AL-UV732L LCD KVM Switch
Product Information
The Angustos AL-UV732L is a high-density, short-depth LCD KVM
switch series. It is a 32-port USB CATx single rail LCD KVM switch
optimized for use in modern data centers. The switch integrates a
17-inch LED screen, keyboard, and mouse pad in a 1U rackmountable
sliding housing. Its short-depth design allows for narrow space and
condensed area rack mounting. The AL-UV732L can control up to 32
computers, and with the cascading of 32 additional KVM switches, it
can control up to 512 computers. It also includes an additional
hot-pluggable USB port for backup keyboard and mouse support. The
AL-UV732L LCD KVM switch offers short space optimization,
exceptional display quality, easy installation, and extreme
versatility.
Features
- Raise efficiency
- Multiple Connection
- Saving time Saving Cost Plug and Play
- Cascadable
- 17 Inch display (4:3)
- Password Protected
Compatible Products
- AC-DV100L: VGA KVM Dongle – CPU Module
- AC-DD100L / AC-DH100L: DVI / HDMI KVM Dongle-CPU Module
- AR-V16L: SHORT DEPTH RACK KVM SWITCH
- IP MODULE CARD: AIP-C
About Angustos
Angustos is a leading manufacturer of digital and analogue KVM
solutions. Founded in 2000, they specialize in extending,
switching, and distributing standardized computer signals. Angustos
is committed to established international standards and offers
complete data center solutions as well as OEM/ODM services. Their
products cater to medium to small businesses, factories, industrial
settings, military and government organizations, home offices, and
personal use.
Specifications
- Keyboard:
- 100 Keys, Detachable
- Multiple Languages Option
- Compatible with Win/Sun/Unix/Linux/Mac
- Mouse:
- Touchpad
- Mouse Resolution: >1000 dots/inch (40×40/mm)
- MTBF: 1,000,000 Press
- KVM Switch Module:
- Direct PC connection: 32
- Maximum PC Connection: 512
- Port Selection: OSD, Button, Hot Key, IP (Optional)
- Console Connector: DB-37 Pins
- KVM Connector: RJ-45 Female x 32
- Power: DC Jack
- Switch button: Panel Digital Keys
- Reset Switch: Panel Function Keys
- Status LEDs: Nixie Tube (Selected Port), Red led (Online
Port) - Server Interface: PS/2, USB
- Cascadable: Support
- Connection Diagram: Included
- LCD Monitor:
- Size / Ratio: 17 / 4:3
- Video: SXGA TFT – LCD
- Visible Square: 337.92 H x 270.336 V
- Resolution: 1280 x 1024 @ 60Hz (Optimal), 1920 x 1200 @ 60Hz
(Max) - Color: 16.7 Mil., RGB 6bit + Hi_FRC
- Contrast: 1000 : 1 (Typical)
- Backlight: LED
- Pixel Pitch: 0.264 x 0.297 mm
- MTBF: 100,000 hours
- CPU Module (AC-Dx100L Series):
- Video Connection: VGA / DVI / HDMI
- Link Connection: 1 x RJ-45 Female
- Operational Specification:
- Operating Temp: -10oC – 50oC
- Storage Temp: -20oC – 60oC
- Humidity: 0-80%RH, No Condensation
- Physical Specification:
- Housing: Metal
- Dimension LCD / KVM: 407x445x45 / 148.4x445x45mm
- Weight LCD / KVM: 6.15 kg / 2.74 kg
- Optional IP Module Bay: ROHS
For more information, visit www.angustos.com.
Contact Information
1309 Coffeen Ave Ste 1200
Sheridan, Wyoming 82801
USA
Product Usage Instructions
To use the Angustos AL-UV732L LCD KVM Switch, follow these
steps:
- Ensure that the switch is securely mounted in a rack or other
suitable location. - Connect the keyboard and mouse to the designated ports on the
switch. - Connect the monitor to the VGA/DVI/HDMI port on the
switch. - If cascading multiple switches, connect the additional KVM
switches using the RJ-45 connectors. - Connect the power supply to the DC jack on the switch.
- Connect the servers or computers to be controlled to the KVM
connectors on the switch. - Power on the switch and the connected servers or
computers. - Use the OSD menu, buttons, hot keys, or optional IP module (if
available) to select and control the desired computer. - For password-protected access, enter the required credentials
when prompted.
Note: Refer to the user manual for detailed instructions on
specific operations, configurations, and troubleshooting.
ANGUSTOS
HIGH DENSITY – SHORT DEPTH LCD KVM SWITCH SERIES
AL-UV732L
32-Port USB CATx Single Rail LCD KVM Switch
Overview
Angustos AL-UV732L LCD KVM Switch is optimized for high density Rack in modern Data Center.
Integrating a 17″ LED screen, keyboard and mouse pad in a 1U rackmountable sliding housing. The short-depth design ultilized for narrow space for short-rack mounting in condensed area. The AL-UV732L can control up to 32 computers; with 32 additional KVM switches are cascaded, a single AL-UV732L LCD KVM Switch can control up to 512 computers.
