GLSPME44 Glasswasher

GLASSWASHER – With Cold Rinse System

Product Description

The GLASSWASHER – With Cold Rinse System, also known as Kasap
Tip Dik Buzdolaplari, is a professional glasswasher designed for
use in industrial kitchens. It provides high efficiency and is
suitable for commercial use.

Technical Information

Product Code: GLSPME44
Dimensions (mm): 480x580x720
Weight (kg): 43
Packaging Dimensions (mm): 500x630x870
Basket Dimensions (mm): 400×400
Power (KW): 5
Operating Voltage (V): 220
Water Pressure: 3×2.5
Fuse (A): 32
Program Pieces: 2-4

Installation Instructions

Place the product on a straight and sturdy ground to prevent
overturning.
Hire a professional technician with installation and service
licenses to handle the installation and servicing of the
appliance.
Connect the appliance to an authorized electric power
supply.
Ensure that the voltage connected to the appliance matches the
voltage specified on the appliance’s label.
Connect the appliance to an earthed outlet in accordance with
safety rules and standards.
Connect the appliance’s earthing to the earthing line on the
nearest electric panel installation.
Follow the current regulations when connecting to the main fuse
and leak current fuse.

Safety Instructions

Before installing the appliance, read the operation and
maintenance instructions carefully. Incorrect installation or part
changing may damage the product or cause injury to people. Our
company is not responsible for any intentional or negligent damage
caused by disobeying instructions and regulations or wrong
connections. Unauthorized intervention with the appliance will
invalidate the warranty.

Operation

If there is a malfunction or failure, immediately turn off the
appliance and have it repaired by authorized service personnel.
Demand original spare parts for repairs.

Cleaning & Maintenance

Refer to the cleaning and maintenance instructions provided in
the user manual to ensure proper care of the glasswasher.

Troubleshooting

If you encounter any issues with the glasswasher, refer to the
troubleshooting section in the user manual for guidance.

Spare Part List – Exploding Drawing

Refer to the spare part list and exploding drawing section in
the user manual for information on available spare parts.

Electric Circuit Schema

Refer to the electric circuit schema section in the user manual
for detailed information on the appliance’s electrical
connections.

View Fullscreen

GLASSWASHER – With Cold Rinse System Kasap Tip Dik Buzdolaplari

CONTENTS

GENERAL INFORMATION

PRODUCT DESCRIPTION

TECHNICAL INFORMATION

TRANSPORTATION

UNPACKING

INSTALLATION

SAFETY INSTRUCTIONS

OPERATION

CLEANING & MAINTENANCE

TROUBLESHOOTING

SPARE PART LIST- EXPLODING DRAWING

ELECTRIC CIRCUIT SCHEMA

Page 2 Page 3 Page 3 Page 4 Page 4 Page 4 Page 5 Page 6 Page 7 Page 8 Page 9 Page 12

GLASSWASHER – With Cold Rinse System
Kasap Tip Dik Buzdolaplari
A GENERAL INFORMATION
Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty.
1. This instruction manual should be kept in a safe place for future reference. 2. Installation should be made in accordance with ordinances and security rules of
that country by a qualified service personnel. 3. This appliance has to be used by trained person. 4. Please turn off the appliance immediately in the event of malfunction or failure.The
appliance should be repaired only by authorized service personnel.Please demand original spare part.
2

GLASSWASHER – With Cold Rinse System

KAa1sapPTRiOpDDUCikT BDEuSzCdRoIPlaTpIOlaNri
*The Professional Glasswasher ,that provides high efficiency has been designed to be used in industrial kitchens.

