NE63CB831512 Smart Slide In Electric Range with Air Fry and Convection
Product Information
The Samsung Front Control Slide-in Electric Range with Air Fry
and Convection is a smart appliance that is fully Wi-Fi connected
and voice enabled, making it easy to create delicious meals for
your family fast. The range is available in two finishes: Bespoke
White Glass and Fingerprint Resistant Stainless Steel.
Features and Benefits
- Air Fry technology allows you to make healthier meals with less
oil - Convection technology ensures even cooking and baking
results - Wi-Fi connectivity and voice control enable you to control the
range with your smartphone or voice assistants like Amazon Alexa
and Google Assistant - The SmartThings app allows you to monitor and control the range
from anywhere - The slide-in design gives a sleek, built-in look
- The range has a large 6.3 cu. ft. oven capacity, five cooktop
burners, and a warming drawer
Product Specs
The NE63**8315 range has the following specifications:
- Oven capacity: 6.3 cu. ft.
- Cooktop burners: 5
- Warming drawer: yes
- Air Fry function: yes
- Convection technology: yes
- Wi-Fi connectivity: yes
- Voice control: yes
- Dimensions (WxHxD): 29 15/16″ x 36″ – 37 1/8″ x 28 11/16″
Product Usage Instructions
Before using the range for the first time, refer to the user
manual and warranty information provided with the product.
Connecting to Wi-Fi
To connect the range to Wi-Fi, follow these steps:
- Download and install the SmartThings app on your
smartphone - Open the app and tap “Add Device”
- Select “Appliances” and then “Range”
- Follow the on-screen instructions to connect the range to your
home Wi-Fi network
Using Air Fry
To use the Air Fry function, follow these steps:
- Press the “Air Fry” button on the control panel
- Select the desired temperature and cooking time using the “+”
and “-” buttons - Press “Start” to begin cooking
- When the cooking is complete, remove the food from the oven
using oven mitts or pot holders
Using Convection Cooking
To use the convection cooking feature, follow these steps:
- Select the desired cooking mode (Bake, Broil, etc.) on the
control panel - Press the “Convection” button to activate convection
cooking - Select the desired temperature and cooking time using the “+”
and “-” buttons - Press “Start” to begin cooking
- When the cooking is complete, remove the food from the oven
using oven mitts or pot holders
Cleaning and Maintenance
Refer to the user manual for instructions on cleaning and
maintaining the range. Some tips include:
- Wipe up spills and splatters as soon as possible to prevent
them from hardening and becoming difficult to remove - Clean the oven regularly using the self-clean function
- Remove and clean the oven racks separately
- Clean the cooktop regularly using a non-abrasive cleaner
Product Guide
6.3 cu. ft. Smart Slide-in Electric Range with Air Fry & Convection
NE63**8315
Available in: Bespoke White Glass Fingerprint Resistant Stainless Steel
Easy Ads Links
Bespoke White Glass: https://dam.gettyimages.com/p/z0c3461/digital-appliances?o=AND&q=NE63CB831512 Fingerprint Resistant Stainless Steel: https://dam.gettyimages.com/p/z0c3461/digital-appliances?o=AND&q=NE63BG8315SS
Samsung proprietary and confidential
8315 Range Product Guide
Table of Contents
NE63**8315 – 6.3 cu. ft. Smart Slide-in Electric Range with Air Fry & Convection
Product Overview
Product Overview
4
Carousel Image Order
5
Product Messaging
Features and Benefits
8
Lifestyle Images
14
Product Videos
16
Product Specs
Related Products
18
Spec Sheet
19
User Manual and Warranty Information
20
Feature Icons
22
2
Samsung proprietary and confidential
Product Overview
NE63**8315 6.3 cu. ft. Smart Slide-in Electric Range with Air Fry & Convection
Samsung proprietary and confidential
8315 Range Product Guide
Product Overview
Product Title 6.3 cu. ft. Smart Slide-in Electric Range with Air Fry & Convection in Bespoke White Glass
Product Description (Paragraph) The Samsung Front Control Slide-in Electric Range with Air Fry and Convection is fully Wi-Fi connected and voice enabled, making it easy to create delicious meals for your family fast. Create a kitchen that expresses your personal style with Bespoke appliances. This range is available in Bespoke White Glass to complement other Bespoke appliances.
