Omcan Rs-cn-0163-b Refrigerated Floor Showcase User Manual

Product Information:

• Model: RS-CN-0163-B 50083
• Parts Breakdown:

1. AB607 – Right Track of Installation Board for 50083
2. AB634 – Installation Board of Compressor for 50083
3. AA248 – Blade of Condenser Fan Motor for 50083
4. AA300 – Condenser for 50083
5. 26247 – Caster without Brake for 50083
6. AB697 – Support Board of Leveling Feet for 50083
7. AA304 – Installation Board Limited Block for 50083
8. AB699 – Front Grill for 50083
9. AB700 – Fixed Board of Curve Glass for 50083
10. AB701 – Curve Glass for 50083
11. AB702, AB641, AB642, AB705, AB644, AB769, AB708, AM934 – Curve
    Glass for 50083 (continued)
12. LED Light for 50083
13. Bottom Shelf for 50083
14. Shelf Support Board Connector for 50083
15. Right Shelf Support Board for 50083
16. Middle Shelf for 50083
17. Left Shelf Support Board for 50083
18. Right Hanger of Grill for 50083
19. Grill Components for 50083
20. Evaporator for 50083
21. AA135 – Power Cord for 50083
22. AA711, AA378, AA124, AB582, AA214, AB604, AB772, AE984 – LED
    Power Supply for 50083
23. Temperature Probe Fixer for 50083
24. Power Switch for 50083
25. Thermostat for 50083
26. Thermostat Water Proof Cover for 50083
27. Sealing Rubber Strip for Curved Glass for 50083
28. Left Hanger of Grill for 50083
29. Thermostat Installation Cover for 50083
30. AA528, AB652, AB650, AB619, AB651, AB716, AB717, AB589, AA874,
    AG542 – Inner Drain Pipe for 50083
31. Left Bracket for 50083
32. Middle Bracket for 50083
33. Right Bracket for 50083
34. Air Pipe Protection Board for 50083
35. Glass Door for 50083
36. Framework of Glass Door for 50083
37. Coiled Copper Pipe of Outer Drain Pan for 50083
38. Outer Drain Pan for 50083
39. Inner Drain Pipe for 50083 (duplicate)
40. AB719 – Compressor for 50083
41. AB720, AB595, AB594, AA984, AA249, AB657, AB658, AB784, AB724,
    AB659, AB726, AB667, AB728, AB729, AM936, AB084, 26246 – Compressor
    Components for 50083
42. Filter Fixer for 50083
43. Filter D25x160-B for 50083
44. Condenser Fan Motor for 50083
45. Condenser Fan Motor Cover for 50083
46. Left Track of Installation Board for 50083
47. Cover Board of Machine Room for 50083
48. Support Board of Machine Room for 50083
49. Cover Board of Machine Room (Big) for 50083
50. Support Holder of Cabinet for 50083
51. Right Back Grill for 50083
52. Thermostat Mounting Plate for 50083
53. Baffle for Evaporator for 50083
54. Defrost Heater for 50083
55. Upper Shelf for 50083
56. Evaporator Temperature Sensor for 50083
57. Caster with Brake for 50083

Product Usage Instructions:

1. Ensure all parts listed in the breakdown are included in the
   package.
2. Refer to the installation board of compressor (AB634) to
   properly mount the compressor (AB719).
3. Attach the blade of the condenser fan motor (AA248) to the
   condenser (AA300).
4. Install the caster without brake (26247) to the designated
   area.
5. Place the support board of leveling feet (AB697) in the
   appropriate position.
6. Securely attach the installation board limited block (AA304) to
   the installation board of compressor (AB634).
7. Mount the front grill (AB699) onto the designated area.
8. Fix the fixed board of curve glass (AB700) to ensure
   stability.
9. Attach the curve glass (AB701) and its components (AB702,
   AB641, AB642, AB705, AB644, AB769, AB708, AM934) to the designated
   position.
10. Install the LED light (LED Light for 50083) in the assigned
    slots (11, 12).
11. Place the bottom shelf (Bottom Shelf for 50083) in the desired
    location.
12. Connect the shelf support board connector (Shelf Support Board
    Connector for 50083) to the right shelf support board (Right Shelf
    Support Board for 50083).
13. Position the middle shelf (Middle Shelf for 50083)
    accordingly.
14. Attach the left shelf support board (Left Shelf Support Board
    for 50083) to complete the shelving setup.
15. Securely mount the right hanger of grill (Right Hanger of Grill
    for 50083) to the designated area.
16. Assemble the grill components (Grill Components for 50083)
    according to the provided instructions.
17. Install the evaporator (Evaporator for 50083) in the
    appropriate position.
18. Connect the power cord (AA135) to the designated slot (Position
    21).
19. Install the LED power supply (LED Power Supply for 50083) using
    the provided components (AA711, AA378, AA124, AB582, AA214, AB604,
    AB772, AE984).
20. Fix the temperature probe fixer (Temperature Probe Fixer for
    50083) securely in place.
21. Attach the power switch (Power Switch for 50083) to the
    designated position.
22. Mount the thermostat (Thermostat for 50083) and ensure it is
    properly covered with the thermostat water proof cover (Thermostat
    Water Proof Cover for 50083).
23. Apply the sealing rubber strip for curved glass (Sealing Rubber
    Strip for Curved Glass for 50083) to ensure a tight seal.
24. Securely attach the left hanger of grill (Left Hanger of Grill
    for 50083) to the designated area.
25. Cover the thermostat installation with the provided cover
    (Thermostat Installation Cover for 50083).
26. Connect the inner drain pipe (Inner Drain Pipe for 50083) using
    the specified components (AA528, AB652, AB650, AB619, AB651, AB716,
    AB717, AB589, AA874, AG542).
27. Install the left bracket (Left Bracket for 50083), middle
    bracket (Middle Bracket for 50083), and right bracket (Right
    Bracket for 50083) in the appropriate positions.
28. Attach the air pipe protection board (Air Pipe Protection Board
    for 50083) to protect the pipes.
29. Mount the glass door (Glass Door for 50083) and its framework
    (Framework of Glass Door for 50083) securely.
30. Connect the coiled copper pipe of outer drain pan (Coiled
    Copper Pipe of Outer Drain Pan for 50083) to the outer drain pan
    (Outer Drain Pan for 50083).
31. Connect the inner drain pipe (Inner Drain Pipe for 50083) to
    complete the drainage system.
32. Assemble the compressor components (Compressor Components for
    50083) according to the provided instructions.
33. Securely fix the filter fixer (Filter Fixer for 50083) in
    place.
34. Install the filter (Filter D25x160-B for 50083) in the assigned
    position (43).
35. Attach the condenser fan motor (Condenser Fan Motor for 50083)
    and cover (Condenser Fan Motor Cover for 50083) to complete the
    cooling system.
36. Mount the left track of installation board (Left Track of
    Installation Board for 50083) in the designated area.
37. Cover the machine room with the cover board (Cover Board of
    Machine Room for 50083) and secure it using the support board
    (Support Board of Machine Room for 50083).
38. Attach the big cover board of machine room (Cover Board of
    Machine Room (Big) for 50083) to complete the machine room
    setup.
39. Securely attach the support holder of cabinet (Support Holder
    of Cabinet for 50083) in place.
40. Mount the right back grill (Right Back Grill for 50083) to the
    designated area.
41. Install the thermostat mounting plate (Thermostat Mounting
    Plate for 50083) in the assigned position.
42. Attach the baffle for evaporator (Baffle for Evaporator for
    50083) to enhance cooling efficiency.
43. Install the defrost heater (Defrost Heater for 50083) to
    prevent ice buildup.
44. Place the upper shelf (Upper Shelf for 50083) in the desired
    location.
45. Connect the
