colors Run Mode 1 |
| Po50 | 00-99 | Colors Run Mode 2 |
| Tr50 | 00-21 | Pixel Colors Mode |
| Tu50 | 00-99 | Pixel Colors Mode speed |
| BE50 | 00-99 | Sound to Dimmer Mode |
| R255 | 000-255 | Red Color dimming |
| G255 | 000-255 | Green Color dimming |
| B255 | 000-255 | Blue Color dimming |
| W255 | 000-255 | White Color dimming |
| Y255 | 000-255 | Amber Color dimming |
| P255 | 000-255 | UV Color dimming |
| ST00 | 000-255 | Strobe Speed (slow to fast) |
DMX Values
6 channels mode
| Channel | Value | Function |
| 1 | 0-255 | Red dimming (from dark to bright) |
| 2 | 0-255 | Green dimming (from dark to bright) |
| 3 | 0-255 | Blue dimming (from dark to bright) |
| 4 | 0-255 | White dimming (from dark to bright) |
| 5 | 0-255 | Amber dimming (from dark to bright) |
| 6 | 0-255 | UV dimming (from dark to bright) |
8 channels mode
| Channel | Value | Function |
| 1 | 0-255 | Master Dimmer RGBWA+UV(from dark to bright) |
| 2 | 0-255 | Strobe (from slow to fast) |
| 3 | 0-255 | Red dimming (from dark to bright) |
| 4 | 0-255 | Green dimming (from dark to bright) |
| 5 | 0-255 | Blue dimming (from dark to bright) |
| 6 | 0-255 | White dimming (from dark to bright) |
| 7 | 0-255 | Amber dimming (from dark to bright) |
| 8 | 0-255 | UV dimming (from dark to bright) |
11 channels mode
| Channel | Value | Function |
| 1 | 0-255 | Dimming |
| 2 | 0-255 | Strobe |
| 3 | 0-25 | Dimming |
| 26-35 | No function | |
| 36-45 | Color jump | |
| 46-55 | Gradient color change | |
| 56-65 | Color select (controlled by ch. 1) | |
| 66-75 | Color jump (controlled by ch. 1) | |
| 76-85 | Pulse/gradient color change (controlled by ch. 1) | |
| 86-95 | Show 1 w gradient color change | |
| 96-105 | Show 2 w gradient color change | |
| … | ||
| 146-155 | Show7 w gradient color change | |
| 156-165 | Show 8 (controlled by ch. 1) | |
| 166-175 | Show 9 (controlled by ch. 1) | |
| … | ||
| 236-245 | Show 15 (controlled by ch. 1) | |
| 246-255 | Sound Active (controlled by ch. 1) | |
| 4 | 0-30 | Dimming |
| 31-45 | Show 1 (controlled by ch. 1) | |
| 46-60 | Show 2 (controlled by ch. 1) | |
| … | ||
| 240-255 | Show 15 (controlled by ch. 1) | |
| Direction of LED running (0-127, toward left ,128-255, toward right) | ||
| 5 | 0-255 | Speed control from slow to fast |
| 6 | 0-255 | Red dimming (from dark to bright) |
| 7 | 0-255 | Green dimming (from dark to bright) |
| 8 | 0-255 | Blue dimming (from dark to bright) |
| 9 | 0-255 | White dimming (from dark to bright) |
| 10 | 0-255 | Amber dimming (from dark to bright) |
| 11 | 0-255 | UV dimming (from dark to bright) |
72 channels mode
| Channel | Value | Function |
| 1 | 0-255 | Red1 dimming (from dark to bright) |
| 2 | 0-255 | Green1 dimming (from dark to bright) |
| 3 | 0-255 | Blue1 dimming (from dark to bright) |
| 4 | 0-255 | White1 dimming (from dark to bright) |
| 5 | 0-255 | Amber1 dimming (from dark to bright) |
| 6 | 0-255 | UV1 dimming (from dark to bright) |
| 7 | 0-255 | Red2 dimming (from dark to bright) |
| 8 | 0-255 | Green2 dimming (from dark to bright) |
| 9 | 0-255 | Blue2 dimming (from dark to bright) |
| … | … | … |
| 70 | 0-255 | White12 dimming (from dark to bright) |
| 71 | 0-255 | Amber12 dimming (from dark to bright) |
| 72 | 0-255 | UV12 dimming (from dark to bright) |
Infrared Remote (IR) Control
To use the IR remote, simply point the remote at the IR receiver on the lighting fixture. The IR receiver on the StageBar HEX 12 is located front panel with the LED lenses.
Black Out
Black Out mode instantly turns all LED’s off. Press the Black Out button to engage or disengage Black Out mode.
Addr
Address mode enables you to set the DMX Address of the fixture. To set up a new DMX address, Press the Addr button, then press (+) or (-) to increase or decrease the DMX Address Value.
Sound
Sound-Active mode enables the light to respond to ambient sounds in the room using the fixture’s built in microphone. Press the Sound button to activate Sound-Active mode. Press (+) or (-) to increase or decrease sound sensitivity based on the playback level of the music.
Auto
In Auto mode, the light loops through various preprogrammed colors.
To turn on Auto mode, press the Auto button, then press (+) or (-) to increase or decrease the speed of the program.
Strobe
In Strobe mode, the light will flash at the desired rate.
To turn on Strobe mode, press the Strobe button, then press (+) or (-) to increase or decrease the strobing rate. You can change the color using manual color mixing (more below).
Fade
In Fade Mode, the light creates smooth, gradual color transitions.
To turn on Fade mode, press the Fade button, then press (+) or (-) to increase or decrease the speed of the program.
Manual Color Mixing
To begin mixing colors, press the Red (R), Green (G), Blue (B), or White (W) button, then press (+) or (-) to increase or decrease the brightness of each color. Continue with the next color until you achieve your desired color.
Color Presets
10 preset colors can be accessed from the IR Remote. Press any number between (1) and (10) to set a color.
- Red
- Green
- Blue
- Amber
- White
- UV
- Yellow
- Magenta
- Red/Orange
- Pink
Setup & Connections
Wired DMX Cable Connections
Use a DMX to cable to connect to the in/out sockets on the bottom of the light for use with a cabled connection for DMX 512 control.
Technical Information
- 12x10W RGBWA+UV 6-in1 LEDS
- DMX Channel Modes: 6 / 8 / 11 / 72 channels
- Control modes: DMX 512, Master /Slave, IR Remote, Sound to Dimmer, Stand Alone
- 0-100% Dimmer
- Lamp rated life: >50000 Hours
- Working temperature: up to 40˚C
- Power connection: PowerCon In / Out
- Power consumption: 130W
- Power link:110v, max 25 units, @220v, max 50 units
- Power supply: AC110-240V;50-60Hz
Please note: As we continue to work towards improving our products and your experience as a user, we recommend that you check our website periodically for updates to user manuals and specifications at www.ColorKeyLED.com or you may contact us directly at [email protected].
