TCD220009AA Flexible Shaft Coupling
Product Information:
Product Name: Flexible Shaft Coupling
Model: ERB Series
Instruction Manual: TCD220009AA
Cautions during Use:
- Follow the Autonics website for selecting the specified
model.
Ordering Information:
This information is only for reference. Follow the Autonics
website to select the specified model.
Cautions during Installation:
- Ensure proper alignment to extend the life of the coupling and
the applied equipment.
Specifications:
| Model | Connection Type | Max. Revolution | Max. Torque | Rated Torque | Mounting Bolt (Mounting Torque) | Torsional Stiffness | Inertia Moment | Max. Allowable Misalignment | Standard Bore Diameter (Tolerance h7) | Max. Allowable Diameter | Material | Unit Weight (Packaged) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ERB-A-19C- | Clamp | 8,000 rpm | 1.2 N m | 0.6 N m | M2.5 (1 N m) | Parallel misalignment: 0.15 mm | – | Aluminum (AL 7075-T6), Alumite surface | 14.4 g (14.9 g) | |||
| ERB-A-19S- | Set screw | 20,000 rpm | 3.0 N m | 1.5 N m | M3 (0.7 N m) | Parallel misalignment: 0.2 mm | – | Aluminum (AL 7075-T6), Alumite surface | 36.7 g (37.3 g) | |||
| ERB-A-26C- | Clamp | 6,000 rpm | – | – | M3 (0.7 N m) | – | – | – | – | – | ||
| ERB-A-26S- | Set screw | 15,000 rpm | – | – | M4 (1.7 N m) | – | – | – | – | – |
Dimensions:
Refer to the user manual for detailed dimensions of each
model.
Contact Information:
Autonics Co., Ltd.
Address: 18, Bansong-ro 513Beon-gil, Haeundae-gu, Busan,
Republic of Korea, 48002
Website: www.autonics.com
Phone: +82-2-2048-1577
Email: [email protected]
Product Usage Instructions:
- Ensure proper alignment during installation to extend the life
of the coupling and the applied equipment. - Refer to the Autonics website for selecting the specified model
based on your requirements. - Follow the dimensions provided in the user manual for accurate
installation. - Refer to the specifications table for the maximum revolution,
maximum torque, and rated torque values. - Use the appropriate mounting bolt and torque values as
specified in the table. - Take into account the max allowable misalignment and parallel
misalignment values specified in the specifications table. - Ensure the standard bore diameter (tolerance h7) and max
allowable diameter are compatible with your equipment. - Handle the coupling with care to prevent damage.
- For further assistance or inquiries, contact Autonics Co., Ltd.
using the provided contact information.
Flexible Shaft Coupling
ERB Series INSTRUCTION MANUAL
TCD220009AA
Thank you for choosing our Autonics product. Read and understand the instruction manual and manual thoroughly before using the product. For your safety, read and follow the below safety considerations before using. For your safety, read and follow the considerations written in the instruction manual, other manuals and Autonics website. Keep this instruction manual in a place where you can find easily. The specifications, dimensions, etc. are subject to change without notice for product improvement. Some models may be discontinued without notice. Follow Autonics website for the latest information.
Cautions during Use
· Couplings are for transferring rotation angle and power between shafts. Before using this, make sure to check the purpose and appropriacy.
· This product uses high strength aluminum alloy and has spring power as Radial beam type. However, if the coupling is dropped, hit or applied excessive power, it may be damaged or transformed.
· If the coupling is applied over the rated misalignment, or the tolerance of the shaft is over the allowable value, it may cause plastic deformation, damage of the product or shorten the life cycle.
· When it occurs abnormal sound during operating the equipment with this coupling, stop the operation and remove the cause such as misalignment, unscrewing, or rotation hazard.
· If this coupling is applied to the equipment which has big fluctuation of load, shaft may be loose by unscrewing. Tighten the screw securely and prevent from unscrewing.
· This product is for transferring rotation power. If there is a risk of human contact, attach the caution label or install a safety cover in a prominent position.
· Rated torque is available to transfer the power continuously. Check the rated capacity before using this product.
