LIGHT SKY 260II Plus Moving Head Laser Light and Head Beam

CHANNEL FUNCTION(V1.0)

Channel table

channe	DMX	Percentage	function
1	Colour
	0 – 4	0 – 1 . 56	White
	5 – 8	1 . 96 – 3 . 14	White+Red
	9 – 12	3 . 53 – 4 . 71	Red
	13 – 17	5 . 10 – 6 . 67	Red+Orange
	18 – 21	7 . 06 – 8 . 24	Orange
	22 – 25	8 . 63 – 9 . 80	Orange+Aquamarine
	26 – 29	10 . 2 – 11 . 4	Aquamarine
	30 – 34	11 . 8 – 13 . 3	Aquamarine+Green
	35 – 38	13 . 7 – 14 . 9	Green
	39 – 42	15 . 3 – 16 . 5	Green+Light Green
	43 – 46	16 . 9 – 18 . 0	Light Green
	47 – 51	18 . 4 – 20 . 0	Light Green+Lavender
	52 – 55	20 . 4 – 21 . 6	Lavender
	56 – 59	22 . 0 – 23 . 1	Lavender+Pink
	60 – 63	23 . 5 – 24 . 7	Pink
	64 – 68	25 . 1 – 26 . 7	Pink+Yellow
	69 – 72	27 . 0 – 28 . 2	Yellow
	73 – 76	28 . 6 – 29 . 8	Yellow+Magenta
	77 – 81	30 . 2 – 31 . 8	Magenta
	82 – 85	32 . 2 – 33 . 3	Magenta+Cyan
	86 – 89	33 . 7 – 34 . 9	Cyan
	90 – 93	35 . 3 – 36 . 5	Cyan+CTO 260 +CTO 2
	94 – 98	36 . 9 – 38 . 4	CTO 260 / CTO 2
	99 – 102	38 . 8 – 40 . 0	CTO 260 +CTO 190 / CTO 2 +CTO 1
	103 – 106	40 . 4 – 41 . 6	CTO 190 / CTO 1
	107 – 110	42 . 0 – 43 . 1	CTO 190 +CTB 8000 / CTO 1 +CTB
	111 – 115	43 . 5 – 45 . 1	CTB 8000 / CTB
	116 – 119	45 . 5 – 46 . 7	CTB 8000 +Dark Blue/ CTB+
	120 – 123	47 . 1 – 48 . 2	Dark Blue
	124 – 127	48 . 6 – 49 . 8	Dark Blue+White
	128 – 191	50 . 2 – 74 . 9	CCW，Fast→Slow Rotation
	192 – 255	75 . 3 – 100	CW，Slow→Fast Rotation
2	Strobe
	0 – 3	0 – 1 . 2	Closed
	4 – 103	1 . 6 – 40 . 4	Slow– Fast Strobe
	104 – 107	40. 8- 42. 0	Open
	108 – 157	42 . 4 – 61 . 6	Pulsation slow-fast, fast off,slow open
	158 – 207	62 . 0 – 81 . 2	Pulsation slow-fast, fast open,slow off
	208 – 212	81 . 6 – 83 . 1	Open

channe	DMX	Percentage	function
	213-251	83.5-98.4	Random Slow-Fast Strobe
	252-255	99.8-100	Open
3	0-255	0-100	Dimmer
4	GOBO
	0 – 3	0 – 1 . 2	White
	4 – 7	1 . 6 – 2 . 7	Gobo 1
	8 – 11	3 . 1 – 4 . 3	Gobo 2
	12 – 15	4 . 7 – 5 . 9	Gobo 3
	16 – 19	6 . 3 – 7 . 5	Gobo 4
	20 – 23	7 . 8 – 9 . 0	Gobo 5
	24 – 27	9 . 4 – 10 . 6	Gobo 6
	28 – 31	11 . 0 – 12 . 2	Gobo 7
	32 – 35	12 . 5 – 13 . 7	Gobo 8
	36 – 39	14 . 1 – 15 . 3	Gobo 9
	40 – 43	15 . 7 – 16 . 9	Gobo 10
	44 – 47	17 . 3 – 18 . 4	Gobo 11
	48 – 51	18 . 8 – 20 . 0	Gobo 12
	52 – 55	20 . 4 – 21 . 6	Gobo 13
	56 – 59	22 . 0 – 23 . 1	Gobo 14
	60 – 73	23 . 5 – 28 . 6	Gobo 1 Shake Slow- Fast Speed
	74 – 87	29 . 0 – 34 . 1	Gobo 2 Shake Slow- Fast Speed
	88 – 101	34 . 4 – 39 . 6	Gobo 3 Shake Slow- Fast Speed
	102-115	40.0-45.1	Gobo 4 Shake Slow- Fast Speed
	116-129	45.5-50.6	Gobo 5 Shake Slow- Fast Speed
	130-143	51.0-56.1	Gobo 6 Shake Slow- Fast Speed
	144-157	56.5-61.6	Gobo 7 Shake Slow- Fast Speed
	158-171	62.0-67.1	Gobo 8 Shake Slow- Fast Speed
	172-185	67.5-72.6	Gobo 9 Shake Slow- Fast Speed
	186-199	72.9-78.0	Gobo 10 Shake Slow- Fast Speed
	200-213	78.4-83.5	Gobo 11 Shake Slow- Fast Speed
	214-227	83.9-89.0	Gobo 12 Shake Slow- Fast Speed
	228-241	89.4-94.5	Gobo 13 Shake Slow- Fast Speed
	242-255	94.9-100	Gobo 14 Shake Slow- Fast Speed
5	Prism
	0 – 63	0-24.7	Unused Range
	64 – 127	25-49.8	Prism 1
	128-191	50.2-74.9	Prism 2
	192-255	75.3-100	Prism 1 +Prism 2
6	Prism Rotation
6	0	0	Unused Range

