315553 Aries King Platform Bed
Product Information: B561-100 ARIES 6/6 EK PANEL
BED-HB/FB/RAILS
The B561-100 ARIES 6/6 EK PANEL BED-HB/FB/RAILS is a
high-quality product that comes with a headboard, footboard, side
rails, bed slats support, and center slats. The product has been
designed to provide perfect stability and support to the mattress,
ensuring a comfortable and peaceful sleep.
Parts List:
| No | ITEM | Qty | No | ITEM | Qty |
|---|---|---|---|---|---|
| A | Headboard | 1 pc | 1 | JCBC M6 x 30mm | 12 pcs |
| B | Footboard | 1 pc | 2 | JCBC M6 x 50mm | 8 pcs |
| C | Headboard Leg LSF | 1 pc | Flat Washer 1/4ID x 19mmOD Blk | 12 pcs | |
| D | Headboard Leg RSF | 1 pc | ALLEN KEY m4x65mm Blk (FOR HB LEG) | 4 pcs | |
| E | Bed Roll-Out Slats | 2 sets | ALLEN KEY m5x65mm Blk (FOR SIDE RAIL) | 1 pc | |
| F | Bed Slats Support | 8 pcs | Flat Head Chipboard Screw m4x32mm Rbw | 32 pcs | |
| G | Side Rail Left | 2 pcs | |||
| H | Side Rail Right | 2 pcs | |||
| I | Center Slat | 2 pcs | |||
| J | Side Rail Leg | 2 pcs |
Hardware List:
| No | ITEM | Qty |
|---|---|---|
| 1 | JCBC Bolt | 4 pcs |
| 2 | JCBC Bolt | 8 pcs |
| 3 | Flat Washer 1/4ID x 19mmOD Blk | 12 pcs |
| 4 | ALLEN KEY m4x65mm Blk (FOR HB LEG) | 1 pc |
| 5 | ALLEN KEY m5x65mm Blk (FOR SIDE RAIL) | 1 pc |
| 6 | Flat Head Chipboard Screw m4x32mm Rbw | 32 pcs |
Product Usage Instructions:
- Step 1.1: Attach Head Board Leg (C,D) to Head
Board (A) using Flat washer (3) and securing with ALLEN KEY
(4). - Step 1.2: Fix the other holes with Csk Screw
(6) as shown. - Step 2.1: Attach Side Rail (G) & (H) to
the Side Rail Leg (J) as shown using JCBC BOLT(1) with Flat washer
(3) and securing with ALLEN KEY (4) by outside side rail (G) &
(H). - Step 2.2: Loosen JCBB Bolt at Headboard &
Footboard Leg using Allen Key (5) (Do not tighten them before Hook
SET-UPSIDE RAIL TO HEAD BOARD (A) closely and push down to fit and
tighten them accordingly. Repeat step 2.2 with the other end of the
rail to hook onto FOOTBOARD (B). - Step 3: Fix the Bed Slat Support (F), to Bed
Slat (E) and Center slats (I) tighten with JCBC Bolt (2) as shown.
Install the bed slat (E) to side rail (G) & (H) and tighten
with Csk Screw (6) as per diagram shown. Repeat step 3 for the
other set of slats assembly.
Note: Must tighten screws periodically with use screw will
become loose check tightness of all screw every 6-8 weeks.
ASSEMBLY INSTRUCTIONS
B561-100 ARIES 6/6 EK PANEL BED-HB/FB/RAILS
Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts,
which may have come loose inside the carton during shipment. Identify and count all items and compare with
the parts list and/or hardware list shown.
PARTS LIST
HARDWARE LIST
No
ITEM
Qty No ITEM
Qty
A Headboard B Footboard C Headboard Leg LSF D Headboard Leg RSF E Bed Roll-Out Slats F Bed Slats Support G Side Rail Left
1 pc 1 pc 1 pc 1 pc 2 sets 8 pcs 2 pcs
1 JCBC M6 x 30mm 12 pcs
2 JCBC M6 x 50mm 8 pcs
Flat Washer 1/4″ID x
3
19mmOD Blk
12 pcs
ALLEN KEY
m4x65mm Blk
4
(FOR HB LEG)
1 pc
H Side Rail Right I Center Slat J Side Rail Leg
2 pcs 2 pcs 2 pcs
ALLEN KEY
m5x65mm Blk
5 (FOR SIDE RAIL)
1 pc
Flat Head Chipboard
6 Screw m4x32mm Rbw 32 pcs
STEP 1.1 : Attach Head Board Leg ( C,D ) to Head Board ( A ) as shown using Flat washer (3)and securing with ALLEN KEY ( 4 ) .
STEP 1.2 : Fix the other holes with Csk Screw (6) as shown.
JCBC BOLT( 1 ) with
A
C
4
LEFT
D
RIGHT
C
BACK VIEW
1
C
3
4x
6
8x
STEP 1.1 :
STEP 1.2 :
1 OF 2 NOTE : MUST TIGHTEN SCREWS PERIODCALLY WITH USE SCREW WILL BECOME LOOSE CHECK TIGHTNESS OF ALL SCREW EVERY 6-8 WEEKS.
STEP 2.1 : Attach Side Rail ( G ) & ( H ) to the Side Rail Leg ( J ) as shown using JCBC BOLT( 1 )with Flat washer (3)and securing with ALLEN KEY ( 4 ) by outside side rail (G) & (H) .
STEP 2.2 : Loosen JCBB Bolt at Headboard & Footboard Leg using Allen Key (5) (Do not tighten them before Hook SET-UPSIDE RAIL TO HEAD BOARD (A) closely and push down to fit and tighten them accordingly. Repeat step 2.2 with other end of rail to hook onto FOOTBOARD (B).
4
STEP 2.2 :
x8
1
STEP 2.1 : G
3 J
LOOSEN 5
H
TIGHTEN 5
A
Left Sticker G HJ
Right Sticker
L
ALIGN BEFORE TIGHTEN
R
J
GH
FRONT VIEW J
SIDE VIEW
DO NOT FULLY TIGHTEN SCREW IN THIS STEP BEFORE ALIGN THE SIDE RAIL AS SHOWN.
H
B
G
STEP 3 : Fix the Bed Slat Support (F ), to Bed Slat (E) and Center slats (I) tighten with JCBC Bolt (2) as shown . Install the bed slat ( E ) to side rail ( G ) & ( H ) and tighten with Csk Screw ( 6 ) as per diagram shown. (NOTE: THE SETUP MUST DONE AT THE DECIDED LOCATION FOR THE BED TO OBTAIN PERFECT STABILITY) Repeat step 3 for other set of slats assembly.
4 2
E
STEP 3.1 :
I
E
I
STEP 3.4 :
Push the side rail(G)&(H) meet with wooden slat(E) and fix the CSK Screw(6) by using the Screw Driver.
F B
STEP 3.2 : 6
G
STEP 3.5 :
6
E
H
STEP 3.3 :
REMARK: Push Slat (E) to the end of side rail and secure with CSK Screw(6) as shown.
F Leveler
2 OF 2
NOTE : MUST TIGHTEN SCREWS PERIODCALLY WITH USE SCREW WILL BECOME LOOSE CHECK TIGHTNESS OF ALL SCREW EVERY 6-8 WEEKS.
