INSTALLATION INSTRUCTIONS
S6000G
ELECTRIC DOGGING
ELECTRICAL DATA
.225 Amps @ 24 VDC
Dogging Black wires
Non-Polarized
PATENT PENDING
When energized by a key switch or a remote maintain the switch and manually depress the push pad this will cause the push pad to remain retracted (unlocked) providing a push-pull door operation. When de-energized the push pad and latch are released.
Any suggestions or comments to this instruction or product are welcome. Please contact us through our website or email [email protected]