channe	DMX	Percentage	function
6	1 – 63	0.4-24.7	0 – 180°rotation 0 – 180
	64 – 127	25.1-49.8	CCW，Fast → Slow
	128-191	50.2-74.9	CW，Slow → Fast
	192-207	75.3-81.2	Slow → Fast Rotation，90 degrees back and forth
	208-223	81.6-87.5	Slow → Fast Rotation，180 degrees back and forth
	224-239	87.8-93.7	Slow → Fast Rotation，270 degrees back and forth
	240-255	94.1-100	Slow → Fast Rotation，360 degrees back and forth
7	Prism Macro
	0-15	0-5.9	Unused Range
	16-55	6.3-21.6	From fast to slow，8 prism free switch
	56-95	22.0-37.3	From fast to slow，16 prism free switch
	96-135	37.6-52.9	From fast to slow，8 prism+16 prism at the same time free switch
	136-175	53.3-68.6	8 prism + 16 prism to free switch from fast to slow
	176-215	69.0-84.3	16 prism + 8 prism to free switch from fast to slow
	216-255	84.7-100	From fast to slow，8 prism and 16 the prism interlock switch
8	0-255	0-100	Frost
9	0-255	0-100	Focus
10	0-255	0-100	Pan
11	0-255	0-100	Pan Fine
12	0-255	0-100	TILT
13	0-255	0-100	TILT Fine
14	0-255	0-100	Unused Range
15	Reset
	0-25	0-9.8	Unused Range
	26-76	10.2-29.8	Effect Reset
	77-127	30.2-49.8	PAN/ TITL Reset
	128-255	50.2-100	Complete Reset
16	Lamp control
	0-25	0-9.8	Unused Range
	26-100	10.2-39.2	Lamp OFF
	101-255	39.6-100	Lamp ON

channe	DMX	Percentage	function
1	Colour
	0 – 4	0 – 1 . 56	White
	5 – 8	1 . 96 – 3 . 14	White+Red
	9 – 12	3 . 53 – 4 . 71	Red
	13 – 17	5 . 10 – 6 . 67	Red+Orange
	18 – 21	7 . 06 – 8 . 24	Orange
	22 – 25	8 . 63 – 9 . 80	Orange+Aquamarine
	26 – 29	10 . 2 – 11 . 4	Aquamarine
	30 – 34	11 . 8 – 13 . 3	Aquamarine+Green
	35 – 38	13 . 7 – 14 . 9	Green
	39 – 42	15 . 3 – 16 . 5	Green+Light Green
	43 – 46	16 . 9 – 18 . 0	Light Green
	47 – 51	18 . 4 – 20 . 0	Light Green+Lavender
	52 – 55	20 . 4 – 21 . 6	Lavender
	56 – 59	22 . 0 – 23 . 1	Lavender+Pink
	60 – 63	23 . 5 – 24 . 7	Pink
	64 – 68	25 . 1 – 26 . 7	Pink+Yellow
	69 – 72	27 . 0 – 28 . 2	Yellow
	73 – 76	28 . 6 – 29 . 8	Yellow+Magenta
	77 – 81	30 . 2 – 31 . 8	Magenta
	82 – 85	32 . 2 – 33 . 3	Magenta+Cyan
	86 – 89	33 . 7 – 34 . 9	Cyan
	90 – 93	35 . 3 – 36 . 5	Cyan+CTO 260 +CTO 2
	94 – 98	36 . 9 – 38 . 4	CTO 260 / CTO 2
	99 – 102	38 . 8 – 40 . 0	CTO 260 +CTO 190 / CTO 2 +CTO 1
	103 – 106	40 . 4 – 41 . 6	CTO 190 / CTO 1
	107 – 110	42 . 0 – 43 . 1	CTO 190 +CTB 8000 / CTO 1 +CTB
	111 – 115	43 . 5 – 45 . 1	CTB 8000 / CTB
	116 – 119	45 . 5 – 46 . 7	CTB 8000 +Dark Blue/ CTB+
	120 – 123	47 . 1 – 48 . 2	Dark Blue
	124 – 127	48 . 6 – 49 . 8	Dark Blue+White
	128 – 191	50 . 2 – 74 . 9	CCW，Fast→Slow Rotation
	192 – 255	75 . 3 – 100	CW，Slow→Fast Rotation
2	Strobe
	0 – 3	0 – 1 . 2	Closed
	4 – 103	1 . 6 – 40 . 4	Slow– Fast Strobe
	104 – 107	40. 8- 42. 0	Open
	108 – 157	42 . 4 – 61 . 6	Pulsation slow-fast, fast off,slow open
	158 – 207	62 . 0 – 81 . 2	Pulsation slow-fast, fast open,slow off
	208 – 212	81 . 6 – 83 . 1	Open

