PKNICK-BU Crown Jewel Twist Pen Kit
Product Information
Product ID: PKNICK-BU
Number of Parts: 2
Type: Bushing
Thru Hole Standard: 0.248 inches
Notes: The tip and cap have the same dimensions
Section Names: Barrel, Extension
Product Usage Instructions
1. Ensure that the bushing is of the correct type and has a thru
hole standard of 0.248 inches.
2. Make sure that the bushing is new and that the bushing
diameters (top row) vary by no more than .002 inches.
3. Identify the correct section for installation, either the
barrel or the extension.
4. For each section, refer to the “Diameter” and “Length”
columns to determine the specific measurements for each part.
5. Install the bushing by placing it in the designated area
according to the associated section.
6. Repeat the installation process for each part, ensuring that
the dimensions match the specifications provided.
7. If using with PKRYL(XX) kits, refer to the associated kits
for additional instructions or compatibility information.
Last Published: Tuesday, May 9, 2023
PICTURE IS AN APPROXIMATE REPRESENTATION. NOT TO EXACT SCALE OR PROPORTION. ALL MEASUREMENTS IN INCHES. BUSHING DIAMETERS (TOP ROW) ARE OPTIMAL AND SHOULD VARY BY NO MORE THAN .002″ WHEN NEW.
ID NUMBER PKNICK-BU
NUMBER OF PARTS
2
TYPE: BUSHING
THRU HOLE STANDARD (0.248′)
NOTES: TIP AND CAP SAME DIMENSIONS
PART NAME
()
()
()
()
()
()
() CAP/TIP (2) ()
()
()
()
()
()
()
AND
(QUANTITY)
SECTION NAME
BARREL
EXTENSION
DIAMETER 0.000″ 0.000″ 0.000″ 0.000″ 0.000″ 0.000″ 0.420″ 0.000″ 0.310″ 0.000″ 0.000″ 0.000″ 0.000″ 0.000″ 0.000″
LENGTH 0.000″ 0.000″ 0.000″ 0.000″ 0.000″ 0.000″ 0.375″ 0.000″ 0.250″ 0.000″ 0.000″ 0.000″ 0.000″ 0.000″ 0.000″
ASSOCIATED PKRYL(XX) KITS:
Last Published: Tuesday, May 9, 2023
