ZOOM19 LED Zoom Moving Head Light

Product Information: LED ZOOM MOVING HEAD LIGHT

The LED ZOOM MOVING HEAD LIGHT is a lighting fixture that uses
19 RGBW 4IN1 LEDs and operates on DMX 512 protocol. It is designed
to provide high brightness, gaily-colored, and astigmatic lighting
effects. The light has a long lifespan of 60-100 thousand hours and
is energy-efficient, making it a green lighting tool. It can be
controlled through DMX512 and offers various color-changing
effects.

Technical Specifications

– DMX Channels: 15/23CH

– LED Type: 19PCS RGBW 4IN1

– Weight: Approximately 8kg per LED moving head

– Power Consumption: 200VA

Installation of LED Moving Head

1. Use the four M8 bolts to securely install the LED moving
head. Ensure that the installation is reliable to prevent swings
and skids during operation.

2. Check if the structure can support the weight of the LED
moving head (approximately 8kg).

3. Install a safety chain on the lamp body side handle for added
security.

Connection of Control Correspond Wire

– Use twin-core shielded cables with a minimum core diameter of
0.3mm to connect the controller and each LED moving head lamp.

– When receiving the DMX512 signal, the lamp near the address
switch will glisten.

– If the lamp glistens continuously, it indicates an incorrect
DMX signal.

– For better performance, use a DMX signal terminal to avoid
digital control signal breaches due to electrical noise.

Connection of Power Cable

– Use the provided plug to connect the main power to the
projector. Pay attention to the voltage and frequency marked on the
panel.

– Each projector should be supplied separately to allow
individual switching on and off.

– Ensure proper grounding and adherence to electrical
installation standards.

– Use a three-core shielded cable to connect the power cable
between each LED moving head lamp.

– The power cable can only supply power for a maximum of 4
lights to avoid overloading the power supply.

USER MANUAL
LED ZOOM MOVING HEAD LIGHT
(19PCS RGBW 4IN1 DMX 512 15/23CH)
Please read over this manual before operation the light

CONTENTS Contents…………………………………………………………….0 Important notice……………………………………………………..1 Attention …………………………………………………………..1 I. Product Illustration………………………………………………2 II .The installment of led moving head ……………………………2 III. The connection of control correspond wire……………………3 IV. Clean maintenance ……………………………………………4 V. Warning…………………………………………………………5 VI. Difficult processing……………………………………………5 VII. Equipment and appendix………………………………………5
VIII. Technical paramet………………………………..6 IX. Functional description…………………………….6 X. Functional description……………………………6 XI. Panel operation……………………………………7 IIDMX512channels……………………………….9
1

Important notice:
· In this instruction for use contains about the installment and the use aspect important information of the LED moving head. When installing and using, you need to look this usage instruction strictly. · Before open the LED moving head and if you want to do the repair work, please make sure the power source is at the separation condition.
Attention:
Unceasingly carries on the product improvement about our company the policy, in this instruction booklet carries the data will have the possibility to be able to change in the future, when no longer separate notice change matters concerned. Our company retains when the product improvement changes the related specification the authority. This instruction booklet publisher cannot be responsible regarding this instruction booklet in information accuracy, also cannot the related consequence which causes regarding these information be responsible.
I. Product Illustration
Our product adopt semiconductor to produce radiation, LED as light origin. With advantage of operation quietly, less power waste, high brightness, gaily-colored, astigmatic, high longevity (60-100 thousands hours), non-calorific etc. Our product apply to use 3 kinds light as red, green, blue LED, synthesize turn colors under election, can create effect of auto gradual change/skip change color, frequent blinking. Can accept control by DMX512, real save power, no pollution green lighting tool.
II .The installment of led moving head
Use the four bolts with M8 size by the clip of the LED moving head to install it. Should guarantee the reliability of the install, this way is to prevent the LED moving head occur swings and skids when it’s working. The weight is about 8Kg of each LED moving head, before install, you should confirm the structure whether can support this weight of the LED moving head light. In order to guarantee the security, you also need to install a safety chain in the lamp body side handle.
2