Product Description (Bullets) · The Samsung Front Control Slide-in Electric Range includes Air Fry and Convection. · Fully Wi-Fi connected and voice enabled, making it easy to create delicious meals for your family fast. · Create a kitchen that expresses your personal style with Bespoke appliances. This range is available in
Bespoke White Glass to complement other Bespoke appliances.
Product Title 6.3 cu. ft. Smart Slide-in Electric Range with Air Fry & Convection in Fingerprint Resistant Stainless Steel
Product Description (Paragraph) The Samsung Front Control Slide-in Electric Range with Air Fry and Convection is fully Wi-Fi connected and voice enabled, making it easy to create delicious meals for your family fast.
Product Description (Bullets) · The Samsung Front Control Slide-in Electric Range includes Air Fry and Convection. · Fully Wi-Fi connected and voice enabled, making it easy to create delicious meals for your
family fast.
Available Colors
Bespoke White Glass NE63CB831512
Fingerprint Resistant Stainless Steel NE63BG8315SS
Note: Bespoke White Glass is a new SKU that requires product set-up. Stainless Steel has already been set up.
Range: Overview | Messaging | Specs | Icons
4
Samsung proprietary and confidential
8315 Range Product Guide
Carousel Image Order
Bespoke White Glass
1
2
3
4
Can be used in carousel until September 30, 2023.
Available in fractions and decimals.
6
7
8
9
11
Range: Overview | Messaging | Specs | Icons
5
5
10
NOTE: There is an additional asset available on Easyads that is a lock-up of the product image and Bespoke warranty badge that can be used for carousel #2.
Samsung proprietary and confidential
8315 Range Product Guide
Carousel Image Order
Stainless Steel
1
2
3
Available in fractions and decimals.
6
7
8
6
4
5
9
10
Range: Overview | Messaging | Specs | Icons
Samsung proprietary and confidential
Product Messaging
NE63**8315 6.3 cu. ft. Smart Slide-in Electric Range with Air Fry & Convection
Samsung proprietary and confidential
8315 Range Product Guide
Features and Benefits NE63**8315
Overall Product Headline
Feature Name
Long Body Copy
Short Body Copy
8
Associated Image
Designed by you, for you
Bespoke Design
Create a kitchen that expresses your personal style with Bespoke appliances. This range is available in Bespoke White Glass to complement other Bespoke appliances. Whether you prefer to match, complement or contrast – the choice is yours.
This range is available in Bespoke White Glass to complement other Bespoke appliances. Whether you prefer to match, complement or contrast the choice is yours.
Note: Available only on NE63CB831512 When Bespoke model is being promoted, Bespoke Design
should be the first feature listed.
Healthier cooking with a crunch*
*As compared to deep frying. Air Fry tray sold separately.
Air Fry
Cooking just got healthier with Air Fry mode.* Using little to no oil, you can quickly prepare your favorite fried foods right in your oven.
*As compared to deep frying. Air Fry tray sold separately.
Use Air Fry in your oven to prepare healthier fried foods using little to no oil.*
*As compared to deep frying. Air Fry tray sold separately.
Cooking with a personalized touch
SmartThings Cooking
One simple-to-use app that searches recipes and sends cooking instructions to your oven, provides meal monitoring status, and so much more.
*SmartThings App available on Android and iOS devices. Wi-Fi connection and Samsung account required. Product experience may vary; for full product capabilities see individual model product page on s.com.
One simple-to-use app that searches recipes and sends cooking instructions to your oven, provides meal monitoring status, and so much more.*
*SmartThings App available on Android and iOS devices. Wi-Fi connection and Samsung account required. Product experience may vary; for full product capabilities see individual model product page on s.com.