Product Code GLSPME44

Dimensions (mm) 480x580x720

Weight (kg) 43

Packaging Dimensions (mm)
500x630x870

A2 TECHNICAL INFORMATION

Product Code

Basket Dimensi on (mm)

GLSPME44 400×400

Pow er
(KW)
5

Operati ng
Voltage (V)
220

Water Pressu
re

Program piece

Cable (mm²)

2-4

3×2,5

Fuse (A)
32

GLASSWASHER – With Cold Rinse System
A3 TRANSPORTATION
K*foTarhksilsifatapptrpulTciakni.pce DcainknoBt ubezmdoovelad pbylaharnid from area to area.It must be moved on pallet with
A4 UNPACKING
*Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol. *Please check that all the parts of appliance had come completely and if they are damaged or not during the shipping.
B INSTALLATION
*Please place the product to straight and sturdy ground,please take necessary steps against possibility of overturn. *Technician who will serve for installation and service for the appliance must be professional on this subject and must have installation and service licenses by the company. *Connection to Electric Power Supply must be done by authorized person. *Please be sure that the voltage connected to appliance must be equal with the voltage which is on appliance’s label.
! This appliance must be connected to an earthed outlet in accordance with safety rules and standards. *Appliance’s earthing must be connected to earthing line on panel which is nearest to electric installation. *Connection to the main fuse and leak current fuse must be done in accordance with the current regulations.
4

GLASSWASHER – With Cold Rinse System

KCasapSTAiFpEDTYikINBSuTzRdUoClaTpIOlaNrSi

*Do not use the appliance in insufficient lighted place.

*Do not touch the moving attachments while the appliance operates.

*Do not install the appliance in the presence of flammable or explosive materials.

*Do not operate the appliance when the machine is empty. !

*Do not load so less or more than appliance’s capacity.

*Do not attempt to use the appliance without suitable protective equipments.

*Because of any reason if there is a fire or flame flare where the appliance is

used,turn off all gas valves and electric contactor switch quickly and use fire

extinguisher .Never use water to extinguish the fire.

*All the damages because of not having earthing connection will not be on

warranty.

*Do not wash the decorated glasses.Prevent silver wares to contact with the other

metals.

GLASSWASHER – With Cold Rinse System
D OPERATION
Kasap Tip Dik Buzdolaplari

*Control Panel;
A : Appliance ON lamp B : Water heated lamp C : Washing lamp D : Water getting /rinsing E : Evacuation lamp

F : Evacuation position G : Appliance OFF position H : Water inlet I : Washing program

*Operating;
· Change the water that is in water tank 3 times in a day. · Before putting the glasses in to the appliance,make prewash with cold or warm water
without using any detergent. · Turn on water source valve. · Plug in the appliance. · In order to take off any residue that remain in storage or pipes,operate the appliance
when it is empty. · In order to operate the appliance switch to `Water Inlet’ position. Water Inlet lamp
signals.It means power is given to glasswasher,water is given and heated. · When heating process completed, water heated lamp signals. · Place the dirty glasses to the baskets. · Close the lid and switch to washing program.Involved indicator lamp signals and washing
process starts. · Washing process; for hot water and washing with detergent (minimum 55°C) ,for rinsing
with hot water (minimum 75°C). · In order to stop washing,open the lid when it is at `Washing’ position. · After the washing is completed, the machine will automatically rinse with hot water for 15
seconds, then rinse with cold water for 15 seconds and automatically drain excess water. · Take off the basket that includes washed glasses.

GLASSWASHER – With Cold Rinse System KEasapCTLiEpADNiIkNGBu&zMdAoIlNaTpElaNrAiNCE
CLEANING AND MAINTENANCE AFTER EVERY USE · Always turn off the appliance and disconnect from the power supply before cleaning. · Clean all surfaces of the appliance with hot soapy water after every use.Rinse and dry with a wet cloth. · Clean the control panel with soft moisty cloth,if necessary use ineffective detergent. · Do not use abrasive cleaning chemicals as these can leave harmful residues. · Do not clean the appliance by spraying water directly,otherwise electric motor may get damaged.
PERIODIC CLEANING AND MAINTENANCE · Maintenance should be done by qualified person. · Clean the limes of the burner,inner surface of the washing tank and water pipes once or twice in a year. · Clean the limes with using rinsing and washing nozzles once in a month by using vinegar or lime remover. · Clean the filters in the appliance once in a week.After cleaning be sure that thumbscrew is compressed. · Clean the appliance’s fountains once in 15 days by detaching it.
7

GLASSWASHER – With Cold Rinse System

TROUBLESHOOTING

Kasap

Tip

Dik

Buzdo12la.. pCClalheeracinktthheeafobusnotrapitniosnif

filter they

if it is dirty. are accumulated

with

residues or not.

