Pro Large Valve Indoor/ Outdoor 3″ to 4″
Ordering Guide
For an indoor or outdoor system with 3″ or 4″ main water line:
| CHOOSE | DESCRIPTION |
| WCEH…Series | 110VAC Industrial Actuator with Valve (See Table 1 below for sizing) |
| WPC/WPCH | WaterCop PRO Control Panel (attached 20′ power cord, 12VDC output; WPCH has HW sensor terminals) |
| RK110VAC | Relay Kit |
| WPM or WPM.XT | Choose Number and Type of Wireless Sensor Hubs; with or without ambient temperature sensing |
| WPSC and Accessories | Choose # of WPSC probes and/ or other options from PRO “Accessories” Section of Price List |
*For outdoor installation extend wires to actuator with 18 gauge outdoor-rated wire and keep RK110VAC indoors with the Control Panel
Table 1
| PART # | DESCRIPTION |
| WCEHH2AATE07 | 3″ Lead Free Brass Valve with 110VAC Industrial Actuator |
| WCEHH2BATE01 | 4″ Lead Free Brass Valve with 110VAC Industrial Actuator |
* This application requires jumpers between terminals 2 & 4 and 3 & 5 for valve feedback.
* See “Supplemental Wiring Guide” (Part # 192458) to control ancillary devices such as well pumps, recirculating pumps, second WaterCop Valve, etc.
The proven leader in household leak protection: WaterCop® is there when you’re not.