Range: Overview | Messaging | Specs | Icons
Samsung proprietary and confidential
8315 Range Product Guide
Features and Benefits NE63**8315 (continued)
Overall Product Headline
Feature Name
Long Body Copy
9
Short Body Copy
Associated Image
Save time with convection
Convection
Powerful convection saves you time by cooking food Cooks food fast and more fast and more evenly. Perfect for baking and roasting. evenly.
All shine Flexible in every way
Fingerprint Resistant Finish
Fingerprint resistant,* for an everyday beautiful finish.
*Bespoke White Glass finish is not fingerprint resistant.
Fingerprint resistant,* beautiful finish.
*Bespoke White Glass finish is not fingerprint resistant.
NOTE: Feature should only be used for Stainless Steel finish.
Flexible Cooktop
Get to high heat quickly for searing meat or boiling water, or turn down to a simmer to make your favorite sauces. The cooktop has 5 burners including 2 dual ring burners, so you can cook with multiple sized pots and pans.
Get to high heat quickly for searing meat or boiling water, or turn down to a simmer to make your favorite sauces.
Range: Overview | Messaging | Specs | Icons
Samsung proprietary and confidential
8315 Range Product Guide
Features and Benefits NE63**8315 (continued)
Overall Product Headline
Feature Name
Long Body Copy
10
Short Body Copy
Associated Image
Cook enough for the whole crew
Large Oven Capacity
This large 6.3 cu. ft. oven fits multiple meals at one time, and it can easily accommodate big casserole
dishes or roasting pans.
This large 6.3 cu. ft. oven
fits multiple meals at one time.
Cook smart, save time
Wi-Fi Connectivity
“Preheat the oven to 350° please”
Voice Control
Range: Overview | Messaging | Specs | Icons
Preheat, monitor, and adjust cook time and temperature of your oven, right from your smartphone through the SmartThings App.*
*Available on Android and iOS devices. A Wi-Fi connection and a Samsung account are required.
Preheat, monitor, and adjust cook time and temperature of your oven through the SmartThings App.*
*Available on Android and iOS devices. A Wi-Fi connection and a Samsung account are required.
Control your oven by voice when you’re busy doing other things by using your favorite voice assistant, whether it’s Bixby, Alexa or Google.*
*Available on Android & iOS devices. A Wi-Fi connection and a Samsung account are required. Bixby is Samsung’s brand of Artificial intelligence (AI). Amazon Alexa and all related logos are trademarks of Amazon.com, Inc. or its affiliates. Google is a trademark of Google LLC.
Control your oven by voice by using your favorite voice assistant, whether it’s Bixby, Alexa or Google.*
*Available on Android & iOS devices. A Wi-Fi connection and a Samsung account are required. Bixby is Samsung’s brand of Artificial intelligence (AI). Amazon Alexa and all related logos are trademarks of Amazon.com, Inc. or its affiliates. Google is a trademark of Google LLC.
Samsung proprietary and confidential
8315 Range Product Guide
Features and Benefits NE63**8315 (continued)
Overall Product Headline
Feature Name
Long Body Copy
Short Body Copy
11
Associated Image
Easy to clean
Glass Touch Controls
Glass Touch Controls offer a premium design that is easy to use and clean.
Touch Controls offer a premium design that is easy to use and clean.
Does the hard work for you
Self & Steam Clean
Get help from your oven with Self & Steam Clean. The self cleaning system deep cleans by heating to a high temperature to burn off grease and food residue. Steam clean in 20 minutes for easier cleaning jobs.
Get help from your oven with Self & Steam Clean.
Cleaning is seamless
Hidden Bake Element
The bake element hidden under the ceramic enamel surface at the bottom of the oven provides a seamless cavity that makes cleaning easy.
The seamless interior makes cleaning your oven easy.
