DAYTON AUDIO KAB-250v4 2x50W Class D Audio Amplifier Board with 5.0 Bluetooth
INCLUDED
- Speaker Cable
- Power Cable
- Bluetooth Pairing
- Control Cable
FUNCTIONAL CABLE PACKAGE
- Aux-In Cable
- Volume Control with Cable
- Battery Cable
- On/Off Power Cable
LED PACKAGE
- Power LED
- Bluetooth LED
- Charging LED
ADDITIONAL
- Interface Expansion Board
- Li-ion Battery Charging Board KAB-BE
- Future Expansion
- Line Out Mono
- Optional External Bluetooth Antenna Port
- Programming Port for Optional KPX Boar
Speaker Output Connector:
J2 MOLEX-4PIN-3MM
Pin | Definition |
| 1 | R OUT |
2 | L OUT+ |
| 3 | R OUT+ |
4 | L OUT |
