Stryker 6385 Power-pro Tl Cot Fastener User Manual

6385 Power-Pro TL Cot Fastener

Power-PRO^TM TL Cot Fastener

The Power-PRO^TM TL Cot Fastener is a product
manufactured by Stryker. It is designed to securely fasten the cot
and ensure its proper function. This maintenance manual provides
instructions and guidelines for servicing the cot fastener.

Warning/Caution/Note Definition

The terms WARNING, CAUTION, and NOTE have specific meanings in
this manual and should be carefully reviewed:

• WARNING: Indicates a potential hazard or
  dangerous situation that can result in serious injury or
  death.
• CAUTION: Highlights precautions that should be
  taken to avoid damage to the cot fastener or other equipment.
• NOTE: Provides special information to make
  maintenance easier or important instructions clearer.

Introduction for Service

This manual serves as a guide for servicing the
Power-PRO^TM TL Cot Fastener. It does not cover the
operation of the product. For operating and usage instructions,
refer to the Operations Manual. The Operations Manual can be
accessed online at https://techweb.stryker.com/.

Expected Service Life

The cot fasteners have an expected service life of seven years
under normal use conditions and with appropriate periodic
maintenance.

Contact Information

If you have any questions or need assistance, please contact
Stryker Customer Service or Technical Support at 1-800-327-0770.
You can also reach out to them in writing at Stryker Medical, 3800
E. Centre Avenue, Portage, MI 49002, USA.

Note: In case of any serious product-related incident, both the
manufacturer and the Competent authority of the European Member
State where the user and/or patient is established should be
notified. To access the operations or maintenance manual online,
visit https://techweb.stryker.com/. Please have the serial
number (A) of your Stryker product available when contacting
Stryker Customer Service or Technical Support. Include the serial
number in all written communication.

Serial Number Location

The serial number (A) of the Stryker product can be found at a
specific location on the cot fastener assembly.

Preventive Maintenance

Regular inspection and adjustments are essential for maintaining
the cot fastener’s performance. The following maintenance schedule
provides a general guideline:

If you are unsure about performing these checks or need further
assistance, contact your Stryker Service Technician. Consult your
Stryker Service Technician to determine the appropriate maintenance
intervals for your product based on factors such as weather,
terrain, geographical location, and individual usage. Replace worn
parts as necessary.

Maintenance Record

The maintenance record section allows you to document the date,
maintenance operation performed, and the person responsible for the
maintenance.

Training Record

In the training record section, you can record the trainee’s
name, training date, and details of the training received, such as
basic training or refresher updates.

Model 6385 Cot Fastener Assembly

The model 6385 cot fastener assembly consists of various
components listed below:

Power-PROTM TL Cot Fastener
Maintenance Manual
6385 6386 6387 6388 6389

EN

6385-009-002 Rev AA.0

2022-11

Table of Contents
Warning/Caution/Note Definition ………………………………………………………………………………………………………………2 Introduction for service ……………………………………………………………………………………………………………………………3
Expected service life ……………………………………………………………………………………………………………………………..3 Contact information ……………………………………………………………………………………………………………………………….3 Serial number location……………………………………………………………………………………………………………………………3 Preventive maintenance ………………………………………………………………………………………………………………………….4 Maintenance record ………………………………………………………………………………………………………………………………..5 Training record……………………………………………………………………………………………………………………………………….6 Model 6385 cot fastener assembly……………………………………………………………………………………………………………7 Model 6386 cot fastener assembly……………………………………………………………………………………………………………8 Model 6387 cot fastener assembly……………………………………………………………………………………………………………9 Model 6388 cot fastener assembly………………………………………………………………………………………………………….10 Model 6389 cot fastener assembly………………………………………………………………………………………………………….11 Foot end fastener assembly …………………………………………………………………………………………………………………..12

6385-009-002 Rev AA.0

1 EN

Warning/Caution/Note Definition
The words WARNING, CAUTION, and NOTE carry special meanings and should be carefully reviewed.
WARNING Alerts the reader about a situation which, if not avoided, could result in death or serious injury. It may also describe potential serious adverse reactions and safety hazards. CAUTION Alerts the reader of a potentially hazardous situation which, if not avoided, may result in minor or moderate injury to the user or patient or damage to the product or other property. This includes special care necessary for the safe and effective use of the device and the care necessary to avoid damage to a device that may occur as a result of use or misuse.
Note – Provides special information to make maintenance easier or important instructions clearer.

