Fs S5800 Series Switches User Guide

S5800 Series Switches

S5800/S8050/S5850 SERIES SWITCHES WEB CONFIGURATION GUIDE

S5800 Series Switches Software Upgrade Guide

Models: S5800-8TF12S; S5800-48T4S; S5800-48F4SR

Website: www.fs.com

1. Introduction to Version Upgrade

When new features are added or the original performance needs to
be optimized and the current running version is out of date, the
device needs to be upgraded. In this case, you need to load a high
version of the system software, upgrade through the CLI interface,
WEB interface, and restart the device.

2. CLI Upgrade

2.1 Network Topology

Figure 1 shows the PC connection switch page.

2.2 Configuration Steps

Follow the steps below to upgrade using the CLI interface:

  1. Login cli configuration page
  • Login Switch #After completing the above steps, hitting the
    Enter key of the keyboard will prompt you to enter the account
    password. At this time, enter the default username and password
    admin/admin to log in to the switch.
  • Upgrade Software #After logging in to the switch, open the
    installed TFTP upload software, specify the server root directory
    in its options, and put the files to be uploaded into this
    directory.
    • Figure 3 shows the TFTP server configuration page.
    • The file FSOS_S5800_8TF12S-V5.3.x.bin should be placed in the
      root directory of the server.
  • Upgrade uImage Console# copy mgmt-if
    tftp://192.168.1.2/FSOS_S5800_8TF12S-V5.3.x.bin
    flash:/boot/FSOS_S5800_8TF12S-V5.3.x.bin
    • NOTE: The 5.3.x in file FSOS_S5800_8TF12S-V5.3.x.bin indicates
      support for all versions of the 5.3 series.
  • Application System File Console#boot system
    flash:/boot/FSOS_S5800_8TF12S-V5.3.x.bin
  • Reboot the device Console#reboot

    3. Web Upgrade

    3.1 Network Topology

    Figure 4 shows the network topology for web upgrade.

    3.2 Configuration Steps

    Follow the steps below to upgrade using the web interface:

    1. Log in to the switch using the web interface.
    2. Select System Management > Upgrade > Software Management
      > Software Upgrade.
    3. Select the software package that needs to be upgraded and click
      Upgrade.
    4. Wait for the upgrade process to complete.
    5. Restart the switch.

    Note: It is recommended to consult the user manual for detailed
    information on upgrading and using the product.

    S5800/S8050/S5850 SERIES SWITCHES WEB CONFIGURATION GUIDE
    S5800 Series Switches Software Upgrade Guide
    Models: S5800-8TF12S; S5800-48T4S; S5800-48F4SR

    www.fs.com

    I

    S5800 SERIES SWITCHES SOFTWARE UPGRADE GUIDE
    Contents
    1. Introduction to Version Upgrade………………………………………………………………………………………………………………….1 2. CLI Upgrade…………………………………………………………………………………………………………………………………………………. 1
    2.1 Network Topology………………………………………………………………………………………………………………………………………………………………….. 1 2.2 Configuration Steps……………………………………………………………………………………………………………………………………………………………….. 1
    3. Web Upgrade……………………………………………………………………………………………………………………………………………… 4
    3.1 Network Topology…………………………………………………………………………………………………………………………………………………………………. 4 3.2 Configuration Steps………………………………………………………………………………………………………………………………………………………………..4

    www.fs.com

    I

    S5800 SERIES SWITCHES SOFTWARE UPGRADE GUIDE
    1. Introduction to Version Upgrade
    When new features are added or the original performance needs to be optimized and the current running version is out of date, the device needs to be upgraded. In this case, you need to load a high version of the system software, upgrade through the CLI interface, WEB interface, and restart the device.
    2. CLI Upgrade
    2.1 Network Topology
    Figure 1 PC connection switch page
    2.2 Configuration Steps
    (1) connection Equipment #Connect the PC and the switch to the network cable and the console port. Connect one end of the RJ-45 network cable to the network card interface of the PC and the other end to the network port of the SW. Connect one end of the console c able USB to the USB port of the PC. One end of the RJ-45 is connected to the console port on the front panel of the switch. (2) Download Configuration Software # After the connection is completed, there we recommend the super terminal, putty or Secure CRT tool to configure the switch. (3) Switch on and Use Login Software #Energizing the switch, then open the installed login software, select the serial port of login mode, port through the device manager to determine. Baud rate :115200, Data bits: 8, Parity: None, Stop bits: 1. (Reference below) NOTE: COM Number can be viewed through device manager. (right click on my computer.>manage>device manager>port (COM and LPT) If it displays an unrecognized USB device, please download and install the corresponding driver.

