Omcan Rs-cn-0500 White Refrigerated Floor Display Case User Manual

RS-CN-0500 White Refrigerated Floor Display Case

Product Information:

The product is a Model RS-CN-0500 34874, which is a
refrigeration unit. It consists of various parts that make up the
unit, including a base, evaporator, trays, frames, grill, ceiling,
panel, shelf, door frame, gasket, poles, glass, transformer, light,
motor, flange, fan blade, condenser, junction box, shelf clips,
power cord, door pin, digital controller, filling pipe, evaporator
pipe, dry filter, gemel, stiffener, air outlet cover, door handle,
water receiver, controller box, compressor, and motor bracket.
These parts work together to provide cooling and storage
functionality.

Product Usage Instructions:

Assembly:

1. Start by assembling the base (item no. 60908) and securing it
   properly.
2. Attach the plastic base of the evaporator (item no. 60909) and
   the foam base for the evaporator (item no. 60910).
3. Place the inner ventilated tray (item no. 60911) and the outer
   ventilated tray (item no. 60912) inside the unit.
4. Install the inner enclosure frame (item no. 60913) and the
   outer enclosure frame (item no. 60914).
5. Attach the rear grill (item no. 60915) and the light ceiling
   (item no. 60916).
6. Install the foam of the light ceiling (item no. 60917) and the
   outer plastic panel (item no. 60918).
7. Place the shelves (item no. AC195) at desired positions using
   the front poles of shelves (item no. 60924).
8. Attach the bottom door frame (item no. 60920) and the upper
   door frame (item no. 60921).
9. Install the evaporator (item no. 60922) and the door gasket
   (item no. 60923).
10. Attach the left and right door frames (item no. 60925) and the
    rear pole (item no. 60926).
11. Install the rear glass (item no. 60927) and the side glass
    (item no. 60928).
12. Connect the LED transformer (item no. 60595) and install the
    LED light (item no. 60929).
13. Attach the door glass (item no. 60930) and install the motor of
    the evaporator (item no. 60931).
14. Secure the flange (item no. 60932) and attach the fan blade of
    the condenser (item no. 60933).
15. Install the condenser (item no. 60934) and cover it with the
    junction box cover (item no. 79359).
16. Attach the junction box (item no. 61244) and secure it
    properly.
17. Place the shelf clips (item no. 45107) as needed to hold the
    shelves in place.
18. Connect the power cord (item no. 79290) to a power source.
19. Insert the door pin (item no. 30606) into its designated
    position.
20. Install the digital controller (item no. 60939) and set it up
    according to the user manual.
21. Connect the filling pipe (item no. 60143) and the evaporator
    pipe (item no. 60941).
22. Install the dry filter (item no. 79319) and the upper gemel
    (item no. 30587).
23. Attach the motor of the evaporator (item no. 60944) and the
    stiffener (item no. 60945).
24. Secure the air outlet cover (item no. 60946) and attach the
    door handle (item no. 60947).
25. Place the water receiver (item no. 60948) in its designated
    position.
26. Install the controller box (item no. 60137) and connect it to
    the controller panel (item no. 60136).
27. Attach the compressor (item no. 60949) and secure it with the
    motor bracket (item no. 60950).
28. Attach the rear wheels (item no. 60561) and the front wheels
    (item no. 60562) for mobility.

Note: Please refer to the user manual for detailed instructions
and safety precautions.

Parts Breakdown
Model RS-CN-0500 34874

Parts Breakdown

Model RS-CN-0500 34874

Item No. Description

60908

Base for 34874

60909

Plastic Base of Evaporator for 34874

60910

Foam Base for Evaporator for 34874

60911

Inner Ventilated Tray for 34874

60912

Outer Ventilated Tray for 34874

60913

Inner Enclosure Frame for 34874

60914

Outer Enclosure Frame for 34874

60915

Rear Grill for 34874

60916

Light Ceiling for 34874

60917

Foam of Light Ceiling for 34874

60918

Outer Plastic Panel for 34874

AC195

Shelf for 34874

60920

Bottom Door Frame for 34874

60921

Upper Door Frame for 34874

60922

Evaporator for 34874

60923

Door Gasket for 34874

60924

Front Poles of Shelves for 34874

Position 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17

Item No. Description

60925

Left and Right Door Frame for 34874

60926

Rear Pole for 34874

60927

Rear Glass for 34874

60928

Side Glass for 34874

60595

LED Transformer for 34874

60929

LED Light for 34874

60930

Door Glass for 34874

60931

Motor of Evaporator for 34874

60932

Flange for 34874

60933

Fan Blade of Condenser for 34874

60934

Condenser for 34874

79359

Cover of Junction Box for 34874

61244

Junction Box for 34874

45107

Shelf Clips for 34874

79290

Power Cord for 34874

30606

Door Pin for 34874

60939

Digital Controller for 34874

Position 18 19 20 21 22-1 22-2 23 24 25 26 27 28 29 30 31 32 33

Item No. Description

60143

Filling Pipe for 34874

60941

Evaporator Pipe for 34874

79319

Dry Filter for 34874

30587

Upper Gemel for 34874

60944

Motor of Evaporator for 34874

60945

Stiffener for 34874

60946

Air Outlet Cover for 34874

60947

Door Handle for 34874

60948

Water Receiver for 34874

60137

Controller Box for 34874

60136

Controller Panel for 34874

60949

Compressor for 34874

60950

Motor Bracket for 34874

60561

Rear Wheels for 34874

60562

Front Wheels for 34874

Position 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
