ODCOUG-36SSL Courtyard Stainless Steel Liner Fireplace
Product Information:
The Courtyard Stainless Steel Liner is a kit designed for use
with specific Hearth & Home Technologies products. It is
compatible with the following models: ODCOUG-36NR, ODCOUG-36TS,
ODCOUG-42NR, and ODCOUG-42TS. The kit includes stainless steel
panels that are used to line the interior of the appliance.
Before beginning installation, it is important to check with
your local building code agency to ensure compliance with local
codes and regulations. This may include obtaining permits and
scheduling follow-up inspections. If you have any questions or
encounter any issues during installation, it is recommended to
contact your Hearth & Home Technologies dealer for
assistance.
Please note that some models may require the removal of a screen
panel, log assembly, or refractory before installing the stainless
steel liner kit.
Product Usage Instructions:
- Ensure that the appliance has cooled completely if it has been
in operation. - If installed, remove the grate, log set, media, and refractory
by following the specific instructions for each component. - Use a Phillips head screwdriver as the required tool for the
installation process. - To remove the rear refractory panel, first remove the Burner
Rear Cover by unscrewing the three screws securing it. Lift the
cover and set it aside. - Tilt the top edge of the rear refractory panel towards the
center of the appliance and lift it out. - Clean any debris left from the refractory panels using a shop
vac or small brush to ensure a flat surface for the stainless steel
panels to sit upon. - Remove the right and left side covers by unscrewing the two
screws securing each cover. Pull the side covers towards the center
of the appliance and remove them. - Remove the protective coating from the new stainless steel
panels. - Lift the rear stainless panel up and over the rear edge of the
burner assembly, placing it against the appliance’s rear wall.
Reinstall the Burner Rear Cover using the three screws that were
removed earlier. - Hold the rear stainless panel in place while installing the
Burner Rear Cover. - Repeat the process for installing the left stainless
panel. - Use a cleaner specifically designed for stainless steel. Apply
the cleaner to a terry cloth and wipe the appliance following the
grain of the stainless steel. Do not spray cleaner directly onto
the appliance. Remove any fingerprints present after
installation. - Reinstall the grate, log set, and media.
Installation Instructions
Courtyard Stainless Steel Liner Models: ODCOUG-36SSL, ODCOUG-42SSL
This kit has been tested for use with specific Hearth & Home Technologies products. Check with your local building code agency before you begin installation to ensure compliance with local codes, including the need for permits and follow-up inspections. If you encounter any problems regarding code approvals, or if you need clarification of any of the instructions contained here, contact your Hearth & Home Technologies dealer. For the dealer nearest you, please visit www.hearthnhome.com.
Model(s) ODCOUG-36NR ODCOUG-36TS ODCOUG-42NR ODCOUG-42TS
Kit ODCOUG-36SSL ODCOUG-42SSL
This Stainless Steel Liner kit is designed for use on the models shown in the chart above. Read these instructions thoroughly before beginning installation.
CAUTION: Allow appliance to cool completely if it has been in operation.
NOTE: Some models may require removal of a screen panel, log assembly or refractory before installation of the stainless liner kit.
KIT CONTENTS: · (1) Rear Stainless Steel Panel · (1) Left Stainless Steel Panel · (1) Right Stainless Steel Panel · (4) #8 x 1/2″ Screws
TOOL REQUIRED: Phillips head screwdriver
INSTRUCTIONS: Remove grate, Log Set, Media and Refractory: 1. Remove grate, log set and media, if installed. 2. Remove refractory, if installed, by removing brackets at
the top and bottom of each side panel. See Figure 1. Tilt refractory top edge towards the center of the appliance and lift out. Repeat on other side.
3. To remove rear refractory, it is necessary to remove the Burner Rear Cover. Remove (3) screws securing cover, lift cover to remove and set aside. See Figure 2.
Burner Rear Cover
Screws
Figure 2 4. To remove rear refractory panel, tilt top edge towards
the center of the appliance and lift out. 5. Use a shop vac or small brush to clean debris left from
refractory panels to ensure a flat surface for the stainless steel panels to sit upon. Remove Side Covers: 6. Remove screws (2) securing the right and left side covers. Pull side covers towards to the center of appliance and remove. See Figure 3. Note: Side covers will no longer be needed.
Top Bracket Bottom Bracket
Screws
Figure 1
Figure 3
Hearth & Home Technologies · Courtyard Stainless Steel Liner Kit Installation Manual · 4150-941 Rev. A · 02/23
7. Carefully remove protective coating from new stainless steel panels.
8. Lift rear stainless panel up and over the rear edge of the burner assembly, place panel against appliance rear wall. Reinstall Burner Rear Cover with (3) screws removed in Step 3. See Figure 4.
Note: Rear stainless panel is secured in place by the side panels and will need to be held in place while installing Burner Rear Cover.
10. Repeat for left stainless panel Installation. See Figure 6.
Rear Stainless Panel
Burner Rear Cover
Figure 4
Figure 6
11. Using cleaner designed for use on stainless steel. Apply cleaner to a terry cloth and wipe appliance following the grain of the stainless. Do not spray cleaner directly onto the appliance. Remove any fingerprints present after installation.
12. Reinstall grate, log set and media.
9. Position right stainless panel against firebox side and slide towards the rear of the firebox until side panel contacts the rear panel. Secure right side panel with (2)
screws provided. See Figure 5.
Right Stainless Panel
Screws
Figure 5
Please contact your Hearth & Home Technologies dealer with any questions or concerns. For the location of your nearest Hearth & Home Technologies dealer, please visit www.hearthnhome.com. Hearth & Home Technologies · Courtyard Stainless Steel Liner Kit Installation Manual · 4150-941 Rev. A · 02/23