EN 2

6385-009-002 Rev AA.0

Introduction for service
This manual assists you with the service of your Stryker product. Read this manual to service this product. This manual does not address the operation of this product. See the Operations Manual for operating and use instructions. To view your Operations Manual online, see https://techweb.stryker.com/.
Expected service life
Cot fasteners have a seven year expected service life under normal use conditions and with appropriate periodic maintenance.
Contact information
Contact Stryker Customer Service or Technical Support at: 1-800-327-0770. Stryker Medical 3800 E. Centre Avenue Portage, MI 49002 USA
Note – The user and/or the patient should report any serious product-related incident to both the manufacturer and the Competent authority of the European Member State where the user and/or patient is established. To view your operations or maintenance manual online, see https://techweb.stryker.com/. Have the serial number (A) of your Stryker product available when calling Stryker Customer Service or Technical Support. Include the serial number in all written communication.
Serial number location
A

6385-009-002 Rev AA.0

3 EN

Preventive maintenance
Fastener lubrication Note · Tri-FlowTM with Teflon® lubricant may be used to reduce the force required to secure and release the cot, minimize
wear, or if the pedal does not stay down with the cot removed. · Do not use silicone, WD-40®, or lithium grease. They could harm the moving parts of the cot fastener system. To lubricate the fastener: 1. Remove the back fastener cover. 2. Spray Tri-FlowTM with Teflon® lubricant (6082-199-012) onto the area indicated below (A) (Figure 1).
A

Figure 1 ­ Fastener lubrication
Regular inspection and adjustments
The following schedule is a general guide to maintenance. Factors such as weather, terrain, geographical location, and individual usage will alter the required maintenance schedule. If you are unsure how to perform these checks, contact your Stryker Service Technician. If you are in doubt as to what intervals to follow in maintaining your product, consult your Stryker Service Technician. Check each routine and replace worn parts if necessary.

Routine
Cot and cot fastener fit and function All fasteners are secure Lubricate the lock (see Fastener lubrication above)

Every 1 month
As needed

3 months X

6 months

12 months X

EN 4

6385-009-002 Rev AA.0

Maintenance record

Date

Maintenance operation

By

performed

Hours

6385-009-002 Rev AA.0

5 EN

Training record

Trainee name

Training date Basic training

Refresher update

Owner’s manual, inservice, formal class, etc.

EN 6

6385-009-002 Rev AA.0

Model 6385 cot fastener assembly
6385-001-010 Rev AA (Reference only)

Item A B C D E F G H J K L

Number 0003-109-000 0003-112-000 0012-058-001 6360-030-012 6385-001-012 6385-001-013 6385-001-080 6385-001-100 6385-001-926 0025-079-000 639000010901

Name Hex head cap screw Hex head cap screw Lock washer Floor plate, small Foot end fastener assembly (page 12) Antler assembly Back cover Label, specification Label, DPM Dome head rivet Label, EAR

Quantity 2 7 7 7 1 1 1 1 1 2 1

6385-009-002 Rev AA.0

7 EN

Model 6386 cot fastener assembly
6386-001-010 Rev AA (Reference only)

Item A B C D E F G H J K L M

Torque items A and D to 30 ± 5 ft-lb

Number 0001-184-000 0003-109-000 0011-014-000 0016-401-000 6385-001-012 6385-001-013 6385-001-080 6386-001-926 6385-001-106 6385-001-100 0025-079-000 639000010901

Name Flat head socket screw Hex head cap screw Flat washer Nylock hex nut Foot end fastener assembly (page 12) Antler assembly Back cover Label, DPM Lock down base plate Label, specification Dome head rivet Label, EAR

