Creality Cl-89l 3d-printers User Manual (+ PDF)

Children under 10 years should not use the printer without
supervision.
Do not plug or unplug the power cord when the printer is
powered on.
Comply with the laws and regulations of the corresponding
countries and regions where the equipment is located (used).
Abide by professional ethics and pay attention to safety
obligations.
Strictly prohibit the use of the product or equipment for any
illegal purposes.
Creality will not be responsible for any violators’ legal
liability under any circumstance.

4. Package Contents

The HALOT-LITE 3D Printer package includes the following:

Print platform x 1
Resin vat x 1
3D printer x 1
U disk x 1
Resin filter x 4
Screwdrivers x 1 set
Release film x 1
Vat cover x 1
Calibration card x 1
Brush x 1
Metal blade x 1
Plastic blade x 1
Power cord x 1

5. Leveling the Platform

To level the printing platform, follow these steps:

Raise the platform and loosen the fixing screws on the left and
right sides of the material trough. Remove the material
trough.
Loosen the four leveling screws of the prototyping
platform.
Attach the calibration card tightly to the print screen and go
to Settings -> Z Axis Motion -> Levelling. Follow the
operating steps for leveling the platform.
Check whether the platform fits evenly with the paper using the
calibration card.
If the calibration card fits evenly with the platform, screw up
the four screws of the platform.

View Fullscreen

CREATE REALITYACHIEVE DREAMS
HALOT-LITE
HALOT-LITE
3D Printer User Manual
V1.4

Dear Consumers, Thank you for choosing our products.For the best experience,please read the instructions before operating the Printer. Our teams will always be ready to render you the best services. Please contact us via the phone number or e-mail address provided at the end when you encounter any problem with the Printer. For a better experience in using our product, you can also learn how to use the printer in the following ways: View the accompanied instructions and videos in the U disk. Visit our official website www.creality.com to find relevant software/hardware information,contact details and operation and maintenance instructions.
Firmware Upgrade Please login the official website https://www.creality.com/download, switch the language and select the relevant printer and model and download the required firmware, you can use it after the installation is finished.

NOTES
1 Do not use the printer any way other than described here in order to avoid personal injury or property damage. 2 Do not place the printer near any heat source or flammable or explosive objects. We suggest placing it in a well-ventilated, low-dust environment. 3 Do not expose the printer to violent vibration or any unstable environment, as this may cause poor print quality. 4 Please use recommended resin to in case damage of machine. 5 Do not use any other power cable except the one supplied. Always use a grounded three-prong power outlet. 6 Please do not open the plastic cover during usage, otherwise the printing will be interrupted. 7 Do not wear cotton gloves when operating the printer. Such cloths may become tangled in the printers moving parts leading to burns, possible bodily injury, or printer damage. 8 Please wait a moment after the print is finished. And please wear gloves to take out the print by tools. 9 Clean the printer frequently. Always turn the power off when cleaning, and wipe with a dry cloth to remove dust, adhered printing plastics or any other material off the frame,
guide rails, or wheels. Use glass cleaner or isopropyl alcohol to clean the print surface. 10 Children under 10 years should not use the printer without supervision. 11 TipsDo not plug or unplug the power cord when power on. 12 Users should comply with the laws and regulations of the corresponding countries and regions where the equipment is located (used), abide by professional ethics, pay attention to safety
obligations, and strictly prohibit the use of our products or equipment for any illegal purposes. Creality will not be responsible for any violators’ legal liability under any circustance.

Contents
Introduction Parameters Parts List Use the 3D Printer Start Printing Control remote printing Wiring Connection Troubleshooting

01-01 02-02 03-03 04-09 10-12 13-13 14-14 15-17

1. Introduction

1 Protective cover 2 Limit switch 3 Hexalobular socket screw 4 Leveling screw

1
2
3 4 5
6 7 8 9
10

5 Buliding platform 6 Hexalobular socket screw 7 Resin vat 8 Touch screen

9 USB port 10 Power socket

2.Equipment parameters
Model Name Build Size XY Axis Resolution XY Axis Accuracy Print speed Layer Thickness Touch Screen Light Source Type Rated Voltage Rated Power Machine Size Package size Net Weight Gross Weight Print Method Machine Language Slicing Software Operation System Compatible Resin
02

Basic Parameters
HALOT-LITE 192*120*200mmlength,width and height 3840*2400 0.05mm 1-4S/layer 0.01-0.2mm 5 inch touch screen Integral light source (wavelength 405nm) 100-240Va.c, 50/60Hz 250W 330*301*572mm 425*393*685mm 10.6KG 13.5KG USB Disk, Creality Cloud (/)/ English/ Español/ Deutsche/ Français/ P/ Português/ Italiano/ Türk/Nederlands/Polskie// Win7/Win8/Win 10 64bit, Mac system (32-bit is not supported) Common rigid photosensivie resin, Standard resin, Hight hardness,High toughness, Dental model resin.

