Anko 43277384 Car Bluetooth Fm Transmitter User Manual (+ PDF)

Plug the unit into your vehicle’s cigarette lighter or power
port.
Tune your radio to an unused FM frequency, then match the same
frequency of this unit.
Insert a Micro SD card or USB disk containing
MP3/WMA/WAV/FLAC/APE files into the card/USB slot. It will play and
transmit the file automatically.

Using Bluetooth Function:

Using Bluetooth for the first time, you need to pair your
mobile phone with this unit.
- Activate your mobile phone’s Bluetooth function, then search
  for new devices.
- When the mobile phone detects this unit (named as KM43277384),
  please pair or connect.
On music playing mode, when there is an incoming call, this
unit will automatically switch to telephone mode.

Bluetooth Calling:

Please press to answer the incoming call or hang off a
call.
Please press and hold for 3 seconds during a call to reject the
incoming call in Bluetooth calling mode.
Please press twice to dial the last number automatically.
When making a call, you can only dial the phone number by your
mobile phone, but once the call is connected, you can use the
hands-free function to enjoy it.

How to Activate Voice Assistant (e.g. Siri/Google
assistant):

Press once to quickly access the voice assistant.

Quick Guide:

Press button: answer the call.
Press button: hang up the call.
Press and hold for 3 seconds to reject incoming calls.
Press twice to dial the last number automatically.
When answering a call, press and hold for 3 seconds to switch
to private call mode.
Press Button: Play the music.
Press Button again: Pause playing.
Press and hold for 2 seconds to increase the volume.
Press and hold for 2 seconds to decrease the volume.
Press CH and then press to increase the frequency.
Press CH and then press to decrease the frequency.
Press Button: Play the next song.
Press Button: Play the previous song.
Press Button: Switch to the next folder.

Note: The product comes with a 12 Months Warranty.

View Fullscreen

User Manual Car Bluetooth® FM Transmitter
43277384
Thanks for choosing our Bluetooth FM Transmitter. This device streams music and phone calls directly from your Bluetooth device to the car FM stereo system. The built-in microphone provides you with an amazing hands-free function, it is also with a Micro SD card/USB Disk slot that lets you enjoy favorite MP3 and WMA tunes by your car’s stereo system and charge your phone simultaneously. Please read the User Manual carefully before using it. Hope this device makes your driving more interesting and safer. Notice Please read user manual carefully before any operations and keep it for your records. Safety Instructions: Please read all safety instruction warnings carefully before using this product. Improper use of this product may result in damage to this or attached products. To ensure the production works well, please never use this in the following conditions: 1. Moist or underwater conditions. 2. Conditions near heater or high temperature service. 3. Conditions with direct and strong sunshine. 4. Do not use chemical solvent on cleaning this product. Packing Contents:
Bluetooth FM Transmitter X1 User Guide X1

Features: 1. Wireless transmit phone call & audio playing to the car FM stereo system via Bluetooth. 2. Switch to Hands-free mode automatically from music playing status when receiving calls. 3. Adjustable goose-neck design allows us to find a better viewing. 4. Elegant design with big white LED display. 5. Support to read Micro SD (Max 64GB). 6. Dual USB output: PD20W Max +DC 5V/2.4A. 7. Voice prompt and hands-free calling for safety driving. 8. Adopt the Bluetooth 5.3 Technology. 9. Siri/Google assistant quick activation. Specifications Bluetooth Version: 5.3 Frequency Range: 87.6-107.9MHz Product Input:12-24V Dual USB Output: PD20W Max +DC 5V/2.4A Micro SD Card (Max Capacity): 64GB USB Disk (Max Capacity): 64GB Music Format: MP3/WMA/WAV/FLAC/APE Transmit Distance: up to 3 m Product Dimension: 59*90*127 mm Product Weight: 78.5g. Compatibility: This device can be paired as a hand free kit with any compatible Bluetooth 2.1 or higher enabled devices.
Appearance:
Operation Instructions
Setup the FM Transmitter Connection: 1. Plug the unit into your vehicle’s cigarette lighter or power port.

2. Tune your radio to an unused FM frequency, then match the same frequency of this unit. 3. Insert Micro SD card or USB disk which containing MP3/WMA/WAV/FLAC/APE files into the card/USB slot. It will play and transmit the file automatically.
Using Bluetooth function: 1. Using Bluetooth for the first time, you need to pair your mobile phone with this unit. Activate your
mobile phone’s Bluetooth function, then search new device. When the mobile phone detects this unit (named as “KM43277384″), please pair or connect. 2. On music playing mode, when there is an incoming call, this unit will automatically switch to telephone mode.
Bluetooth calling: 1. Please press to answer the incoming call or hang off a call. 2. Please press and hold for 3 seconds during call to reject the incoming call in Bluetooth calling mode. 3. Please press twice to dial the last Number automatically. 4. When making a call, you can only dial the phone number by your mobile phone, but once the call connected, you can use the hands-free function to enjoy it.
How to Activate Voice Assistant (e.g. Siri/Google assistant):
Press ” ” once to quickly access voice assistant.

Quick Guide:

No.

Operation Guide

1 Answer/hang up the call

2 Ignore calls
3 Last number redial

4 Private calling

5 Play and Pause the music

6 Adjust the Volume
7 Frequency modulation
8 Music selection
9 Folder selection

12 Months Warranty

On FM transmitter
Press ” ” button: answer the call. Press ” ” button: hang up the call.
Press ” ” and hold for 3 seconds to reject incoming calls.
Press ” ” twice to dial the last number automatically.
When answering a call, press ” ” and hold for 3 seconds to switch to private call mode. Press ” ” Button: Play the music. Press ” ” Button again: Pause playing. Press “” and hold for 2 seconds to increase the Volume. Press “” and hold for 2 seconds to decrease Volume. press “CH” and then press “” to increase the frequency. Press “CH” and then press “” to decrease the frequency. Press “” Button: Play the next song. Press “” Button: Play the previous song.
Press ” ” Button: Switch to next folder.

Thank you for your purchase from Kmart. Kmart Australia Ltd warrants your new product to be free from defects in materials and workmanship for the period stated above, from the date of purchase, provided that the product is used in accordance with accompanying recommendations or instructions where provided. This warranty is in addition to your rights under the Australian Consumer Law. Kmart will provide you with your choice of a refund, repair or exchange (where possible) for this product if it becomes defective within the warranty period. Kmart will bear the reasonable expense of claiming the warranty. This warranty will no longer apply where the defect is a result of alteration, accident, misuse, abuse or neglect. Please retain your receipt as proof of purchase and contact our Customer Service Centre on 1800 124 125 (Australia) or 0800 945 995 (New Zealand) or alternatively, via Customer Help at Kmart.com.au for any difficulties with your product. Warranty claims and claims for expense incurred in returning this product can be addressed to our Customer Service Centre at 690 Springvale Rd, Mulgrave Vic 3170. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. For New Zealand customers, this warranty is in addition to statutory rights observed under New Zealand legislation.
