FUZE 1910
QUICK START GUIDE
150.354 V1
| MENU | DESCRIPTION | ||
| DMX ADDRESS | A000-Axxx | DMX address setting | |
| AUTOPLAY | Auto run | Internal program 1-9 | Auto program |
| Music Run | Internal program 1-9 | Sound control | |
| RESET | ALL | On / Off | Reset all |
| Pan /Tilt | On / Off | Reset Pan /Tilt | |
| REVERS PAN | On / Off | Reverse Pan | |
| REVERS TILT | On / Off | Reverse Tilt | |
| SPECIAL | Reset default | On / Off | Reset default |
| Calibrate | Access for Beamz authorized dealer only | ||
| Temperature | xxx °C / F | Current temperature | |
| Manual Ctrl | PAN = xxx | Manual control | |
| Mic SET | 0-99% | Sensitivity of microphone | |
| DMX MODE | CH 16 | Standard mode | |
| CH 28 | Basic mode | ||
| SCAN DEGREE | PAN | 630° / 540° / 360° | Select TILT Degree, default is 540° |
| TILT | 270° / 180° / 90° | Select PAN Degree, default is 270° | |
| VERSION | Vx.xx | Software version | |
DMX CHANNELS
| 16CH | 28CH | FUNCTION | VALUE | DESCRIPTION |
| 1 | 1 | Master dimmer | 000-255 | Dimmer 0-100% |
| 2 | 2 | Shutter | 000-031 | No function |
| 032-063 | Open | |||
| 064-095 | Strobe, slow to fast | |||
| 096-127 | Open | |||
| 128-159 | Pulse effect in sequences slow to fast | |||
| 160-191 | Open | |||
| 192-223 | Random strobe effect slow to fast | |||
| 224-255 | Open | |||
| 3 | 3 | Pan | 000-255 | Movement 0°-540° |
| 4 | 4 | Pan Fine | 000-255 | |
| 5 | 5 | Tilt | 000-255 | Movement 0°-270° |
| 6 | 6 | Tilt Fine | 000-255 | |
| 7 | 7 | P/T Speed | 000-225 | Slow to fast |
| 226-235 | Blackout by movement | |||
| 236-255 | No function | |||
| 8 | 8 | Colour | 000-255 | Red dimmer 0-100% |
| 9 | 9 | 000-255 | Green dimmer 0-100% | |
| 10 | 10 | 000-255 | Blue dimmer 0-100% | |
| 11 | 11 | 000-255 | White dimmer 0-100% | |
| 12 | LED Ring 1 | 000-255 | Red dimmer 0-100% | |
| 13 | 000-255 | Green dimmer 0-100% | ||
| 14 | 000-255 | Blue dimmer 0-100% | ||
| 15 | 000-255 | White dimmer 0-100% | ||
| 16 | LED Ring 2 | 000-255 | Red dimmer 0-100% | |
| 17 | 000-255 | Green dimmer 0-100% | ||
| 18 | 000-255 | Blue dimmer 0-100% | ||
| 19 | 000-255 | White dimmer 0-100% |
| 16CH | 28CH | FUNCTION | VALUE | DESCRIPTION |
| 20 | LED Ring 3 | 000-255 | Red dimmer 0-100% | |
| 21 | 000-255 | Green dimmer 0-100% | ||
| 22 | 000-255 | Blue dimmer 0-100% | ||
| 23 | 000-255 | White dimmer 0-100% | ||
| 24 | Macro color | 000-015 | No function | |
| 016-031 | Red | |||
| 032-047 | Green | |||
| 048-063 | Blue | |||
| 064-079 | White | |||
| 080-095 | Red + green | |||
| 096-111 | Red + blue | |||
| 112-127 | Red + white | |||
| 128-143 | Green + blue | |||
| 144-159 | Green + white | |||
| 160-175 | Blue + white | |||
| 176-191 | Red + green + blue | |||
| 192-207 | Red + green + blue + white | |||
| 208-212 | 2700K | |||
| 213-217 | 3200K | |||
| 218-222 | 3500K | |||
| 223-227 | 5000K | |||
| 228-232 | 5500K | |||
| 233-237 | 6000K | |||
| 238-242 | 6500K | |||
| 243-247 | 7000K | |||
| 248-255 | 8000K | |||
| 13 | 25 | Color temperature | 000-015 | No function |
| 016-045 | Below 3200K | |||
| 046-075 | 3200K-3500K | |||
| 076-105 | 3500K-5000K | |||
| 106-135 | 5000K-5500K | |||
| 136-165 | 5500K-6000K | |||
| 166-195 | 6000K-6500K | |||
| 196-225 | 6500K-7000K | |||
| 226-255 | 7000K-8000K | |||
| 14 | 26 | Macro | 000-015 | No function |
| 016-031 | Macro run 1 | |||
| ….. | ….. | |||
| 128-143 | Macro run 8 | |||
| 144-159 | Macro sound 1 | |||
| ….. | ….. | |||
| 240-255 | Macro sound 7 | |||
| 15 | 27 | Marco speed | 000-255 | Macro speed. from slow to fast |
| 16 | 28 | Special | 000-079 | No function |
| 080-094 | Reset motors | |||
| 095-099 | No function | |||
| 100-119 | Internal program 1 | |||
| ….. | ….. | |||
| 220-239 | Internal program? | |||
| 240-255 | Internal sound program 1 |