channe	DMX	Percentage	function
	213-251	83.5-98.4	Random Slow-Fast Strobe
	252-255	99.8-100	Open
3	0-255	0-100	Dimmer
4	GOBO
	0 – 3	0 – 1 . 2	White
	4 – 7	1 . 6 – 2 . 7	Gobo 1
	8 – 11	3 . 1 – 4 . 3	Gobo 2
	12 – 15	4 . 7 – 5 . 9	Gobo 3
	16 – 19	6 . 3 – 7 . 5	Gobo 4
	20 – 23	7 . 8 – 9 . 0	Gobo 5
	24 – 27	9 . 4 – 10 . 6	Gobo 6
	28 – 31	11 . 0 – 12 . 2	Gobo 7
	32 – 35	12 . 5 – 13 . 7	Gobo 8
	36 – 39	14 . 1 – 15 . 3	Gobo 9
	40 – 43	15 . 7 – 16 . 9	Gobo 10
	44 – 47	17 . 3 – 18 . 4	Gobo 11
	48 – 51	18 . 8 – 20 . 0	Gobo 12
	52 – 55	20 . 4 – 21 . 6	Gobo 13
	56 – 59	22 . 0 – 23 . 1	Gobo 14
	60 – 73	23 . 5 – 28 . 6	Gobo 1 Shake Slow- Fast Speed
	74 – 87	29 . 0 – 34 . 1	Gobo 2 Shake Slow- Fast Speed
	88 – 101	34 . 4 – 39 . 6	Gobo 3 Shake Slow- Fast Speed
	102-115	40.0-45.1	Gobo 4 Shake Slow- Fast Speed
	116-129	45.5-50.6	Gobo 5 Shake Slow- Fast Speed
	130-143	51.0-56.1	Gobo 6 Shake Slow- Fast Speed
	144-157	56.5-61.6	Gobo 7 Shake Slow- Fast Speed
	158-171	62.0-67.1	Gobo 8 Shake Slow- Fast Speed
	172-185	67.5-72.6	Gobo 9 Shake Slow- Fast Speed
	186-199	72.9-78.0	Gobo 10 Shake Slow- Fast Speed
	200-213	78.4-83.5	Gobo 11 Shake Slow- Fast Speed
	214-227	83.9-89.0	Gobo 12 Shake Slow- Fast Speed
	228-241	89.4-94.5	Gobo 13 Shake Slow- Fast Speed
	242-255	94.9-100	Gobo 14 Shake Slow- Fast Speed
5	Prism
	0 – 63	0-24.7	Unused Range
	64 – 127	25-49.8	Prism 1
	128-191	50.2-74.9	Prism 2
	192-255	75.3-100	Prism 1 +Prism 2
6	Prism Rotation
6	0	0	Unused Range