Warning: Do not use the hand of the LED moving head to up and down or fix. III. The connection of control correspond wire
The connection of controller between the led moving head lamp and respectively led moving head lamp should use the twin core shielded cable, and the diameter of each core at least be 0.3mm. After receives the DMX512 signal, the lamp of nearby the address switch condition will glisten. When it’s do not receive the DMX signal, the lamp will in extinguish condition, but if the signal lamp glisten continuously, the mean is the DMX signal is not be correct.
When installing, uses the DMX signal terminal is much better. It can avoid the digital control signal breached by the electrical noise. Generally speaking, the DMX terminal is Cannon plug coupling, it has a 120 ohm resistances between the 2 feet and 3 feet, it will connected on the last led moving head lamp’s digital plug of the led moving head lamp chain.
3

333 12

DMX+
DMXGND

3 21

Connecting DMX512 digital signal, Please using high quality screen line to connect it, for fear interfering.
GND

333

1

2

DIGITAL SIGNAL

3

2

1

IV. the connection of Power Cable
Use the provided plug to connect the main power to the projector paying attention to the voltage and frequency marked on the panel of the projector. It is recommended that each projector be supplied separately so that they may be individually switched on and off.
IMPORTANT It is essential that each projector is correctly earthed and that electrical installation conforms
4

to all relevant standards. Power consumption of this projector is 200VA. The connection of Power cable between the led moving head lamp and respectively led moving head lamp should use the three core shielded cable, Power cable joint (at most 4pcs) in each other, this is the Connector picture as below: Important Notice: In order to avoid overloading the power supply, the power cable can only supply power for at most 4 light
V. Clean maintenance
In order to guarantee the LED moving head lamp can work better, you should keep the lamp in clean state. Suggests clean the lamp body and fan in each 15 days. For the PVS board, you need clean it on time. When you cleaning the PVC piece, please do not use any soluble cleanser,
VI. Warning
·Don’t disassemble and assemble the LED moving head. ·Please do not put the led moving head lamp in water or other any type’s liquids and the
metal (IP20). ·Do not install the led moving head lamp in the humidity environment. ·Should maintain the minimum 0.5 meter distance between the led moving head lamp and
other neighboring object surface.
5

VII. Difficult processing

Question

Answer

The LED moving head lamp can not Inspects the fuse on the rear panel. start.

Although shines, but the LED moving Check the digital start address (sees

head lamp can not accept the 09th) and also check the connection

instruction of the controller.

situation of the communication control

line the (to see 03rd).

LED moving head lamp only can work Inspect the power supply and voltage

intermittently.

is whether normal.

Do not receive the DMX512 signal The light beam appears gloomily.

Whether the signal lines do contact good or broken
Inspect the optics part is whether clean.

Other maintains work should by the specialist which has the experience to carry on.

VII. Equipment and appendix
1 led moving head lamp 2 the product of USER MANUAL 3 Power source connected lines 4 signal lines

1PCE 1PCE 1PCE 1PCE

VIII. Technical parameters
Voltage / frequency: 90-130V/ 180V-240V/50-60Hz
Bulbs: 19*10W RGBW Power:250 W Control signal: DMX 512, in sets at the automatic procedure Channel: 15/23CH, DMX512 channel control Motion: level 540°, vertical 280°, horizontal and vertical uses the electronic replacement
function
6

