JYL3093A Tavira LED Floor Lamp
Product Information: – Model: JYL3093A – Product Dimensions:
15L x 15W x 62.5H – Maximum Bulb Wattage: – On/Off Type A Bulb: Max
100-Watt – CFL Bulb: Max 23-Watt – LED Bulb: Max 12-Watt Product
Usage Instructions: Preparation: 1. Before starting
assembly, ensure that all parts are present and undamaged. 2.
Compare the parts with the package contents list and hardware
contents list. 3. If any part is missing or damaged, do not proceed
with assembly. Estimated Assembly Time: 15 minutes. Step 1:
1. Make sure all parts are aligned properly before assembling. 2.
Avoid rotating the lamp body too hard to prevent base screw
breakage. 3. Screw the Lamp body (B1) onto the Lamp base (A). 4.
Screw the Lamp body (B2) onto the Lamp body (B1). 5. Screw the Lamp
assembly (D) onto the Lamp body (C). 6. Screw the Lamp body (C)
onto the Lamp body (B2). 7. Take care not to twist the power cord
and tighten all screws securely. Step 2: 1. Insert the harp
(G) into the saddle (E). 2. Place the shade (H) on the harp (G) and
then tighten the finial (I) into the harp (G). 3. Insert the bulb
(J) into the socket (F). Step 3: 1. Place the lamp on a
level surface to ensure stability. Enjoy your lamp!
WARNING
INSPECT ITEM CAREFULLY BEFORE ATTEMPTING TO INSTALL. IF THERE IS ANY DAMAGE OR OBVIOUS DEFECT, DO NOT INSTALL. ITEM MAY NOT BE RETURNED ONCE IT HAS BEEN INSTALLED.
CARE AND MAINTENANCE Unplug lamps before using any cleaning solutions. Dust shades with a feather duster or with an appropriate vacuum-brush attachment. Wipe with a soft, dry cloth and clean lamp bases with the methods appropriate to the material. Avoid the use of chemicals and household cleaners as they may damage the finish.
NOTICE& IMPORTANT SAFETY INSTRUCTIONS
* Please make sure that you have all parts indicated before you begin assembly of this item * This item should be assembled on a soft surface to prevent scratching the finish during assembly * To reduce the risk of fire, electrical shock or injury to persons or property, please follow the guideline below for safe use and installation *The external flexible cable or cord of this lamp cannot be replaced; If the cord is damaged, the lamp shall be destroyed
**This portable lamp has a polarized plug (one blade is wider than the other) as a safety feature to reduce the risk of electric shock. this plug will fit in a polarized outlet only one way. if the plug does not fit fully in the outlet, reverse the plug, if it still does not fit, contact a qualified electrician. Never use with an extension cord unless the plug can be fully inserted. do not attempt to disregard this safety feature.
Part List and Hardware List
PIECE DESCRIPTION PICTURE QUANTITY PIECE DESCRIPTION PICTURE QUANTITY
A
Lamp base
1X
F
Socket
1X
B1
Lamp Body
1X
G
Harp
1X
B2
Lamp Body
1X
H
Shade
1X
C
Lamp Body
1X
I
Finial
1X
D
Socket Assembly
1X
J
Bulbs
1X
E
Saddle
1X
Model# JYL3093A Product Dimensions: 15″L X 15″W X 62.5″H
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Assembly Time: 15 minutes.
PLEASE USE ON/OFF TYPE”A” BULB MAX 100-WATT OR CFL BULB MAX 23-WATT OR LED BULB MAX 12-WATT THERE IS LED 9-WATT BULB IN THE BOX
Step 1 Make sure all parts could be aligned before assemble Do not rotate lamp body too hard avoid base screw broken Screw the Lamp body (B1) onto the Lamp base(A) Screw the Lamp body (B2) onto the Lamp body (B1) Screw the Lamp assembly (D) onto the Lamp body(C) Screw the Lamp body (C) onto the Lamp body(B2) Be careful not to twist the power cord and tighten securely
ENJOY YOUR LAMP
Step 2 Insert the harp (G) into the saddle (E). Put the shade(H) on the harp(G) ,then tighten the finial (I) into the harp (G) Insert the bulb(J) into the socket(F).
Step 3 Put the light on a level surface to check if everything is stable.