    www.fs.com

    1

    S5800 SERIES SWITCHES SOFTWARE UPGRADE GUIDE
    Figure 2 Login cli configuration page (4) Login Switch #After completing the above steps, hitting the Enter key of the keyboard will prompt you to enter the account password. At this time, enter the default username and password admin/admin to log in to the s witch. (5) Upgrade Software #After logging in to the switch, open the installed TFTP upload software, specify the server root directory in its options, and put the files to be uploaded into this directory.

    Figure 3 TFTP server configuration page
    NOTE: The file FSOS_S5800_8TF12S-V5.3.x.bin should be placed in the root directory of the server. (6) Upgrade uImage Console# copy mgmt-if tftp://192.168.1.2/FSOS_S5800_8TF12S-V5.3.x.bin flash:/boot/FSOS_S5800_8TF12S-V5.3.x.bin NOTE: The 5.3.x in file FSOS_S5800_8TF12S-V5.3.x.bin indicates support for all versions of the 5.3 series.

    www.fs.com

    2

    S5800 SERIES SWITCHES SOFTWARE UPGRADE GUIDE
    (7) Application System File Console#boot system flash:/boot/FSOS_S5800_8TF12S-V5.3.x.bin
    (8) Reboot the device
    Console#reboot
    (9) Upgrade webImage #After completing the above steps, wait for the device to restart before continuing to upgrade the webImage. Console# copy mgmt-if tftp://192.168.1.2/FSOS-webImage-v5.3.x.bin flash:/FSOS-webImage-v5.3.x.bin
    (10) Enable web services Console(config)# http server load flash:/FSOS-webImage-v5.3.x.bin Console(config)# service http enable Console(config)# service https enable

    www.fs.com

    3

    S5800 SERIES SWITCHES SOFTWARE UPGRADE GUIDE
    3. Web Upgrade
    3.1 Network Topology
    Figure 1 PC connection switch page
    3.2 Configuration Steps
    (1) Enable web services Console(config)# http server load flash:/FSOS-webImage-v5.3.9.bin Console(config)# service http enable Console(config)# service https enable NOTE: FSOS-webImage-v5.3.9.bin is the old web version. (2) Login WEB #Enter the IP address of the management interface in the URL field of the browser: 192.168.1.1, and then enter the default username and password: admin/admin

    Figure 2 Login web page

    www.fs.com

    4

    S5800 SERIES SWITCHES SOFTWARE UPGRADE GUIDE After successful login, the monitor page will appear , as shown in figure 3.

    Figure 3 Monitor page
    (3) Upgrade uImage #After entering the WEB interface of the switch, click “System Management>File Management” to select the uImage file to be upgraded on web. During the upgrade process, do not close the upgrade page and power off the device.

    Figure 4 Upgrade uImage page

    www.fs.com

    5

    S5800 SERIES SWITCHES SOFTWARE UPGRADE GUIDE (4) Application System File #After uploading the uImage, click “Use Image”, you can apply the uImage file.
    Figure 5 Apply uImage page #After applying the uImage file, you can see that it is followed by a *.
    Figure 6 File system page

    www.fs.com

    6

    S5800 SERIES SWITCHES SOFTWARE UPGRADE GUIDE (5) Reboot the device

    Figure 7 Device reboot page
    (6) Upgrade webImage #After the switch restarts, repeat step (1) and you can log back into the Web interface, click “System Management>File Management” to select the webImage file to be upgraded on web. During the upgrade process, do not close the upgrade page and power off the device.

    Figure 8 Upgrade webImage page

    www.fs.com

    7

    S5800 SERIES SWITCHES SOFTWARE UPGRADE GUIDE
    (7) Login New WEB #After upgrading the webImage, repeat step (1) and you can log back into the Web interface.

    Figure 9 New login page
    #Enter the default username and password: admin/admin, the monitor page will appear , as shown in figure 10. You can see that the uImage and webImage versions are the latest updates.

    Figure 10 New login page
    NOTE: After the version upgrade, the browser cache needs to be cleared, otherwise the previous cache will affect the current use of the Web.

    www.fs.com

    8