Color: 16.7 million kinds of colors changes Adjusts the light: 0-100 electron adjusts the light, various colors may alone move also may mix the color tone Strobe: 1-25/second high speed strobe, but single color mixes the color strobe ZOOM angel: 105-30degree adjust
IX. Functional description
Ccontroller can control Moving head light’s three axes (PAN axis, TITL axis and Zoom axis), The light have RGBW 4IN1 Multi-Chip LED Lamp, and 3IN1 Tricolor RGB LED Moving Head, and 3color and 4 color, it have DMX mode (can be set DMX address), self-propelled mode (can be set up master-slave), Sound mode (can be set master / slave), The mode selection can be set by the panel or DMX 512 controller (this must be set to DMX mode); The light also have strobe / random frequency flash / strobe out fast and slow / slow forward faster strobe mode, the color jump / gradients
X. Functional Setting 1. Fast operation settings
Controller can quickly set the light’s mode, the main interface, followed by “ESC” key to select DMX mode, Auto mode or sound-activated mode, In DMX mode: Press “UP” “DOWN” to optional DMX address; In the self-propelled mode: Press “UP” “DOWN” to choose master or slave; In the sound mode: Press “UP” “DOWN” to choose master or slave I
X. Panel operation
A Manual B up C down D Enter
7

E. LCD Display
A B CD
Operating instructions: Pree A will show different function,Press B or C for changing function,Press D for enter.
Detailed function instruction:
1 [DMX Address Set] for setting DMX address for light 2 [Work Mode Set] For setting diffrent work mode, 3 mdoes workable ,they are
DMX512,AUTO,SOUND Activated..When entering AUTO or SOUND,Light will send DMX signals automatically.
3 [Invert PAN Set] 4 [Invert TILT Set] 5 [Channel Set] For chosing different Channel Mode, two kinds available,23 channels or 15 Channels. 6 [Restore Factory Settings] 7 [Reset] For resetting light
8

23DMX channel function

23 Channels
CH 1 CH 2 CH 3 CH 4
CH 5
CH 6 CH 7

pan Adjustment Pan fine
Tilt Adjustmen Tilt fine
pan/tilt moving speed zoom dimming

CH 8

strobe

CH 9
CH 10
CH 11 CH 12 CH 13 CH 14 CH 15 CH 16 CH 17 CH 18 CH 19 CH 20 CH 21 CH 22
CH 23

LEDS color changing
LEDS color changing speed R1 G1 B1 W1 R2 G2 B2 W2 R3 G3 B3 W3
Reset

pan Adjustment Pan fine
Tilt Adjustment Tilt fine
from fast to slow
from near to far from duck to bright
no function
strobe from slow to fast
no function LEDS color changing
from fast to slow
from dark to bright from dark to bright from dark to bright from dark to bright from dark to bright from dark to bright from dark to bright from dark to bright from dark to bright from dark to bright from dark to bright from dark to bright
no function reset

0—-255 0—-255 0—-255 0—-255
0—-255
0—-255 0—-255 0—-15
16—-255
0—-15 16—-255
0—-255
0—-255 0—-255 0—-255 0—-255 0—-255 0—-255 0—-255 0—-255 0—-255 0—-255 0—-255 0—-255 0—-127 128—-255

9

15 Channels CH 1 CH 2 CH 3 CH 4
CH 5
CH 6 CH 7
CH 8

pan Adjustment Pan fine
Tilt Adjustment Tilt fine
pan/tilt movign speed zoom Dimming
strobe

CH 9
CH 10
CH 11 CH 12 CH 13 CH 14
CH 15

LEDS color changing
LEDs color changing speed
R G B W

pan Adjustment Pan fine
Tilt Adjustment Tilt fine
from fast to slow
from near to far from dark to brightness
no function strobe from slow to fast
no function LEDs’ Color changing
from fast to slow
from dark to bright from dark to bright from dark to bright from dark to bright nofunction
reset

0—-255 0—-255 0—-255 0—-255
0—-255
0—-255 0—-255 0—-15 16—-255 0—-15 16—-255
0—-255
0—-255 0—-255 0—-255 0—-255 0—-127 128—-255

Powered on LED Moving light,conect it to the DMX controller,after receving the DMX signal, the singal mark X disappeared,then light is under DMX controller’s control.
Under DMX Mode,connecting multiple lights together,but disconnect with DMX controller, all lights can work in the same step. When connected the first one to controller, the whole group can move in the same step under DMX controller’s control.