· Max. torque is available to transfer the power in a moment. Check the rated capacity before using this product.
Ordering Information
This is only for reference. For selecting the specified model, follow the Autonics website.
ERB A – –
Diameter Number: External diameter (unit: mm)
Connection type C: Clamp S: Set screw
Bore diameters Number / Number: Bore diameters
(unit: mm)
Cautions during Installation
· It must be used within the rated allowable misalignment range. When using the flexible coupling over the rated misalignment range, it may cause vibration or shorten the life cycle.
· When there are more than two misalignments, each allowable value is 50%. · It is recommended to use the flexible coupling below 1/3 of the allowable
misalignment value to extend the life of the coupling and the applied equipment.
Specifications
Model
ERB-A-19C- ERB-A-19S- ERB-A-26C- ERB-A-26S-
Connection type
Clamp
Set screw
Clamp
Set screw
Max. revolution
8,000 rpm
20,000 rpm 6,000 rpm
15,000 rpm
Max. torque
1.2 N m
3.0 N m
Rated torque
0.6 N m
1.5 N m
Mounting bolt (mounting torque)
M2.5 (1 N m) M3 (0.7 N m) M3 (0.7 N m) M4 (1.7 N m)
Torsional stiffness Inertia moment
140 N m / rad 6.4 × 10-7 kg.m2
240 N m / rad 3.4 × 10-6 kg.m2
Max. allowable misalignment
Angular misalignment: 2.5°
Angular misalignment: 2.5°
Parallel misalignment: 0.15 mm Parallel misalignment: 0.2 mm
End-play: ± 0.3 mm
End-play: ± 0.4 mm
Standard bore diameter (tolerance h7)
Ø 4, Ø 5, Ø 6 mm
Ø 6, Ø 8 mm
Max. allowable diameter
Ø 4 to 8 mm
Ø 5 to 12 mm
Material
Aluminum (AL 7075-T6), Alumite surface
Unit weight (packaged) 14.4 g ( 14.9 g)
36.7 g ( 37.3 g)
Dimensions
· Unit: mm, For the detailed drawings, follow the Autonics website.
Clamp type
K
L
B
Ø D2 Ø D1 ØA
M
C
C
Model ERB-A-19C-04/04 ERB-A-19C-04/05 ERB-A-19C-04/06 ERB-A-19C-05/05 ERB-A-19C-05/06 ERB-A-19C-06/06 ERB-A-26C-06/06 ERB-A-26C-06/08 ERB-A-26C-08/08
ØA L
Ø D1 Ø D2
MC
BK
4
+0.018 0
19
23
4
+0.018 0
5
+0.018 0
6
+0.018 0
M2.5 6.1 3
19
23
5
+0.018 0
5
+0.018 0
6
+0.018 0
5.75
19
23
6
+0.018 0
6
+0.018 0
26
31.4
6
+0.018 0
6
+0.018 0
8
+0.018 0
M3
7.4
3.7
8.55
26
31.4
8
+0.018 0
8
+0.018 0
Set screw type
L
M
B
B
Ø D2 Ø D1 ØA
Model ERB-A-19S-04/04 ERB-A-19S-04/05 ERB-A-19S-04/06 ERB-A-19S-05/05 ERB-A-19S-05/06 ERB-A-19S-06/06 ERB-A-19S-06/08 ERB-A-26S-06/06 ERB-A-26S-06/08 ERB-A-26S-06/10 ERB-A-26S-06/12 ERB-A-26S-08/08
C
C
ØA L 19 22 19 22 19 22
26 30 26 30
Ø D1 Ø D2
MC
B
4
+0.018 0
4
+0.018 0
5
+0.018 0
6
+0.018 0
5
+0.018 0
5
+0.018 0
M3
5.7
2.8
6
+0.018 0
6
+0.018 0
6
+0.018 0
8
+0.018 0
6
+0.018 0
6
+0.018 0
8
+0.018 0
10
+0.018 0
M4
6.8
3.4
12
+0.018 0
8
+0.018 0
8
+0.018 0
