Hager Keb733n1 Tap-off Box Instruction Manual

KEB733N1 Tap-Off Box

Product Information

Product Model: KEB733N1, KEB733P1

Type Label Specifications:

  • Rated Operating Voltage (Ue): 1
  • Rated Frequency Range (fn): 2
  • Conditional Rated Short-Circuit Current (Icc): 3
  • Size, Tap-off Box (ISize): 4
  • Rated Current (Inc): 5
  • Max. Rated Current of the Fuse-Link (Imax): 6

Safety Information:

Electrical devices may only be installed and assembled by a
qualified electrician in accordance with the relevant installation
standards, guidelines, regulations, directives, safety and accident
prevention regulations of the country. Always comply with the
warning information on the device! Failure to comply with these
installation instructions may result in damage to the device, fire
or other hazards. These instructions are an integral component of
the product and must be retained by the end user.

Product Usage Instructions

  1. Ensure that the installation is carried out by a qualified
    electrician who follows all relevant installation standards and
    regulations.
  2. Before starting the installation, carefully read and comply
    with the safety information provided on the device.
  3. Refer to the type label specifications for the rated operating
    voltage, frequency range, short-circuit current, tap-off box size,
    rated current, and max rated current of the fuse-link.
  4. Use the appropriate tools, such as a Phillips screwdriver
    (PH3), flathead screwdriver (5 mm PZ2), and wrench (SW10), as
    indicated in the instructions.
  5. Follow the provided diagrams and instructions for the correct
    wiring connections. Pay attention to the PEN and PE connections
    depending on the type of electrical system (TN-C-S, TN-S).
  6. Tighten the screws and connections according to the specified
    torque values (3.5 Nm for SW10 screws, 8 Nm for SW10 nuts).
  7. Ensure all connections are secure and properly insulated to
    prevent electrical shocks.
  8. Once the installation is complete, test the device to ensure it
    is functioning correctly.
  9. Keep the user manual and instructions for future reference and
    troubleshooting.

6LE008170A 8PS5980-0AA01-6AA5.00

e Montageanleitung z Assembly instructions i Montagehandleiding s Monteringsanvisning m Instrukcja montau

KEB733N1, KEB733P1
e Abgangskasten Größe 2/ 3 z Tap-off box, size 2/ 3 i Aftakkast grootte 2/ 3 s Uttagslåda storlek 2/ 3 m Skrzynka odplywowa rozmiar 2/ 3

z Safety Information!
Electrical devices may only be installed and assembled by a qualified electrician in accordance with the relevant installation standards, guidelines, regulations, directives, safety and accident prevention regulations of the country.
Always comply with the warning information on the device!
Failure to comply with these installation instructions may result in damage to the device, fire or other hazards.
These instructions are an integral component of the product and must be retained by the end user.

-25°C

+55°C +70°C (< 24 h)

IEC / EN 61439-1 IEC / EN 61439-6

DANGER! Electric shock when live parts are touched! An electric shock can lead to death!
· Isolate all connection cables before working on the device and cover any live parts in the area!

Details on the type label
Main circuit:
1 Ue Rated operating voltage 2 fn Rated frequency range 3 Icc Conditional rated short-circuit current 4 ISize Size, tap-off box 5 Inc Rated current (for MCCB: Value of the overload trigger) 6 Imax Max. rated current of the fuse-link

e Sicherheitshinweis!

i Veiligheidsinstructie!

Einbau und Montage elektrischer Geräte dürfen nur durch eine Elektrofachkraft gemäß den einschlägigen Installationsnormen, Richtlinien, Bestimmungen, Sicherheits- und Unfallverhütungsvorschriften des Landes erfolgen. Warnhinweise auf dem Gerät sind unbedingt zu beachten! Bei Nichtbeachten der Installationshinweise können Schäden am Gerät, Brand oder andere Gefahren entstehen. Diese Anleitung ist Bestandteil des Produktes und muss beim Endkunden verbleiben.
GEFAHR! Elektrischer Schlag bei Berühren spannungsführender Teile! Elektrischer Schlag kann zum Tod führen!
· Vor Arbeiten am Gerät Anschlussleitungen freischalten und spannungsführende Teile in der Umgebung abdecken!
Angaben auf dem Typenschild Hauptstromkreis: 1 Ue Bemessungsbetriebsspannung 2 fn Bemessungsfrequenzbereich 3 Icc Bedingter Bemessungskurzschlussstrom 4 ISize Baugröße Abgangskasten 5 Inc Bemessungsstrom (bei MCCB: Wert des Überlastauslösers) 6 Imax Max. Bemessungsstrom der Sicherung

