Instruction Manual
UNIVERSAL DIMMER
OPERATING INSTRUCTIONS
Important! Read the user instructions carefully before use. Save them for future reference.
(Translation of the original instructions).
Care for the environment!
Recycle discarded products in accordance with local regulations.
Jula reserves the right to make changes. For the latest version of operating instructions, see www.jula.com
SAFETY INSTRUCTIONS
WARNING!
New installations and extensions to existing systems should always be carried out by an authorized electrician. If you have the necessary experience and knowledge (otherwise contact an electrician), you can replace power switches and wall sockets, fit plugs, extension cords, and light sockets. Incorrect installation can result in fatal injury and the risk of fire.
TECHNICAL DATA
Rated voltage: 230 V – SO Hz
Output
Incandescent bulbs/Halogen bulbs: 30-200 W
Low voltage halogen with an electronic transformer: 30-200 W
Compatible LEDs 3-24 W
INSTALLATION
WARNING!
Disconnect the power supply before electrical installation.
- Connect the wires to the dimmer according to the wiring diagram. The maximum size of the wire is 2.5 mm2.
- Fit the dimmer in the conduit box.
HOW TO USE
- Switch the light on and off by pressing the dimmer dial.
- Turn the dimmer dial to increase or reduce the brightness.
- When the light source is switched on the next time it has the same brightness as when it was switched off.
JULA AB, BOX 363, SE-532 24 SKARA
2021-12-10
© Jula AB
015579 – 015580