In addition, the AL-UV732L included an additional hot-pluggable USB port that supports other keyboard and mouse for back-up. With all of the technology involved, the AL-UV732L LCD KVM Switch has gone beyond the expectations and requirements for a modern Data Center use, which including : short space optimization, exceptional display quality, easy to install, extreme versatility.
Features
High Density Utilization · Front USB for back up mouse-keyboard. · Connect to servers with distance up to 40m with single Cat5e / 6 UTP cable · LCD KVM console with an 17” LED-backlit 4:3 LCD monitor in a single rail design. · Short-depth overall size allowing user to work with in condensed space of high density Rack · Slide Lock secure the console drawer to remain firmly in slide position when not in use.
Flexible compatibility · Superior video quality up to 1280 x 1024 @60Hz; DDC2B; 16.7 Mil. Color. · Cascade up to 512 computers from a single console (With compatible KVM Switches) · Auto PS/2 and USB interface sensing. · Keyboard and mouse emulation (PS/2 and USB) for seamless switching. · Computer selection with pushbuttons, hotkeys, and multilingual on-screen display (OSD). · Two level password security. · Operates with all software and operating systems including all Windows versions, DOS, Linux, Unix, BSD, all Sun OS, all Mac OS and NetWare. · Keyboard Language supports: English (UK), English (US), German (GER.) Japanese, Korean, Russian, Swedish, Chinese.
Installation Flexibility · Standard rack mount kit included · No software required – Plug and Play · Firmware upgradable · Supports hot-plugging · Supports Over IP Module for Remote Control
Raise efficiency
Multiple Connection
AL-UV732L FRONT VIEW AL-UV732L REAR VIEW
Saving time Saving Cost Plug and Play
Cascadable
17 Inch display (4:3)
Password Protected
Compatible Product
AC-DV100L
VGA KVM Dongle – CPU Module
AC-DD100L / AC-DH100L
DVI / HDMI KVM Dongle-CPU Module
AR-V16L
SHORT DEPTH RACK KVM SWITCH
IP MODULE CARD
AIP-C
Angustos
Angustos was founded in 2000 and is now regarded as one of the foremost manufacturers of digital and analogue KVM solutions.
For more than 20 years our customers have been convinced by our core competencies in extending, switching and distributing standardised computer signals.
We are committed to established international standards. We can provide customers with complete Datacenter solutions as well as OEM/ODM services. We can cover even from medium to small business, factory & industrial, military & government, home office & personal use.
WWW.ANGUSTOS.COM
1309 COFFEEN AVE STE 1200 SHERIDAN, WYOMING 82801 USA
SPECIFICATION
KEYBOARD & MOUSE
Keyboard
100 Keys, Detachable
Multiple Languages Option
Compatible
Win/Sun/Unix/Linus/Mac
Mouse
Touchpad
Mouse Resolution
>1000 dots/inch (40×40/mm)
MTBF
1,000,000 Press
KVM SWITCH MODULE
Direct PC connection
32
Maximum PC Connection
512
Port Selection
OSD, Button, Hot Key, IP (Opt)
Console Connector
DB-37 Pins
KVM Connector
RJ-45 Female x 32
Power
DC Jack
Switch button
Panel Digital Keys
Reset Switch
Panel Function Keys
Status LEDs
Nixie Tube (Selected Port)
Red led (Online Port)
Server Interface
PS/2 , USB
Cascadable
Support
CONNECTION DIAGRAM
LCD MONITOR
ANGUSTOS
Size / Ratio
17″ / 4:3
Video
SXGA TFT – LCD
Visible Square
337.92 H x 270.336 V
Resolution
1280 x 1024 @ 60Hz (Optimal)
Color
1920 x 1200 @ 60Hz (Max) 16.7 Mil. , RGB 6bit + Hi_FRC
Contrast
1000 : 1 (TyP)
Back light
LED
Pixel Pitch
0.264 x 0.297 mm
MTBF
100,000 hours
CPU MODULE (AC-Dx100L Series)
Video connection
VGA / DVI / HDMI
Link connection
1 x RJ-45 Female
OPERATIONAL SPECIFICATION
Operating Temp
-10oC – 50oC
Storage Temp
-20oC – 60oC
Humidity
0-80%RH, No Condensation
PHYSICAL SPECIFICATION
Housing
Metal
Dimension LCD / KVM
407x445x45 / 148.4x445x45mm
Weight LCD / KVM
6.15 kg / 2.74 kg
OPTIONAL IP MODULE BAY
ROHS
CE/FCC
*For connection with IP Module : Use Instruction on Over IP KVM
RJ-45 Cat5e / Cat6 Cable (Max 40m)
OPTIONAL IP MODULE BAY
Cascade KVM
*Connect to VGA + USB Port on Level 2 KVM
AL-UV732L Back
KVM Dongle – CPU Module
AC-DV100L : VGA Video AC-DD100L : DVI Video AC-DH100L : HDMI Video
PC or Server
WWWWWW..AANNGGUUSSTTOOSS..CCOOMM
1309 COFFEEN AVE STE 1200 SHERIDAN, WYOMING 82801 USA