Inbouw en montage van elektrische apparatuur mag alleen door een installateur worden uitgevoerd conform de geldende installatienormen, richtlijnen, voorschriften, bepalingen en ongevallenpreventievoorschriften van het betreffende land.
De waarschuwingen op het apparaat moeten absoluut worden aangehouden!
Bij het niet naleven van de installatie-instructies kan schade aan het apparaat, brand of andere gevaren optreden.
Deze handleiding maakt deel uit van het product en dient in het bezit van de eindgebruiker te blijven.
GEVAAR!
Gevaar voor elektrische schok bij aanraking van spanningvoerende delen!
Elektrische schokken kunnen de dood tot gevolg hebben!
· Voorafgaand aan werkzaamheden aan het apparaat de aansluitleidingen loskoppelen en spanningvoerende delen in de omgeving afdekken!
Specificaties op de typeplaat
Hoofdstroomcircuit: 1 Ue Nominale bedrijfsspanning 2 fn Nominaal frequentiebereik 3 Icc Nominale begrensde kortsluitstroom 4 ISize Grootte aftakkast 5 Inc Nominale stroom (bij MCCB: waarde van de overbelastingsbeveiliging) 6 Imax Max. nominale stroom van de zekering

01

22-1012_MOA_unibar_M_6LE008170A.indd 1

07.02.23 07:41

s Säkerhetsanvisningar!

m Wskazówka bezpieczestwa!

Inbyggnad och montering av elektriska enheter får endast utföras Zabudowy i montau urzdze elektrycznych moe dokona tylko

av en behörig elektriker i enlighet med de gällande nationella in- wykwalifikowany instalator zgodnie z wlaciwymi dla danego kra-

stallationsnormerna, riktlinjerna, bestämmelserna, säkerhets- och ju normami dot. instalacji, dyrektywami, warunkami i przepisami

olycksfallsförebyggande föreskrifterna.

BHP.

Varningar på enheten måste ovillkorligen följas! Kan medföra allvarliga kroppsskador, eldsvåda eller materiella skador. Läs och följ hela bruksanvisningen. Denna anvisning betraktas som en produktkomponent och ska lämnas kvar hos slutkunden.
FARA!

Bezwzgldnie przestrzega wskazówek ostrzegawczych na urzdzeniu!
Nieprzestrzeganie wskazówek dotyczcych instalacji moe doprowadzi do uszkodzenia urzdzenia, poaru lub innych niebezpieczestw.
Niniejsza instrukcja jest czci skladow produktu i musi pozosta u klienta.

Elektrisk stöt vid beröring av spänningsförande delar! Elektrisk stöt kan leda till döden!
· Koppla från anslutningsledningar och täck över spänningsförande delar i omgivningen före arbeten på enheten!
Uppgifter på märkskylten

NIEBEZPIECZESTWO! Niebezpieczestwo poraenia prdem przy dotkniciu elementów znajdujcych si pod napiciem! Poraenie prdem grozi mierci!
· Przed rozpoczciem prac przy urzdzeniu naley odlczy przewody podlczajce od sieci, a take osloni

Huvudkrets:

ssiednie elementy znajdujce si pod napiciem!

1 Ue Nominell driftspänning 2 fn Nominellt frekvensområde 3 Icc Villkorlig nominell kortslutningsström 4 ISize Storlek uttagslåda 5 Inc Märkström (vid MCCB: värde för överlastutlösaren) 6 Imax. Max. märkström för säkringen

Dane na tabliczce znamionowej
Obwód glówny:
1 Ue Napicie znamionowe pracy 2 fn Zakres czstotliwoci znamionowej 3 Icc Prd znamionowy zwarciowy umowny 4 ISize Rozmiar skrzynki odplywowej 5 Inc Prd znamionowy

(w przypadku MCCB: warto wyzwalacza przecieniowego)

6 Imax Maks. prd znamionowy wkladki bezpiecznikowej

1 x

6 x

02 22-1012_MOA_unibar_M_6LE008170A.indd 2

10 mm 1 x 5 mm PZ2
07.02.23 07:41

01
SW10

SW10

02

03

C

B A

04
B
A F
5 x PH3

D
C
2 x SW10
E

PH3
3,5 Nm

SW10
8 Nm

TN-C-S PEN

L1 L2 L3 N PE

L1 L2 L3 N L1 L2 L3 PEN
L1 L2 L3 N PE

TN-S

L1 L2 L3 N PE

L1 L2 L3 N L1 L2 L3 N PE

03 22-1012_MOA_unibar_M_6LE008170A.indd 3

Hager Electro GmbH & Co. KG, Zum Gunterstal, 66440 Blieskastel, Germany 07.02.23 07:41

01

A

B

A

A

02

B

A

2 x SW10

C A D
03

A
A
B
2 x SW10
A

SW10
8 Nm
SW10
8 Nm

04 22-1012_MOA_unibar_M_6LE008170A.indd 4

5 x SW10

T +49 6842 945 0 F +49 6842 945 4625 [email protected] hager.com – 03.2023 07.02.23 07:41