channe	DMX	Percentage	function
6	1 – 63	0.4-24.7	0 – 180°rotation 0 – 180
	64 – 127	25.1-49.8	CCW，Fast → Slow
	128-191	50.2-74.9	CW，Slow → Fast
	192-207	75.3-81.2	Slow → Fast Rotation，90 degrees back and forth
	208-223	81.6-87.5	Slow → Fast Rotation，180 degrees back and forth
	224-239	87.8-93.7	Slow → Fast Rotation，270 degrees back and forth
	240-255	94.1-100	Slow → Fast Rotation，360 degrees back and forth
7	Prism Macro
	0-15	0-5.9	Unused Range
	16-55	6.3-21.6	From fast to slow，8 prism free switch
	56-95	22.0-37.3	From fast to slow，16 prism free switch
	96-135	37.6-52.9	From fast to slow，8 prism+16 prism at the same time free switch
	136-175	53.3-68.6	8 prism + 16 prism to free switch from fast to slow
	176-215	69.0-84.3	16 prism + 8 prism to free switch from fast to slow
	216-255	84.7-100	From fast to slow，8 prism and 16 the prism interlock switch
8	0-255	0-100	Frost
9	0-255	0-100	Focus
10	0-255	0-100	Pan
11	0-255	0-100	Pan Fine
12	0-255	0-100	TILT
13	0-255	0-100	TILT Fine
14	Function
	0-25	0-9.8	Unused Range
	26-30	10.2-11.8	Effect Reset
	31-35	12.2-13.7	PAN/ TITL Reset
	36-40	14.1-15.7	Complete Reset
	41-180	16.1-70.6	Unused Range
	181-200	71.0-78.4	Lamp OFF
	201-220	78.8-86.3	Unused Range
	221-255	86.7-100	Lamp ON

channe	DMX	Percentage	function
1	Colour
	0 – 4	0 – 1 . 56	White
	5 – 8	1 . 96 – 3 . 14	White+Red
	9 – 12	3 . 53 – 4 . 71	Red
	13 – 17	5 . 10 – 6 . 67	Red+Orange
	18 – 21	7 . 06 – 8 . 24	Orange
	22 – 25	8 . 63 – 9 . 80	Orange+Aquamarine
	26 – 29	10 . 2 – 11 . 4	Aquamarine
	30 – 34	11 . 8 – 13 . 3	Aquamarine+Green
	35 – 38	13 . 7 – 14 . 9	Green
	39 – 42	15 . 3 – 16 . 5	Green+Light Green
	43 – 46	16 . 9 – 18 . 0	Light Green
	47 – 51	18 . 4 – 20 . 0	Light Green+Lavender
	52 – 55	20 . 4 – 21 . 6	Lavender
	56 – 59	22 . 0 – 23 . 1	Lavender+Pink
	60 – 63	23 . 5 – 24 . 7	Pink
	64 – 68	25 . 1 – 26 . 7	Pink+Yellow
	69 – 72	27 . 0 – 28 . 2	Yellow
	73 – 76	28 . 6 – 29 . 8	Yellow+Magenta
	77 – 81	30 . 2 – 31 . 8	Magenta
	82 – 85	32 . 2 – 33 . 3	Magenta+Cyan
	86 – 89	33 . 7 – 34 . 9	Cyan
	90 – 93	35 . 3 – 36 . 5	Cyan+CTO 260 +CTO 2
	94 – 98	36 . 9 – 38 . 4	CTO 260 / CTO 2
	99 – 102	38 . 8 – 40 . 0	CTO 260 +CTO 190 / CTO 2 +CTO 1
	103 – 106	40 . 4 – 41 . 6	CTO 190 / CTO 1
	107 – 110	42 . 0 – 43 . 1	CTO 190 +CTB 8000 / CTO 1 +CTB
	111 – 115	43 . 5 – 45 . 1	CTB 8000 / CTB
	116 – 119	45 . 5 – 46 . 7	CTB 8000 +Dark Blue/ CTB+
	120 – 123	47 . 1 – 48 . 2	Dark Blue
	124 – 127	48 . 6 – 49 . 8	Dark Blue+White
	128 – 191	50 . 2 – 74 . 9	CCW，Fast→Slow Rotation
	192 – 255	75 . 3 – 100	CW，Slow→Fast Rotation
2	Strobe
	0 – 3	0 – 1 . 2	Closed
	4 – 103	1 . 6 – 40 . 4	Slow– Fast Strobe
	104 – 107	40. 8- 42. 0	Open
	108 – 157	42 . 4 – 61 . 6
		62 . 0 – 81 . 2	Pulsation slow-fast, fast open,slow off
	208 – 212	81 . 6 – 83 . 1	Open

