JYL8506A 63.5 Inch Floor Lamp
Product Information
The JYL8506A is a portable lamp with a polarized plug, designed
for safe and easy use. It includes three shelves, made up of top,
middle, and base shelf, along with 12 square tubes, screws, screw
covers, cork, wool mat, wire clip, socket board, shade, and a bulb.
The lamp can use an on/off type A bulb with a maximum of 60-watt or
CFL bulb with a maximum of 13-watt or LED bulb with a maximum of
9-watt.
Product Usage Instructions
Before attempting to install the product, inspect it carefully
to ensure there is no damage or obvious defect. If there is any
damage or defect, do not install it, as the item may not be
returned once it has been installed. Follow the below instructions
for the safe use and installation of the product:
- Unplug lamps before using any cleaning solutions. Dust shades
with a feather duster or an appropriate vacuum-brush attachment.
Wipe with a soft, dry cloth and clean lamp bases with the methods
appropriate to the material. Avoid the use of chemicals and
household cleaners as they may damage the finish. - Make sure you have all parts indicated before you begin
assembly of this item. This item should be assembled on a soft
surface to prevent scratching the finish during assembly. - The external flexible cable or cord of this lamp cannot be
replaced; if the cord is damaged, the lamp shall be destroyed. - This portable lamp has a polarized plug as a safety feature to
reduce the risk of electric shock. This plug will fit in a
polarized outlet only one way. If the plug does not fit fully in
the outlet, reverse the plug. If it still does not fit, contact a
qualified electrician. Never use with an extension cord unless the
plug can be fully inserted. Do not attempt to discard this safety
feature. - Carefully remove all parts from the box and remove all plastic
coverings. Insert 4pcs Middle Square tube(F1) onto the Base shelf
(C) with the screws(G) by the Screwdriver(L) and place the Wool Mat
(N) to cover the screw holes. - Insert 4pcs Middle Square tube(F1) into the 4pcs Middle Square
tube(F2) by the thread-pipe(H) through the Middle shelf(B1). Insert
4pcs Middle Square tube(F2) into the 4pcs Middle Square tube(F3) by
the thread-pipe(H) through the Middle shelf(B2). ENJOY YOUR
LAMP - Insert 4pcs Middle Square tube(F3) into the 4pcs Top Square
tube(E) by the thread-pipe(H) through the Socket board(D). Insert
Top shelf(A) onto the Top Square tube(E) with the screws(G) by the
Screwdriver(L), and place the screw cover (I) to cover the screw
holes. - Insert the 4pcs Cork(M) into the Socket board(D) holes. Put the
Shade (J) onto the Socket board(D). Insert the bulb(K) into the
Socket board(D).
WARNING INSPECT ITEM CAREFULLY BEFORE ATTEMPTING TO INSTALL. IF THERE IS ANY DAMAGE OR OBVIOUS DEFECT, DO NOT INSTALL. ITEM MAY NOT BE RETURNED ONCE IT HAS BEEN INSTALLED.
CARE AND MAINTENANCE Unplug lamps before using any cleaning solutions. Dust shades with a feather duster or with an appropriate vacuum-brush attachment. Wipe with a soft, dry cloth and clean lamp bases with the methods appropriate to the material. Avoid the use of chemicals and household cleaners as they may damage the finish.
NOTICE& IMPORTANT SAFETY INSTRUCTIONS * Please make sure that you have all parts indicated before you begin assembly of this item * This item should be assembled on a soft surface to prevent scratching the finish during assembly * To reduce the risk of fire, electrical shock or injury to persons or property, please follow the guideline below for safe use and installation *The external flexible cable or cord of this lamp cannot be replaced; If the cord is damaged, the lamp shall be destroyed
**This portable lamp has a polarized plug (one blade is wider than the other) as a safety feature to reduce the risk of electric shock. this plug will fit in a polarized outlet only one way. if the plug does not fit fully in the outlet, reverse the plug, if it still does not fit, contact a qualified electrician. Never use with an extension cord unless the plug can be fully inserted. do not attempt to disgard this safety feature.
Part List and Hardware List
PIECE DESCRIPTION PICTURE QUANTITY PIECE DESCRIPTION PICTURE QUANTITY
A
Top shelf
1X
I
screw cover
4X
B
Middle shelf
2X
J
Shade
1X
C
Base shelf
1X
K
Bulb
1X
D Socket board
1X
L
Screwdriver
1X
E
Top Square tube
4X
M
Cork
4X
F
Middle Square tube
12X
N
Wool Mat
4X
G
screws
8X
O
Wire clip
3X
H
thread-pipe
12X
Model# JYL8506A Product Dimensions: 10.25″Lx 10.25″W x 63.5″H
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Assembly Time: 6 minutes.
PLEASE USE ON/OFF TYPE”A” BULB MAX 60-WATT OR CFL BULB MAX 13-WATT OR LED BULB MAX 9-WATT THERE IS LED 9.5-WATT BULB IN THE BOX
1
2
3
Step 1 Carefully remove all parts from the box and remove all plastic coverings. Refer to Diagram 1: innsert 4pcs Middle Square tube(F1) onto the Base shelf (C) with the screws(G)by the Screwdriver(L) and place the Wool Mat (N) to cover the screw holes.
Refer to Diagram 2: insert 4pcs Middle Square tube(F1) into the 4pcs Middle Square tube(F2) by the thread-pipe(H) through the Middle shelf(B1).
Insert 4pcs Middle Square tube(F2) into the 4pcs Middle Square tube(F3) by the thread-pipe(H) through the Middle shelf(B2). ENJOY YOUR LAMP
Step 2 Insert 4pcs Middle Square tube(F3) into the 4pcs Top Square tube(E) by the thread-pipe(H) through the Socket board(D)
Insert Top shelf(A) onto the Top Square tube(E)with the screws(G) by the Screwdriver(L),and place the screw cover (I) to cover the screw holes.
Step 3 Insert the 4pcs Cork(M) into the Socket board(D) holes Put the the Shade (J) onto the Socket board(D) Insert the bulb(K) into the Socket board(D).
Step 3 Put the light on a level surface to check if everything is stable.
Insert 3pcs Wire Clip (O) onto the Square tube(F1-F2-F3)
Insert the wire into the Wire Clip (O), Secure the wire and prevent tripping
