PKCP9000BU 2 Piece Bushing Set for 30 Caliber Bullet Cartridge Rollerball Pen Kit
Product Information:
| ID Number | PKCP9000BU |
| Number of Parts | 2 |
| Type | Bushing |
| Thru Hole Standard | 0.248 inches |
| Notes | Cap and tip have the same measurements |
Product Usage Instructions:
The product consists of two parts – Cap/Tip (2) and an
unidentified part. The bushing type is used, and it has a standard
thru hole diameter of 0.248 inches. The cap and tip have the same
measurements.
To use the product:
- Identify the Cap/Tip (2) parts.
- Ensure that the bushing is in optimal condition with a diameter
varying by no more than .002 inches when new. - Align the bushing with the appropriate assembly or
equipment. - Insert the bushing into the designated Thru Hole with a
diameter of 0.248 inches. - Secure the bushing in place, ensuring it is tightly
fitted.
For any further information or assistance, please refer to the
user manual or contact customer support.
PICTURE IS AN APPROXIMATE REPRESENTATION. NOT TO EXACT SCALE OR PROPORTION. ALL MEASUREMENTS IN INCHES. BUSHING DIAMETERS (TOP ROW) ARE OPTIMAL AND SHOULD VARY BY NO MORE THAN .002″ WHEN NEW.
ID NUMBER PKCP9000BU
NUMBER OF PARTS
2
TYPE: BUSHING
THRU HOLE STANDARD(0.248″)
NOTES: CAP AND TIP SAME MEASUREMENTS
PART NAME
()
()
()
()
()
()
() CAP/TIP (2) ()
()
()
()
()
()
()
AND
(QUANTITY)
SECTION NAME
BARREL
EXTENSION
DIAMETER 0.000″ 0.000″ 0.000″ 0.000″ 0.000″ 0.000″ 0.477″ 0.000″ 0.362″ 0.000″ 0.000″ 0.000″ 0.000″ 0.000″ 0.000″
LENGTH 0.000″ 0.000″ 0.000″ 0.000″ 0.000″ 0.000″ 0.386″ 0.000″ 0.250″ 0.000″ 0.000″ 0.000″ 0.000″ 0.000″ 0.000″
ASSOCIATED PKCP90(XX) KITS:
Last Published: Tuesday, May 9, 2023