Range: Overview | Messaging | Specs | Icons
Samsung proprietary and confidential
8315 Range Product Guide
12
Features and Benefits NE63**8315 (continued)
Overall Product Headline
Feature Name
Long Body Copy
Short Body Copy
Associated Image
Samsung Bespoke appliances
Samsung Bespoke appliances come with an additional come with an extended
year of manufacturer’s warranty. Have confidence
warranty for 2 years of
you’re covered for 2 years on parts and labor.* Bespoke Extended Warranty
coverage.*
*Purchase date of eligible models must be between 10/1/20229/30/2023; proof of purchase
*Purchase date of eligible models must be between
required. For full warranty terms and conditions for specific models, see individual model
10/1/20229/30/2023; proof of purchase required.
product page on Samsung.com.
For full warranty terms and conditions for specific
models, see individual model product page on
Samsung.com.
Range: Overview | Messaging | Specs | Icons
Samsung proprietary and confidential
Lifestyle Images
NE63**8315 6.3 cu. ft. Smart Slide-in Electric Range with Air Fry & Convection
Samsung proprietary and confidential
8315 Range Product Guide
Lifestyle Images
Bespoke White Glass
Stainless Steel
Range: Overview | Messaging | Specs | Icons
14
Samsung proprietary and confidential
Product Videos
NE63**8315 6.3 cu. ft. Smart Slide-in Electric Range with Air Fry & Convection
Samsung proprietary and confidential
8315 Range Product Guide
16
Product Videos
FPO
Air Fry
Ready2FitTM
Self & Steam Clean
Range: Overview | Messaging | Specs | Icons
Samsung proprietary and confidential
Product Specs
NE63**8315 6.3 cu. ft. Smart Slide-in Electric Range with Air Fry & Convection
Samsung proprietary and confidential
8315 Range Product Guide
Related Products
COLOR
PRODUCT
MODEL
Bespoke White Glass
29 cu. ft. Smart Bespoke 4-Door FlexTM Refrigerator with Customizable Panel Colors
23 cu. ft. Smart Counter Depth Bespoke 4-Door FlexTM Refrigerator with Customizable Panel Colors
Bespoke 4-Door FlexTM Refrigerator Panel in Bespoke White Glass – Top Panel
Bespoke 4-Door FlexTM Refrigerator Panel in Bespoke White Glass – Bottom Panel
Smart Bespoke Dishwasher with StormWash+TM 42dBA with Smart Dry
2.1 cu. ft. Capacity Bespoke Over-the-Range Microwave in Bespoke White Glass
RF29A9675AP* RF23A9675AP* RA-F18DUU35 RA-F18DBB35 DW80BB707012 ME21B706B12
COLOR
PRODUCT
MODEL
Fingerprint Resistant Stainless Steel
29 cu. ft. Smart Bespoke 4-Door FlexTM Refrigerator with Customizable Panel Colors
23 cu. ft. Smart Counter Depth Bespoke 4-Door FlexTM Refrigerator with Customizable Panel Colors
Bespoke 4-Door FlexTM Refrigerator Panel in Fingerprint Resistant Stainless Steel – Top Panel
Bespoke 4-Door FlexTM Refrigerator Panel in Fingerprint Resistant Stainless Steel – Bottom Panel
Smart Bespoke Linear Wash 39dBA Dishwasher in Fingerprint Resistant Stainless Steel
2.1 cu. ft. Capacity Bespoke Over-the-Range Microwave in Fingerprint Resistant Stainless Steel
RF29A9675AP* RF23A9675AP* RA-F18DUUQL RA-F18DBBQL DW80R9950US ME21A706BAS
Range: Overview | Messaging | Specs | Icons
Accessories
SKU
Description
NX-AB5900RS/AA NX-AB5400RS/AA NX-AF5000RS/AA
NX-AA5000RS
9″ backguard for 30″ slide-in range 4″ backguard for 30″ slide-in range Trim kit for 30″ slide-in range, 5 piece Air Fry Tray Accessory for 30″ Ranges
18
Color(s) Stainless Steel
Samsung proprietary and confidential
8315 Range Product Guide
Spec Sheet
NE63**8315
6.3 cu. ft. Smart Slide-in Electric Range with Air Fry & Convection
Signature Features
Air Fry · Cooking just got healthier with Air Fry mode.* Using little to no oil,
you can quickly prepare your favorite fried foods right in your oven.