Quantity 7 2 7 7 1 1 1 1 2 1 2 1

EN 8

6385-009-002 Rev AA.0

Model 6387 cot fastener assembly
6387-001-010 Rev AA (Reference only)

Item A B C D E F G H J K L M

Torque items A and D to 30 ± 5 ft-lb

Number 0001-184-000 0003-109-000 0011-014-000 0016-401-000 6385-001-012 6385-001-013 6385-001-080 6387-001-926 6385-001-107 6385-001-100 0025-079-000 639000010901

Name Flat head socket screw Hex head cap screw Flat washer Nylock hex nut Foot end fastener assembly (page 12) Antler assembly Back cover Label, DPM Lock down base plate Label, specification Dome head rivet Label, EAR

Quantity 7 2 7 7 1 1 1 1 2 1 2 1

6385-009-002 Rev AA.0

9 EN

Model 6388 cot fastener assembly
6388-001-010 Rev AA (Reference only)

Item A B C D E F G H J K L M N

Torque items A and D to 30 ± 5 ft-lb

Number 0001-184-000 0003-109-000 0011-014-000 0016-401-000 6385-001-012 6385-001-013 6385-001-080 6385-001-100 6388-001-106 6388-001-080 6388-001-926 0025-079-000 639000010901

Name Flat head socket screw Hex head cap screw Flat washer Nylock hex nut Foot end fastener assembly (page 12) Antler assembly Back cover Label, specification Lock down base plate Lock down washer (not shown) Label, DPM Dome head rivet Label, EAR

Quantity 7 2 7 7 1 1 1 1 2 8 1 2 1

EN 10

6385-009-002 Rev AA.0

Model 6389 cot fastener assembly
6389-001-010 Rev AA (Reference only)

Item A B C D E F G H J K L M N

Torque items A and D to 30 ± 5 ft-lb

Number 0001-184-000 0003-109-000 0011-014-000 0016-401-000 6385-001-012 6385-001-013 6385-001-080 6385-001-100 6388-001-107 6389-001-080 6389-001-926 0025-079-000 639000010901

Name Flat head socket screw Hex head cap screw Flat washer Nylock hex nut Foot end fastener assembly (page 12) Antler assembly Back cover Label, specification Lock down base plate Lock down washer (not shown) Label, DPM Dome head rivet Label, EAR

Quantity 7 2 7 7 1 1 1 1 2 8 1 2 1

6385-009-002 Rev AA.0

11 EN

Foot end fastener assembly
6385-001-012 Rev AA (Reference only)

EN 12

6385-009-002 Rev AA.0

Item A B C D E F G H J K M N R T U V W Y AA AB AC AD

Number 0003-109-000 0003-113-000 0003-390-000 0011-077-000 0016-028-000 0025-079-000 638500010015 0038-590-000 0038-591-000 0055-100-076 6060-090-114 6385-001-050 6385-001-082 6385-001-085 6385-001-086 6385-001-087 6385-001-088 6385-001-090 6385-001-091 6385-001-092 6385-001-093 6385-001-094

Name Hex head cap screw Hex head cap screw Hex head cap screw Washer Fiberlock hex nut Dome head rivet Spring retaining bracket Extension spring Extension spring Riv nut Label, warning Plate, bottom, weldment Inside hook Main link Flange bearing Pedal spacer Pedal Main rod Rod spacer Top rod Bottom slide Bottom roller

6385-009-002 Rev AA.0

Quantity 4 1 4 4 6 4 1 4 1 2 2 1 2 1 2 2 1 1 1 1 1 2

13 EN

Item AE AF AG AH AJ

Number 6385-001-095 6385-001-097 6385-001-098 6385-001-099 6080-090-023

Name Link stop Slide bushing Lock pin Slot cover Label, RUGGED

Quantity 1 2 1 2 1

EN 14

6385-009-002 Rev AA.0

Stryker Medical 3800 E. Centre Avenue Portage, MI 49002 USA

6385-009-002 Rev AA.0 WCR: AC.3

2022-11

References

• Stryker Medical - Tech Web