GLASSES ARE NOT

3. Check the amount of detergent.

WASHED WELL

4. If the chosen washing program is too less,repeat the

program.

5. Be sure that the dishes are placed correctly on baskets.

GLASSES ARE NOT DRIED WELL

1. Check that if there is polisher or not if necessary add some.
2. Check the amount of polisher.

MIST OVER ON CUPS
RUST ON CUPS
MUCH FOAM AT STORAGE WASHING OR RINSING HANDLES ARE TURNING SLOWLY

1. Take off the baskets after washing.
1. Only use products that are not foaming for the professional glasswashers.
1. Check the amount of detergent. 2. If foaming detergent is used,pour it and rinse the storage
till the foams are lost.
1. Take off washing handles and clean them. 2. Clean the washing pump absorbing filter.

VISCIDITY ON CUPS

1. Reduce the amount of polisher.

· If glasswashing is not done at suitable quality · If any function of security doesn’t work
Do not use the appliance.
*If these problems are still going on,contact with our authorized services.
8

GLASSWASHER – With Cold Rinse System KGasapSTPiApRDEikPABRuTzLdIoSlTa-EpXlaPrLiODING DRAWING
9

GLASSWASHER – With Cold Rinse System

NAME OF THE PRODUCT:1100-MS

NAME OF THE PRODUCT

PRODUCT CODE

Kas12ap Tip Dik BuMzdAGoNlELaETVIpCElSRaENrSiOR

ERK.M.ELK-SWC-KTG-004 ERK.M.ELK-SLT-PKO-011

GLASS FUSE 5A

ERK.M.ELK-SGR-011

LC1K0901M7 CONTACTOR

ERS.M.ELK-KNT-KNT-020

CONTACTOR LC1K0910M

ERS.M.ELK-KNT-KNT-021

LC1K1210M7 CONTACTOR

ERS.M.ELK-KNT-KNT-022

evacuation time relay

ERK.M.ELK-KNT-ROL-007

WASH TIME RELAY

ERK.M.ELK-KNT-ROL-020

ELECTRICAL PANEL GROUP

M.ELK-PNO-BYM-019

PROCESTAT FLOAT

M.ELK-MUH-001

TOP COVER SHEET

YSC-ERS.BYM-LZ-0469

BASKET

M.PLS-ERS-024

CHASSIS

–

BACK COVER SHEET

YSC-ERS.BYM-PN-0359

LEFT SIDE SHEET

YSC-ERS.BYM-PN-0356

SPINNING SPINDLE

YTL-ERS.BYM-KS-0031

DETERGENT SEAL

M.CNT-ERS-013

UPPER SPIN

M.ENJ-ERS-PLS-BYM-054

SPRAY SCREW

M.ENJ-ERS-PLS-BYM-031

BOTTOM SPIN

M.ENJ-ERS-PLS-BYM-055

SPRAY PIPE

YBR-ERS.BYM-KS-0009

FOUNTAIN ARM

M.ENJ-ERS-PLS-BYM-045

SPRAY BOTTOM SHEET

YSC-ERS.BYM-LZ-0054

LOWER SPRAY ELBOW

M.ENJ-ERS-PLS-BYM-046

INLET FITTING

YTL-ERS.BYM-KS-0033

VALVE HOSE

ERS.M.MEK-TES-HRT-006

HOSE (150CM)

ERS.M.MEK-TES-HRT-011

WASTE WATER HOSE

M.MEK-TES-HRT-107

POLISHING PUMP HOSE

M.MEK-TES-HRT-020

RINSE PORT

YTL-ERS.BYM-KS-0004

DETERGENT ENTRY PLASTIC

M.PLS-ERS-036

AIR TRAP LOCATION

M.ENJ-ERS-PLS-BYM-015

VALVE DOUBLE

M.ELK-SLN-PLS-008

DETERGENT SEAL

M.CNT-ERS-013

AIR TRAP

M.ENJ-ERS-PLS-BYM-019

OUTPUT PIPE

YBR-ERS.BYM-KS-0004

BOILER TANK

M.MEK-TES-BYM-BYL-003

DRAIN WEDGE

M.ENJ-ERS-PLS-BYM-016

FILTER COVER

M.ENJ-ERS-PLS-BYM-086

GLASSWASHER – With Cold Rinse System

Kas4a0p Tip DikDBISCuHzARdGoElWaEpDlGaErLiOCATION

FILTER GASKET

RINSE SPIN HOSE

TANK RESISTANCE 230V-2500W

BOILER RESISTANCE-220V-2000W

FOOT

DRAIN PUMP

FILTER

FILTER LOCATION

FILTER GASKET

WASHING MOTOR

ORING

5/8 SILICONE HOSE

WASHING PUMP HOSE

RESISTANCE COVER

THERMOSTAT PIPE

THERMOSTAT 0-90°C

POLISHING PUMP

BOTTOM COVER SHEET

SLEEVE PART

TOP COVER ARM RIGHT LEFT SHEET

COVER OUTER SHEET

DOOR HANDLE

MAGNET LOCATION

MAGNET

LOCK KIT SPRING PLACE

BEAR

COVER LOCK SPRING

LOCK BODY

CORNER PLASTIC RIGHT

CORNER PLASTIC LEFT

SWITCH BUTTON

GREEN WARNING LAMP

YELLOW WARNING LAMP

PANEL LABEL

RIGHT SIDE SHEET

M.ENJ-ERS-PLS-BYM-112 M.CNT-ERS-021
M.MEK-TES-HRT-103 M.ELK-RZS-BRU-BYM-028 M.ELK-RZS-BRU-BYM-018
M.AKS-AYK-INX-004 M.ELK-MTR-PMP-002 M.ENJ-ERS-PLS-BYM-041 M.ENJ-ERS-PLS-BYM-042
M.CNT-ERS-021 M.ELK-MTR-PMP-003
M.CNT-ORG-009 HTS-HRT-004
ERS.M.MEK-TES-HRT-014 M.ENJ-ERS-PLS-BYM-025 YBR-ERS.BYM-KS-0003 M.ELK-MEK-TRM1-008
M.ELK-MTR-PMP-004 YSC-ERS.BYM-LZ-0476 YTL-ERS.BYM-KS-0119 YSC-ERS.BYM-LZ-0475 YSC-ERS.BYM-PN-0354 ERS.M.AKS-KLP-INX-003 M.ENJ-ERS-PLS-BYM-001
M.MIK-ERS-001 YTL-ERS.BYM-KS-0073
M.MUH-021 M.YAY-ERS-035 YTL-ERS.BYM-KS-0072 M.ENJ-ERS-PLS-BYM-061 M.ENJ-ERS-PLS-BYM-062 ERS.M.AKS-DGM-MUH-001 ERS.M.ELK-LMB-SNY-001 ERS.M.ELK-LMB-SNY-003 M.AKS-ETK-LKS-ERS-BYM-015 YSC-ERS.BYM-PN-0357

GLASSWASHER – With Cold Rinse System
H ELECTRIC CIRCUIT SCHEMA
Kasap Tip Dik Buzdolaplari

5 Progressive Magnetic Door Commutator Sensor

C1
Boiler Contactor
230V

C2
Washing Contactor
230V

PR1

Lid Contactor 230V

Rinsing Contactor 230V

Prossestat

ZR1

ZR2

Start lamp

Rinsing lamp
