2531-695 Spyglass Terrace

Product Information

This product is a light fixture with a chain loop designed for
indoor use. It comes with a mounting plate, canopy, rod, support
cable, loop, quick link, and screws for installation. The fixture
can accommodate one medium base bulb up to 60 watts or CFL/LED
equivalent.

Product Usage Instructions

Before installation, shut off power at the fuse box or circuit
breaker box and remove the old fixture including the mounting
hardware.
Unpack the new fixture carefully and lay out all the parts in a
clean area, taking care not to misplace any small parts necessary
for installation.
Secure rod (J) onto all thread (I) on the fixture body.
Determine the desired hanging height and thread rods (F1, F2,
and F3) to all thread on rod (J). Screw loop (H1) to rod (F1). Pass
the wires carefully through each rod as you assemble.
Attach quick link (G) to loop (H1) and loop (H2) on canopy (D).
Carefully feed the wire through loop (H1), quick link (G), and loop
(H2).
Attach mounting plate (A) to the junction box with mounting
screws (B). The side of the mounting plate (A) with GND marked on
it and two convex points must face out.
Align the fixture to mounting plate (A) and attach hook (P) on
the end of support cable (C) and a slot located on mounting plate
(A). Carefully allow the support cable (C) to support the weight of
the fixture while wiring.
Connect the electrical wires as shown in fig 2, making sure
that all wire connectors are secured. If your junction box has a
ground wire (green or bare copper), connect the fixture’s ground
wire to it. Otherwise, connect the fixture’s ground wire directly
to the mounting plate (A) using the green screw provided.
Tuck the wire connectors neatly into the junction box.
Slide canopy (D) over mounting plate (A) and secure with screws
(E).
Install one medium base bulb (K) up to 60 watts each or CFL or
LED equivalent (not included) in accordance with the fixture
specification–DO NOT EXCEED THE MAXIMUM WATTAGE RATING!
Your installation is now complete. Return power to the junction
box and test the fixture.

View Fullscreen

INSTALLATION INSTRUCTIONS

Item#2531-695 (New. 2022/04/29) READ AND SAVE THESE INSTRUCTIONS
W AR NI N G ! S HU T P O WE R O F F AT F U S E O R CI R C UI T B R E AK E R .

AVERTISSEMENT! COUPER LE COURANT AU NIVEAU DES FUSIBLES OU DU DISJONCTEUR.

PREPARATION (Fig. 1)
1. Shut of power at the fuse box or circuit breaker box and remove
the old fixture including the mounting hardware.
2. Carefully unpack your new fixture and lay out all the parts in a
clean area. Take care not to misplace any small parts necessary
for installation.
ASSEMBLING THE FIXTURE WITH CHAIN LOOP (Fig.1&Fig. 3)
3. Secure rod (J) onto all thread (I) on the fixture body. 4. Determine the desired hanging height and thread rods (F1, F2
and F3) to all thread on rod (J). Screw loop (H1) to rod (F1).
Pass the wires carefully through each rod as you assemble.
5. Attach quick link (G) to loop (H1) and loop (H2) on canopy (D).
Carefully feed the wire through loop (H1), quick link (G), and loop
(H2).
6. Attach mounting plate (A) to the junction box (not included) with
mounting screws (B) (Size: #8-32N*L0.5″). The side of the
mounting plate (A) with “GND” marked on it and two convex
points must face out.
7. The support cable is provided to support the weight of the fixture
while wiring. Align the fixture to mounting plate (A) and attach
hook (P) on the end of support cable (C) and a slot located on
mounting plate (A). Carefully allow the support cable (C) to
support the weight of the fixture while wiring.
CONNECTING THE WIRES (Fig. 2)
8. Connect the electrical wires as shown in fig 2, making sure that
all wire connectors are secured. If your junction box has a
ground wire (green or bare copper), connect the fixture’s ground
wire to it. Otherwise, connect the fixture’s ground wire directly to
the mounting plate (A) using the green screw provided.
9. Tuck the wire connectors neatly into the junction box..
COMPLETING THE INSTALLATION (Fig. 1)
10. Slide canopy (D) over mounting plate (A) and secure with screws
(E).
11. Install (1) one medium base bulb (K) up to 60 watts each or CFL
or LED equivalent (not included) in accordance with the fixture
specification–DO NOT EXCEED THE MAXIMUM WATTAGE RATING! (NE PAS DEPASSER LA PUISSANCE NOMINALE MAXIMALE!).

Fig. 1 Set#A-021-118DH – Mounting plate -Ground screw -Mounting screw*2
H2 H1 F1 F2 F3
J I
K

P A B C D E G
Rod# W30-1-695*1(F1) W30-1-695*2(F2) W30-H-695*1(F3)

Your installation is now complete. Return power to the junction box and test the fixture.
Note: Illustration (Fig. 1) on this manual is for installation purposes only. It may or may not be identical to the fixture purchased.

Fig. 2 FIXTURE WIRES Black or Smooth

FIXTURE WIRES White or Ribbed

FIXTURE WIRES Bare Copper (Ground)

Page: 1/2

HOUSE WIRES Black (Hot)

HOUSE WIRES White (Neutral)

HOUSE WIRES Green (Ground)

LA-3553E

Fig.3

A B
D E H2 G H1
F1

a. Hardware Bag:

A. Mounting Plate *1 B. Mounting Screw*2