*As compared to deep frying. Air Fry tray sold separately.
Convection · Powerful Convection saves you time by cooking food fast and more evenly.
Perfect for baking and roasting. Ready2FitTM Guarantee · If your Samsung Front Control Slide-In Range doesn’t fit your 30″ Freestanding
Range cutout, enjoy $100* on us to cover any countertop modification costs.
*Visit https://promos.samsung.com/slideinready2fit for details.
Available Colors
White Glass
Fingerprint Resistant Stainless Steel (shown)
Features
· Air Fry Tray Not Included · Convection · Ready2FitTM Guarantee · Fingerprint Resistant Finish · Large Oven Capacity 6.3 cu. ft. · Glass Touch Controls · Storage Drawer
Air Fry Tray Not Included
Convection
· Flexible Cooktop: Five Element Cooktop – Two Dual Elements (6″/9″ and 9″/12″) – Two Single Elements (6″) – Warming Center
Convenience
· Wi-Fi Connectivity · Voice-Enabled · Convection Auto Conversion · Self & Steam Clean · Hidden Bake Element · Child Safety Lock · Delay Start · Auto Oven Light · Kitchen Timer · Sabbath Mode
Spec Sheet – front
NE63**8315
6.3 cu. ft. Smart Slide-in Electric Range with Air Fry & Convection
Installing Your Range
36″-363/4″ 2915/16″
293/4″ 2811/16″
3″
24″
25″
3″
24″
357/8″
6″
B
A
26 7 /16″ 491/4″
A: Cabinet opening min 30″ B: Acceptable electrical outlet area
IMPORTANT: If your cabinets are over 363/4″ high, you must install this range on a hard, heat resistant support that raises the surface of the range so that it is about even with the countertop.
** 15″
30″ * 30″
* 30″ minimum clearance between the top of the cooking surface and the bottom of an unprotected wood or metal cabinet; or 24″ minimum when the bottom of the wood or metal cabinet is protected by not less than ¼” of flame retardant millboard covered with not less than no.28 MSG sheet steel, 0.015″ stainless steel, 0.024″ aluminum, or 0.020″ copper.
**15″ minimum between the countertop and the adjacent cabinet bottom.
IMPORTANT: Consult with Installation Manual for detailed instructions before installing. All ranges must be installed with the Anti-Tip device that is included.
/
/
Power Source 240V/208V/60 Hz/40A
Electric Ceramic Cooktop · Right Front: 9″/12″ Dual Element, 3000 W · Left Front: 6″/9″ Dual Element, 3000 W · Right Rear: 6″, 1200 W · Left Rear: 6″, 1200 W · Center: 7″ Warming Center
Oven · Capacity: 6.3 cu. ft. · Convection Bake · Convection Roast · Bake · Air Fry · Variable Broil: Low/High · Bread Proof
Warranty One (1) Year Parts and Labor
White Glass Model Only: Two (2) Years Parts and Labor*
*Effective for purchases made between 10/1/22 – 9/30/23; proof of purchase required.
Product Dimensions & Weight (WxHxD) Oven Interior Dimensions: 24 13/16″ x 22 7/16″ x 19 3/4″
Outside Net Dimensions: 29 15/16″ x 36 – 363/4″ (Adjustable) x 28 11/16″
Weight: 171.5 lbs
Shipping Dimensions & Weight (WxHxD) Dimensions: 33 1/16″ x 41 3/4″ x 30 5/16″
Weight: 194.4 lbs
Standard Finishes Model #
UPC Code
Fingerprint Resistant Stainless Steel
NE63BG8315SS 887276712468
/ Bespoke F/ inishes White Glass
NE63CB831512 887276744278
/
/ /
Actual color may vary. Design, specifications, and color availability are subject to change without notice. Non-metric weights and measurements are approximate.
