S-PPS-300 Air Portable Power Station
Product Information
Product Name: S-PPS-300Air
Basic Info:
- Battery Energy: . WH
- Battery Cell Energy: 18Ah/12.8V
- Battery Material: Lithium Iron Phosphate
- Battery Cell Quantity: 6000mAh* pcs
- Battery Combination Mode: S P
- Size: 268*110*185mm
- Weight: . KG
- Accessory: 20V-3A Constant-voltage and constant-current
DC adapter - Set Weight: . KG
- Color: Grey
- Material: Flame Retardant ABS Resin + PC
- Inner Box Size: 310x155x240mm
- Out Box Size: 335*330*515mm
- Package: One unit per box
Input Info:
- AC Input: AC~220V/50Hz 0.5A Max
- Input DC: 12V~24/1A~5A(max 60W) Solar panel
supported - Typc-C Input: DC 5V3A/9V3A/12V3A/15V3A/20V3.25A
Output Info:
- Inverter Output: AC 220V-50Hz 400W(Max) sine wave
- Total Output: DC OUT total output
- Type-C Output: DC 5V3A/9V2A/12V1.5A
- USB-A1/A2 Output: DC 5V3A/9V2A/12V1.5A
- Remote Spot Lamp Output: 3W
Battery Info:
- Battery Material: 32700 Lithium Iron Phosphate
- Battery Cell Quantity: 6000mAh*12 pcs
- Battery Combination Mode: 4S3P
- Cycle Life: 1500 times 80%
- Protection: High-temp cut-off, low-temp protection,
over-discharge protection, overload protection, short-circuit
protection, overcurrent protection
Operating Environment:
- Optimum Service Temperature: 20~30°C
- Discharge Temperature: -10~40°C
- Charging Temperature: 0~40°C
- Storage Temperature: 0~40°C (Optimum 20~30°C)
FOB Price:
- Sample: $
- 100-300 Units: $
- 300-500 Units: $
- Above 500 Units: $
Product Usage Instructions
To use the S-PPS-300Air product, please follow these
instructions:
- Connect the AC input to an AC power source with a voltage of
AC~220V/50Hz and a maximum current of 0.5A. - For DC input, use a 12V~24V power source with a current range
of 1A~5A (maximum 60W). You can also connect a solar panel for
power support. - Use the Type-C input for DC input, with voltage and current
options of DC 5V3A/9V3A/12V3A/15V3A/20V3.25A. - The inverter output provides AC power at 220V-50Hz with a
maximum power of 400W (sine wave). - The total output includes DC OUT total output, Type-C output,
USB-A1/A2 output, and Remote Spot Lamp output. Please refer to the
product information for specific voltage and current values. - Make sure to charge the battery before use. Connect the
included 20V-3A Constant-voltage and constant-current DC adapter to
the product for charging. - The product can be used with various devices. Refer to the
“Using time of different devices” section in the manual to
determine the expected usage time for specific devices. - Ensure that the operating environment is within the recommended
temperature range. The optimum service temperature is 20~30°C,
while the discharge and charging temperatures should be between
-10~40°C. The storage temperature should also be within 0~40°C
(optimum 20~30°C). - Take necessary precautions to protect the battery. The product
includes protection features such as high-temp cut-off, low-temp
protection, over-discharge protection, overload protection,
short-circuit protection, and overcurrent protection.
S-PPS-300Air
Basic info
Battery energy
. WH
Battery cell energy
18Ah/12.8V
Battery material
lithium iron phosphate
Battery cell quantity 6000mah* pcs
Battery combination mode S P
Size
268*110*185mm
Weight
. KG
Accessory
20V-3A Constant-voltage and constant-current DC adapter
Set weight
. KG
Color
grey
Material
flame retardant ABS resin +PC
Inner box size
310x155x240mm
Out box size
335*330*515mm
Package
one unit per box
Input info
AC input
AC~220V/50Hz 0.5A Max
Input DC
12V~24/1A~5A(max 60W) Solar panel supported
Typc-C inpu
DC 5V3A/9V3A/12V3A/15V3A/20V3.25A
Inverter output Total output DC OUT total output Type-C output USB-A1/A2 output Remote spot lamp
Output info
AC 220V-50Hz 400W(Max) sine wave 5V4A (USB-1+USB-2) DC 12V6ADC-1+DC-2) DC 5V3A/9V3A/12V3A/15V3A/20V3.25A DC 5V3A/9V2A/12V1.5A 3W
Using time of different devices
Iphone
.h
Drone
40W
h
DSLR camera
10W
h
Laptop
40W
h
Switch controller
.h
iPad Pro
h
Projector
100W
h
Electric fan
30W
.h
Car refrigerator
60W
h
Led light
h
Battery info
Battery material
32700lithium iron phosphate
Battery cell quantity
6000mah*12 pcs
Battery combination mode 4S3P
Cycle life
1500 times80%
Protection
high-temp cut-off, low-temp protection, over-discharge protection, overload protection,short-circuit protection, overcurrent protection
Operating environment
Optimum service temperature 20~30
Discharge temperature -10~40
Charging temperature Storage temperature
0~40
0~40 (optimum 20~30)
FOB price
Sample: 100-300 units: 300-500 units: Above 500 units:
