Angustos Al-v516p Lcd Kvm Console Drawer Instruction Manual (+ PDF)

The Angustos AL-V516P LCD KVM Console Drawer is designed for
high-density racks in modern data centers. It features a 15-inch
LED screen, keyboard, and mouse pad, all integrated into a 1U
rack-mountable sliding housing. The compact design makes it ideal
for narrow spaces and densely populated areas. The AL-V516P can be
installed and connected with Angustos KVM Switch or other brand KVM
switches for convenient configuration. It has the capability to
control up to 16 computers, and with the cascading of 16 additional
KVM switches, a single AL-V516P LCD KVM Switch can control up to
256 computers. The console also includes an additional
hot-pluggable USB port for backup keyboards and mice.

Features

Saving time
Raise efficiency
Compatible with Angustos AR-V08L, AR-V16L, and AR-UV32L KVM
Switches
Short space optimization
Exceptional display quality
Easy installation
Extreme versatility

Angustos

Angustos, founded in 2000, is a leading manufacturer of digital
and analog KVM solutions. With over 20 years of experience,
Angustos specializes in extending, switching, and distributing
standardized computer signals. They provide complete data center
solutions as well as OEM/ODM services for various industries
including medium to small businesses, factories, military and
government organizations, home offices, and personal use.

Specification

Keyboard & Mouse

Keyboard: 104 keys, digital & e-switch, multiple languages
option (Win/Sun/Unix/Linux/Mac)
Mouse: Touchpad with a resolution of >1000 dots/inch (40×40
mm), MTBF of 1,000,000 presses

KVM Switch Module

Direct PC connection
Maximum PC Connection: 16
Port Selection: OSD, Button, Hot Key, IP (Optional)
Console Connector: HDB-15
KVM Connector: HDB-15 Female x 16
Power: DC Jack
Switch button: Panel Digital Keys
Reset Switch: Panel Function Keys
Status LEDs: Nixie Tube (Selected Port), Red LED (Online
Port)
Server Interface: PS/2, USB
Cascadable: Support

LCD Monitor

Size / Ratio: 15 / 4:3 TFT – LED
Video Visible Square Resolution: 409.8 H x 230.4 V
Color: 16.7 Million, True 8 Bit
Contrast Ratio: 700:1 (Typical)
Brightness: 250 – 400 nit (Optional)
Pixel Pitch: 297 x 297 um
MTBF: 100,000 hours

Operational Specification

Operating Temp: -10°C – 60°C
Storage Temp: -20°C – 70°C
Humidity: 0-95% RH, No Condensation

Physical Specification

Housing: Metal
Dimension: 528 x 481 x 44 mm
Weight LCD / KVM: 12 kg

AL-V516P Back

DB-15 Pin Custom KVM Cable

Contact Information

Website: www.angustos.com

Address: 1309 Coffeen Ave Ste 1200, Sheridan, Wyoming 82801,
USA

View Fullscreen

PROFESSIONAL LED LCD KVM SWITCH – P SERIES

ANGUSTOS

16 PORT – 15″ PS/2-USB VGA Single Rail LCD KVM Console Drawer

AL-V516P

Overview
Angustos AL-V516P LCD KVM Console Drawer is optimized for high density Rack in modern Data Center.
Integrating a 15″ LED screen, keyboard and mouse pad in a 1U rackmountable sliding housing. The compact design console is ultilized for extreme narrow space and super densed area. The AL-V516P can be installed and connected with Angustos KVM Switch or other brand KVM for convenience configuration. The AL-V516P can control up to 16 computers; with 16 additional KVM switches are cascaded, a single AL-V516P LCD KVM Switch can control up to 256 computers.
In addition, the AL-V516P included an additional hot-pluggable USB port that supports other keyboard and mouse for back-up. With all of the technology involved, the AL-V516P LCD KVM Console has gone beyond the expectations and requirements for a modern Data Center use, which including : short space optimization, exceptional display quality, easy to install, extreme versatility.

Features
High Density Utilization · Front USB for back up mouse-keyboard. · LCD KVM console with an 15” LED-backlit 4:3 LCD monitor in a single rail design. · Extreme refresh rate up to 75Hz · Short-depth overall size allowing user to work with in condensed space of high density Rack · Slide Lock secure the console drawer to remain firmly in slide position when not in use.
Flexible compatibility · Superior video quality up to 1024 x 768 @75Hz; DDC2B; 16.7 M Color. · Compatible with Angustos and other brands KVM Switches. · Cascade up to 256 computers from a single console (With compatible KVM Switches) · Auto PS/2 and USB interface sensing. · Keyboard and mouse emulation (PS/2 and USB) for seamless switching. · Operates with all software and operating systems including all Windows versions, DOS, Linux, Unix, BSD, all Sun OS, all Mac OS and NetWare. · Keyboard Language supports: English (UK), English (US), German (GER.) Japanese, Korean, Russian, Swedish, Chinese. · Digital & E-Switch key. Mechanical Mute.

Installation Flexibility · Standard rack mount kit included · No software required – Plug and Play · Supports hot-plugging

Saving time

Raise efficiency

Compatible Product

AR-V08L

SHORT DEPTH RACK KVM SWITCH

AR-V16L

SHORT DEPTH RACK KVM SWITCH

AR-UV32L

HIGH – DENSITY RACK KVM SWITCH

Angustos
Angustos was founded in 2000 and is now regarded as one of the foremost manufacturers of digital and analogue KVM solutions.
For more than 20 years our customers have been convinced by our core competencies in extending, switching and distributing standardised computer signals.

AL-V516P FRONT VIEW AL-V516P REAR VIEW

Saving Cost Plug and Play

15″

15 Inch display (4:3)

Password Protected

We are committed to established international standards. We can provide customers with complete Datacenter solutions as well as OEM/ODM services. We can cover even from medium to small business, factory & industrial, military & government, home office & personal use.

WWW.ANGUSTOS.COM
1309 COFFEEN AVE STE 1200 SHERIDAN, WYOMING 82801 USA

SPECIFICATION

KEYBOARD & MOUSE

Keyboard
Compatible Mouse Mouse Resolution MTBF

104 Keys, Digital & E – Switch Multiple Languages Option Win/Sun/Unix/Linus/Mac Touchpad >1000 dots/inch (40×40/mm) 1,000,000 Press

KVM SWITCH MODULE

Direct PC connection

Maximum PC Connection

256

Port Selection

OSD, Button, Hot Key, IP (Opt)

Console Connector

HDB-15

KVM Connector

HDB-15 Female x 16

Power

DC Jack

Switch button

Panel Digital Keys

Reset Switch

Panel Function Keys

Status LEDs

Nixie Tube (Selected Port)

Red led (Online Port)

Server Interface

PS/2 , USB

Cascadable

Support

CONNECTION DIAGRAM

LCD MONITOR
Size / Ratio Video Visible Square Resolution
Color Contrast Brightness Pixel Pitch MTBF

ANGUSTOS
15″ / 4:3 TFT – LED 409.8 H x 230.4 V 1024 x 768 @ 75Hz (Optimal) 1920 x 1200 @ 60Hz (Max) 16.7 Mil. , True 8 Bit 700 : 1 (TyP) 250 – 400 nit (Optional) 297 x 297 um 100,000 hours

OPERATIONAL SPECIFICATION

Operating Temp

-10oC – 60oC

Storage Temp

-20oC – 70oC

Humidity

0-95%RH, No Condensation

PHYSICAL SPECIFICATION

Housing

Metal

Dimension

528 x 481x 44 mm