©2022 Samsung Electronics America, Inc. 85 Challenger Road, Ridgefield Park, NJ 07660. Tel: 800-SAMSUNG. samsung.com. Samsung is a registered trademark of Samsung Electronics Co. Ltd.
Ready2FitTM
Spec Sheet – back
Range: Overview | Messaging | Specs | Icons
19
Samsung proprietary and confidential
8315 Range Product Guide
User Manual & Warranty
User Manual
1-Year Warranty
Range: Overview | Messaging | Specs | Icons
20
2-Year Extended Limited Warranty Addendum to LIMITED WARRANTY TO ORIGINAL CONSUMER PURCHASER WITH PROOF OF PURCHASE This is an addendum to the Limited Warranty to Original Consumer Purchaser with Proof of Purchase (“Limited Warranty”) for the Samsung Range models listed below (“Addendum”). A copy of your Limited Warranty is available at samsung.com on the product page for your model and in the user manual. Notwithstanding any terms in the Limited Warranty to the contrary, this Addendum modifies and supplements the Limited Warranty as follows: for ranges purchased between October 1, 2022 and September 30, 2023, the range is warranted by SAMSUNG against manufacturing defects in materials or workmanship for the limited warranty period of 2 years parts and labor. All other terms, conditions, and limitations in the Limited Warranty apply, including the limitation on implied warranties (where permitted by law). If there is a conflict between this Addendum and the Limited Warranty, the provisions of this Addendum will control and the Limited Warranty will be construed accordingly. Together this Addendum and the Limited Warranty contain the entire manufacturer’s warranty for your product. Eligible Models Purchased Between October 1, 2022 and September 30, 2023:
NE63A8711QN/AA NE63T8511ST/AA NE63T8711ST/AA NX60A8711QN/AA NX60T8511ST/AA NX60T8711ST/AA NE63BB861112AA NE63BB871112AA NE63BB851112AA NX60BB871112AA NX60BB851112AA NE63CB831512AA NX60CB831512AA
2-Year Bespoke Home Warranty*
*Bespoke White Glass finish only.
Samsung proprietary and confidential
Feature Icons
NE63**8315 6.3 cu. ft. Smart Slide-in Electric Range with Air Fry & Convection
Samsung proprietary and confidential
8315 Range Product Guide
22
Feature Icons
Slide-In Design
Air Fry
Wi-Fi Connectivity
SmartThings
Convection
2-Year Bespoke Warranty*
*Bespoke White Glass finish only.
Range: Overview | Messaging | Specs | Icons
Samsung proprietary and confidential
Amazon.com. Spend less. Smile more.
Samsung US | Mobile | TV | Home Electronics | Home Appliances | Samsung US
Private Library![Samsung Front Control Slide-in Electric Range With Air Fry [ne63t8511ss] User Manual](https://static-data1.manualsee.com/1/img/335/18027/2020/12/00-96.jpg "Samsung Front Control Slide-in Electric Range With Air Fry [ne63t8511ss] User Manual")
![Samsung Front Control Slide-in Electric Range With Smart Dial & Air Fry [ne63t8711ss] User Manual](https://static-data1.manualsee.com/1/img/343/18039/2020/12/00-98.jpg "Samsung Front Control Slide-in Electric Range With Smart Dial & Air Fry [ne63t8711ss] User Manual")
![Samsung Front Control Slide-in Electric Range With Convectio [ne63t8311ss] User Manual](https://static-data1.manualsee.com/1/img/338/18032/2020/12/Samsung-Front-Control-Slide-in-Electric-Range-with-Convectio-NE63T8311SS-featured.png "Samsung Front Control Slide-in Electric Range With Convectio [ne63t8311ss] User Manual")
