GALCO RSCG060696G RSCG Series Wiegmann Enclosures
GALCO RSCG060696G RSCG Series Wiegmann Enclosures
By Wiegmann
Catalog ID: RSCG060696G
- Prop 65 – Cancer & Reproductive Harm Notice NEMA 3R Gutter 6X6X96 Carbon Steel – Galvanized Designed to protect wiring in outdoor installations against rain, sleet and snow or indoors against dripping water.
- Trough and cover are fabricated from galvanized steel
- Drip shield prevents rain, snow and sleet from entering the enclosure
- Mounting holes are located on the back of the enclosure
- Slip-on removable cover is securely fastened with screws located along the bottom edge
- Knockouts are located on the bottom of the enclosure
Product Details
General
- Color Gray
- Cover Type Screw Cover
- EU RoHS Indicator No
- Finish Type Galvanized
- Knockouts Yes
- Material Stee
- Mounting Type Wall Mount
- Series RSCG
- Type Gutter
- UPC 786725884209
Dimensions
- Actual Depth 6.06 in
- Actual Height 6.06 in
- Actual Width 96.13 in
- Depth 6 in
- Height 6 in
- Width 96 in
Conductor Related
- Cable Entry Knock Outs
- Certifications and Compliance
- Certified Listed cULus
- Nema Rating 1, 3R
Logistics
- Carton Quantity 4