3. Package Content

Print platform x 1

Resin vat x 1

3D printer x 1

1 U disk x 1 5 Resin filter x 4

Tool list
2 Screwdrivers x 1set 6 Release film x 1

9 Vat cover x 1

Calibration Card

10 Calibration card x 1

Tips: the above accessories are for reference only, in kind prevail!

3 Brush x 1 7 Metal blade x 1

4 Plastic blade x 1 8 Power cord x 1

4. Interface Information
Print
Note: The current interface is for reference only, due to the continuous upgrading of functions, the actual to the official website of the latest firmware UI as the standard.
04

4. Interface Information
Setting
Note: The current interface is for reference only, due to the continuous upgrading of functions, the actual to the official website of the latest firmware UI as the standard. 05

5. Level Platform
Note: The printing platform has been leveled at the factory. If it needs leveling due to transportation or other reasons, please follow the steps below to adjust the printing platform.

1. To calibrate the printing platform, first raise the platform, loosen the fixing screws on the left and right sides of the material trough, and take out the material trough;

2. Loosen the four Leveling screw of the prototyping platform, attach Calibration card tightly to the print screen, press Settings Z Axis Motion LevellingRefer to operating steps of levelling platform 2 for operation., to check whether the platform fits evenly with the paper.

3. After confirming that Calibration card fits evenly with the platform, screw up the four screws of the platform.

5. Level Platform
Note: The current interface is for reference only, due to the continuous upgrading of functions, the actual to the official website of the latest firmware UI as the standard. 07

6. Load Resin
Pour the UV photosensitive resin into the resin vat. The slot capacity is 500ml/1000ml.

MAX MAX

LEVEL LEVEL

1000ML 500ML

1000ml 500ml

TipsHow to change resin: Take out the resin vat slowly, pour out the remaining resin into the container, clean the resin vat, pour in new resin, and then install the resin vat to the machine.

Caution Resin may cause skin irritation or an allergic skin reaction. Please wear gloves before use to avoid direct contact with the skin.

7. Release Film Instructions
a. b. c.

Installation steps
a. First, remove the 14 screws at the bottom of the vat and take down the old release film.
b. Prepare the new release film, peel off the the protective films on both sides of the release film. Align the holes and fit the release film on the clamping ring.
c. Finally, place the film-ring assembly back into the vat frame gently, then intall and tighten the fixing screws diagonally.
d. The installed release film is as shown.
d.

Parameters
190mm*266mm (Size)
0.15-0.2mm (Thickness)
95% (Light Transmittance )

8. Start Printing
æ
1. Slicer

ctb3(D.cotb)jects

1. Open the slicer software of LCD 3D printer, click” open”on the left of the screen and add model file.

2. If the model needs to add support, click the upper left icon to set corresponding parameters.

3. Click icon Setting slice printing parametersClick”Slice”

4 waiting for slice to be finishedsave the sliced file You are welcome to find more details of slicing tutorial on the official website www.creality.com).

8. Start Printing

2. Print

file name Save type
Hide Folder

ctb3(D.cotb)jects

preservation

cancel

1. Generate cxdlp fileand save the file to U disk.

USB port 2. Insert the U disk press the print button.

Warning: During the printing process, the machine can not be shaken, so as not to affect the printing quality. 11

8. Start Printing

1. Select files;

2. Select the file to be printed and press” Start”;

3. Printing···

9. Control remote printing

1.Download

2.Register

3.Log in

4. Add equipment

HALOT-LITE

5. Scan QR Code

6. Device naming

7. Select device

8. check printing status

9. Print Progress

10.Wiring Connection
UL LED fan port

Exhaust fan

Power Supply port

UV LED POWER EN port

Z motor driver port

USB HOST port Spare brush firmware interface
14

RGB screen port

Z ends top LCD screen port

11.Troubleshooting
15

FCC Statement
FCC Caution: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: –Reorient or relocate the receiving antenna. –Increase the separation between the equipment and receiver. –Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. –Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator& your body.
16

IC Caution:
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions:
(1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device.
To maintain compliance with RF exposure guidelines, this equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux apparei ls radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
Pour maintenir la conformité aux directives d’exposition aux radiofréquences, cet équipement doit être installé et utilisé avec une distance minimale de 20 cm entre le radiateur et votre corps.
17

SHENZHEN CREALITY 3D TECHNOLOGY CO., LTD.
Add:18F,JinXiuHongDu Building, Meilong Blvd., Longhua Dist., Shenzhen, China 518131 Official Website: www.creality.com Tel+86 755-8523 4565 E-mail: [email protected] [email protected]

R 210-167519