channe	DMX	Percentage	function
	213-251	83.5-98.4	Random Slow-Fast Strobe
	252-255	99.8-100	Open
3	0-255	0-100	Dimmer
4 5	GOBO
	0 – 3	0 – 1 . 2	White
	4 – 7	1 . 6 – 2 . 7	Gobo 1
	8 – 11	3 . 1 – 4 . 3	Gobo 2
	12 – 15	4 . 7 – 5 . 9	Gobo 3
	16 – 19	6 . 3 – 7 . 5	Gobo 4
	20 – 23	7 . 8 – 9 . 0	Gobo 5
	24 – 27	9 . 4 – 10 . 6	Gobo 6
	28 – 31	11 . 0 – 12 . 2	Gobo 7
	32 – 35	12 . 5 – 13 . 7	Gobo 8
	36 – 39	14 . 1 – 15 . 3	Gobo 9
	40 – 43	15 . 7 – 16 . 9	Gobo 10
	44 – 47	17 . 3 – 18 . 4	Gobo 11
	48 – 51	18 . 8 – 20 . 0	Gobo 12
	52 – 55	20 . 4 – 21 . 6	Gobo 13
	56 – 59	22 . 0 – 23 . 1	Gobo 14
	60 – 69	23 . 5 – 27 . 0	Gobo 1 Shake Slow- Fast Speed
	70 – 79	27 . 4 – 31 . 0	Gobo 2 Shake Slow- Fast Speed
	80 – 89	31 . 4 – 34 . 9	Gobo 3 Shake Slow- Fast Speed
	90-99	35.3-38.9	Gobo 4 Shake Slow- Fast Speed
	100-109	39.3-42.7	Gobo 5 Shake Slow- Fast Speed
	110-119	43.1-46.6	Gobo 6 Shake Slow- Fast Speed
	120-129	47.0-50.5	Gobo 7 Shake Slow- Fast Speed
	130-139	50.9-54.5	Gobo 8 Shake Slow- Fast Speed
	140-149	54.9-58.4	Gobo 9 Shake Slow- Fast Speed
	150-159	58.8-62.3	Gobo 10 Shake Slow- Fast Speed
	160-169	62.7-66.2	Gobo 11 Shake Slow- Fast Speed
	170-179	66.7-70.2	Gobo 12 Shake Slow- Fast Speed
	180-189	70.6-74.1	Gobo 13 Shake Slow- Fast Speed
	190-199	74.5-78.0	Gobo 14 Shake Slow- Fast Speed
	200-225	78.4-88.2	Fast– Slow Rotation
	226-229	88.6-89.8	Stop
	230-255	90.2-100	Slow– Fast Rotation
	Prism
	0 – 63	0-24.7	Unused Range
	64 – 127	25-49.8	Prism 1
	128-191	50.2-74.9	Prism 2
	192-255	75.3-100	Prism 1 +Prism 2

channe	DMX	Percentage	function
6	Prism Rotation
	0	0	Unused Range
	1 – 63	0.4-24.7	0 – 180°rotation 0 – 180
	64 – 127	25.1-49.8	CCW，Fast → Slow
	128-191	50.2-74.9	CW，Slow → Fast
	192-207	75.3-81.2	Slow → Fast Rotation，90 degrees back and forth
	208-223	81.6-87.5	Slow → Fast Rotation，180 degrees back and forth
	224-239	87.8-93.7	Slow → Fast Rotation，270 degrees back and forth
	240-255 94.1-100 Slow → Fast Rotation，360 degrees back and forth
7	Prism Macro
	0-15	0-5.9	Unused Range
	16-55	6.3-21.6	From fast to slow，8 prism free switch
	56-95	22.0-37.3	From fast to slow，16 prism free switch
	96-135	37.6-52.9	From fast to slow，8 prism+16 prism at the same time free switch
	136-175	53.3-68.6	8 prism + 16 prism to free switch from fast to slow
	176-215	69.0-84.3	16 prism + 8 prism to free switch from fast to slow
	216-255	84.7-100	From fast to slow，8 prism and 16 the prism interlock switch
8	0-255	0-100	Frost
9	0-255	0-100	Focus
10	0-255	0-100	Pan
11	0-255	0-100	Pan Fine
12	0-255	0-100	TILT
13	0-255	0-100	TILT Fine
14	0-255	0-100	Unused Range
15	Reset
	0-25	0-9.8	Unused Range
	26-76	10.2-29.8	Effect Reset
	77-127	30.2-49.8	PAN/ TITL Reset
	128-255	50.2-100	Complete Reset
16	Lamp control
	0-25	0-9.8	Unused Range
	26-100	10.2-39.2	Lamp OFF
	101-255	39.6-100	Lamp ON

Light Sky 260ii Plus Moving Head Laser Light And Head Beam User Manual

LIGHT SKY 260II Plus Moving Head Laser Light and Head Beam

CHANNEL FUNCTION(V1.0)

Documents / Resouces

Related Manuals
