Carmanah Mx 200 Top Of Pole Mount Kit Installation Guide

MX 200 Top of Pole Mount Kit

Product Information

The MX Series is a top of pole mount kit designed for the MX 100
and MX 200 solar power modules. It is manufactured by Carmanah
Technologies Corp. and is suitable for outdoor installation. The
kit includes a wedge casting, adhesive gasket strip, and bolts for
mounting.

Product Usage Instructions

Before starting the installation process, it is important to
read all included install guides provided with the product.

1. Obtain the wedge casting and adhesive gasket strip included
   with the power module. Install the gasket strip along the top edge
   of the wedge casting.



   Note: Failure to apply the gasket strip could
   result in water entry and product damage.

2. Thread the supplied bolts partially into the top of the pole
   casting. Take note of the longer bolt’s location on the large
   casting.
3. Fully thread the wedge casting into the top of the pole
   casting.
4. Install the assembly onto the pole and orient the power module
   according to the instructions provided in LEVEL 2 guide.

   Note: For square posts, partially unthread the
   wedge casting during installation.

5. Tighten all seven casting bolts securely.
6. Fasten the solar power module to the wedge casting following
   the instructions provided in LEVEL 2 guide.

Note: For any further assistance or inquiries,
contact Carmanah Technologies Corp. at 1.250.380.0052 or email
[email protected]. Additional information can also be
found on their website at carmanah.com.

MX Series
MX 100 & 200 TOP OF POLE MOUNT KITS INSTALL GUIDE
LEVEL 4

Depicted assembly order does not include cable routing steps and be modified to suit preference.

1. Obtain wedge casting and adhesive gasket strip included with power module and install gasket strip along top edge as shown.

Adhesive gasket

Failure to apply gasket could result in water entry and product damage.

Wedge casting
90819REVA
Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | [email protected] | carmanah.com

MX 100 & 200 TOP OF POLE MOUNT KITS INSTALL GUIDE
LEVEL 4 2. Thread supplied bolts partially into top of pole casting. Note
location of longer bolt on large casting. 3. Fully thread wedge casting into top of pole casting. 4. Install on pole and orient power module per LEVEL 2 instructions.
On square posts, this requires partially unthreading wedge casting. 5. Tighten all seven casting bolts. 6. Fasten solar power module (not shown) to wedge casting per
LEVEL 2 guide.
OR

NOTE: READ ALL INCLUDED INSTALL GUIDES BEFORE SYSTEM INSTALLATION

Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | [email protected] | carmanah.com
