MT MX 90.3 Aquariums Mesh Lid System
Product Information: Mesh Lid Assembly Manual MT MX/MDX
90.3/110.4
The Mesh Lid Assembly is designed to provide a protective cover
for your MT MX/MDX 90.3/110.4 product. It comes with a clear mesh
netting and LED light mount cutout for added convenience and
functionality. The package includes various parts such as frame
corners, hanging clips, mesh spline, frame inner corners, and a
ruler.
The product is available in two sizes:
- MT MX/MDX 90.3: Frame dimensions – 13.5(343.2mm)*2,
15.3(387.5mm)*2, 16.7(423mm)*2; LED light mount cutout –
2.1(53mm)*2; Mesh spline – 2.9(73mm)*2; Frame inner corners –
1.6(40.7mm)*2 - MT MX/MDX 110.4: Frame dimensions – 13.5(343.2mm)*2,
21.2(537.5mm)*2, 16.7(423mm)*2; LED light mount cutout –
2.1(53mm)*2; Mesh spline – 7.6(193mm)*2; Frame inner corners –
2.8(70.5mm)*2
Product Usage Instructions
- Identify the left and right parts of the assembly.
- Assemble the frame corners with the frame inner corners using
the ruler for measurement. - Attach the hanging clips to the frame corners for hanging
purposes. - Insert the clear mesh netting into the frame and secure it with
the mesh spline. - Attach the LED light mount cutout to the desired location.
- Your Mesh Lid Assembly is now ready to use. Cover your MT
MX/MDX 90.3/110.4 product with the assembly for added
protection.
Mesh Lid Assembly Manual MT MX/MDX 90.3/110.4
Left
Right
1
A
B
C
D
E
H
L
F
G
I
M J
K
A B C D E F G
CODE
PART
Qty
A
Aluminum Frame A
2
B
Aluminum Frame B
2
C
Aluminum Frame C
2
D
Aluminum Frame D
2
E
Aluminum Frame E
2
F
Aluminum Frame F
2
G
Aluminum Frame G
2
H
LED Light Mount Cutout
2
I
Frame Corners
10
J
Hanging Clips
12
K
Clear Mesh Netting
2
L
Mesh Spline
2
M
Frame Inner Corners
2
MT MX/MDX 90.3 13.5″(343.2mm)*2 15.3″(387.5mm)*2 16.7″(423mm)*2
2.1″(53mm)*2 4.1″(105mm)*2 2.9″(73mm)*2 1.6″(40.7mm)*2
MT MX/MDX 110.4 13.5″(343.2mm)*2 21.2″(537.5mm)*2 16.7″(423mm)*2
2.1″(53mm)*2 4.1″(105mm)*2 7.6″(193mm)*2 2.8″(70.5mm)*2
2
Left
J
J
Right
J
J
H
DG
F
E
M
J
H
F
GD
J
M
E
A
C
C
A
J
J
I
B J
J
I
B
J
J
Mesh Lid Assembly Manual MT MX/MDX 90.3/110.4
3
K&L
Ruler
4
