Product Name: Angustos AL-H716L 16-Port
PS/2-USB HDMI Single Rail LCD KVM Switch
Product Overview: The Angustos AL-H716L LCD KVM
Switch is a high-density, short-depth switch designed for modern
data centers. It features a 17.3-inch LED screen, keyboard, and
mouse pad integrated into a 1U rackmountable sliding housing. The
switch supports Full HD resolution and can control up to 16
computers. It can be cascaded with up to 16 additional KVM
switches, enabling control of up to 256 computers. The AL-H716L
also includes a hot-pluggable USB port for backup keyboard and
mouse support. It offers short space optimization, exceptional
display quality, easy installation, and extreme versatility.
Features:

Raise efficiency
Multiple connection options
Saving time with cascading support
Saving cost with plug and play functionality
17.3-inch display with 16:9 aspect ratio
Password protected
Compatible with other Angustos products

Product Usage Instructions

Keyboard & Mouse:
The keyboard features 100 keys and is detachable. It supports
multiple language options and is compatible with
Win/Sun/Unix/Linux/Mac operating systems. The mouse has a
resolution of >1000 dots/inch (40×40/mm) and is designed for
long-lasting use with a lifespan of 1,000,000 presses.

KVM Switch Module:
The AL-H716L supports direct PC connections and can connect up to
16 computers. It also supports cascading, allowing for control of
up to 256 computers. Port selection can be done through the
On-Screen Display (OSD), buttons, hotkeys, or IP (optional). The
console connector is HDMI Female, and the KVM connector is HDMI +
USB Type B x 16. Power is supplied through a DC Jack, and the
switch features panel digital keys, reset switch, panel function
keys, and status LEDs.

LCD Monitor:
The LCD monitor has a size of 17.3 inches with a 16:9 wide AHVA
TFT-LCD ratio. It offers a resolution of 1920 x 1080P @ 60Hz
(optimal) and a maximum resolution of 3840 x 2610 @ 30Hz. The color
contrast is 600:1 (typical) with 16.7 million colors. The backlight
brightness is 300 nit (cd/m2), and the pixel pitch is 0.1989 x
0.1989 mm. The LCD monitor has a lifespan of 100,000 hours.

Operational Specification:
The AL-H716L operates within a temperature range of -10°C to 50°C.
It can be stored within a temperature range of -20°C to 60°C. The
humidity range is 0-80%RH without condensation.

Physical Specification:
The housing of the AL-H716L is made of metal. The dimensions of the
LCD and KVM are 407x445x45mm and 148.4x445x45mm, respectively. The
weight of the LCD is 8.5 kg, and the weight of the KVM is 3.32
kg.

Connection Diagram:
Please refer to the provided connection diagram for the AL-H716L
switch. Note that the USB port is reserved for an external keyboard
and mouse.

View Fullscreen

ANGUSTOS

HIGH DENSITY – SHORT DEPTH LCD KVM SWITCH SERIES – FULL HD

AL-H716L

16-Port PS/2-USB HDMI Single Rail LCD KVM Switch

Overview
Angustos AL-H716L LCD KVM Switch is optimized for high density Rack in modern Data Center. Supporting Full HD resolution for high end computers / servers.
Integrating a 17.3″ LED screen, keyboard and mouse pad in a 1U rackmountable sliding housing. The short-depth design ultilized for narrow space for short-rack mounting in condensed area. The AL-H716L can control up to 16 computers; with 16 additional KVM switches are cascaded, a single AL-H716L LCD KVM Switch can control up to 256 computers.
In addition, the AL-H716L included an additional hot-pluggable USB port that supports other keyboard and mouse for back-up. With all of the technology involved, the AL-H716L LCD KVM Swtich has gone beyond the expectations and requirements for a modern Data Center use, which including : short space optimization, exceptional display quality, easy to install, extreme versatility.

Features
High Density Utilization · Front USB for back up mouse-keyboard. · LCD KVM console with an 17.3” LED-backlit 16:9 LCD monitor in a single rail design. · Short-depth overall size allowing user to work with in condensed space of high density Rack · Slide Lock secure the console drawer to remain firmly in slide position when not in use. · Extender compatible Can be combined with Angustos KVM Extender up to 60m.
Flexible compatibility · Superior video quality up to 1920 x 1080 @60Hz; DDC2B; 16.7 Mil. Color. · Cascade up to 256 computers from a single console (With compatible KVM Switches) · Auto PS/2 and USB interface sensing. · Keyboard and mouse emulation (PS/2 and USB) for seamless switching. · Computer selection with pushbuttons, hotkeys, and multilingual on-screen display (OSD). · Two level password security. · Operates with all software and operating systems including all Windows versions, DOS, Linux, Unix, BSD, all Sun OS, all Mac OS and NetWare. · Keyboard Language supports: English (UK), English (US), German (GER.) Japanese, Korean, Russian, Swedish, Chinese.
Installation Flexibility · Standard rack mount kit included · No software required – Plug and Play · Firmware upgradable · Supports hot-plugging

Raise efficiency

Multiple Connection

AL-H716L FRONT VIEW AL-H716L REAR VIEW

Saving time

Cascadable

Saving Cost Plug and Play

17.3″ 17.3 Inch display (16:9)
Password Protected

Compatible Product

AR-H08L

8 PORT HDMI 4K KVM SWITCH

AR-H16L

16 PORT HDMI 4K KVM SWITCH

KCE600H

HDMI USB KVM EXTENDER

Angustos
Angustos was founded in 2000 and is now regarded as one of the foremost manufacturers of digital and analogue KVM solutions.
For more than 20 years our customers have been convinced by our core competencies in extending, switching and distributing standardised computer signals.
We are committed to established international standards. We can provide customers with complete Datacenter solutions as well as OEM/ODM services. We can cover even from medium to small business, factory & industrial, military & government, home office & personal use.

WWW.ANGUSTOS.COM
1309 COFFEEN AVE STE 1200 SHERIDAN, WYOMING 82801 USA

SPECIFICATION

KEYBOARD & MOUSE

Keyboard
Compatible Mouse Mouse Resolution MTBF

100 Keys, Detachable Multiple Languages Option Win/Sun/Unix/Linus/Mac Touchpad >1000 dots/inch (40×40/mm) 1,000,000 Press

KVM SWITCH MODULE

Direct PC connection

Maximum PC Connection

256

Port Selection

OSD, Button, Hot Key, IP (Opt)

Console Connector

HDMI Female

KVM Connector

HDMI + USB Type B x 16

Power

DC Jack

Switch button

Panel Digital Keys

Reset Switch

Panel Function Keys

Status LEDs

Nixie Tube (Selected Port)

Red led (Online Port)

Server Interface

PS/2 , USB

Cascadable

Support

LCD MONITOR
Size / Ratio Video Visible Square Resolution
Color Contrast Back light / Brightness Pixel Pitch MTBF

ANGUSTOS
17.3″ / 16:9 Wide AHVA TFT-LCD 381.88 H x 214.812 V 1920 x 1080P @ 60Hz (Optimal) 3840 x 2610 @ 30Hz (Max)* 16.7 Mil. , RGB 6bit + Hi_FRC 600 : 1 (TyP) LED / 300 nit (cd/m2) 0.1989 x 0.1989 mm 100,000 hours

OPERATIONAL SPECIFICATION

Operating Temp

-10oC – 50oC

Storage Temp

-20oC – 60oC

Humidity

0-80%RH, No Condensation

PHYSICAL SPECIFICATION

Housing

Metal

Dimension LCD / KVM

407x445x45 / 148.4x445x45mm
