OXD442 IP20 CTA Suspended Linear Lights

Product Information

The product is a Microwave Sensor for use with microwave
fittings. It is designed for ceiling mounting at heights between
2.5-4.5 meters. The Microwave Sensor can be adjusted to meet
customer requirements. The adjustments are made using six DIP
switches located on the top of the sensor. The switches control the
detection area, hold time, daylight threshold, standby period, and
standby dimming level.

Product Usage Instructions

Microwave Settings

Switch 1: Detection Area Adjustment
Switches 2 & 3: Hold Time (Time required ON after the last
detection)
Switch 4: Daylight Threshold (Light level when sensor will
operate)
Switch 5: Stand-by period (Time required ON in stand-by
mode)
Switch 6: Stand-by dimming level (Light level in stand-by
mode)

Wiring

The product requires suitable cable and power to be supplied to
the installation point. The wiring instructions vary depending on
the type of fitting being used:

Microwave Fittings

+ Positive (Red) – Negative (Black)

Emergency & Microwave Fitting

+ Positive (Red) – Negative (Black)

Fittings With 0(1)-10V Dimming (Without Emergency &
Microwave Sensor)

+ Positive (Red) – Negative (Black)

0-10V Dimming: 2-core cable terminated to a 0-10V
dimmer control (if required). Will dim down to OFF.

1-10V Dimming: 2-core cable terminated to a 1-10V
dimmer control (if required). Will dim down to 10%. A separate
switch is required on the mains input to turn the light OFF.

Fittings With 0(1)-10V Dimming (Without Microwave Sensor)

+ Positive (Red) – Negative (Black)

0-10V Dimming: 2-core cable terminated to a 0-10V
dimmer control (if required). Will dim down to OFF.

1-10V Dimming: 2-core cable terminated to a 1-10V
dimmer control (if required). Will dim down to 10%. A separate
switch is required on the mains input to turn the light OFF.

Note: The emergency battery backup fitting can be wired
as maintained or non-maintained. The emergency with microwave
sensor fitting is maintained only.

Maintained: The LED driver connects to
‘Switched Live’ with ‘Unswitched’ permanent live to the emergency
inverter. The luminaire can be switched on/off, but will illuminate
at a lower level on power failure.
Non-maintained: The LED driver is not
connected to ‘Switched Live’ with ‘Unswitched’ permanent live to
the emergency inverter. The luminaire only illuminates on power
failure.

To enable manual testing of the fitting, an inline keyswitch
must be fitted with the Permanent Live input into the driver.

0-10V Dimming

When the controller is set at 10V, the light output will be at
100%. When the controller is set to the minimum 0V, the output will
be 0%. The independent mains switch can then be used to turn off
the light/driver.

1-10V Dimming

When the controller is set at 10V, the light output will be at
100%. When the controller is set to the minimum 1V, the output will
be 10%. The independent mains switch can then be used to turn off
the light/driver.

Inceptor Duo

This section provides general information about the Inceptor Duo
product range. Please refer to the specific Installation, Technical
& Safety Information Sheet for detailed instructions.

IMPORTANT: Before commencing installation, read
the instructions and consult a competent electrician if there are
any doubts regarding the installation or use of the product.

Installation:

Refer to Fig 1. The luminaire comes with an accessory packet
containing 3 screws and 3 plugs. Before starting any work, ensure
that the mains isolator on the consumer unit is turned off.

View Fullscreen

MICROWAVE SETTINGS
The fittings supplied with Microwave Sensor, the mounting heights are 2.5-4.5M for ceiling mounting. The Microwave Sensor can be adjusted to meet the customer requirements. The adjustments are made via six DIP switches mounted on the top of the Microwave Sensor.
Switch 1 – Detection Area Adjustment Switches 2 & 3 – Hold Time (Time required ON after the last detection) Switches 4 – Daylight Threshold – (Light level when sensor will operate) Switches 5 – Stand-by period – (Time required ON in stand-by mode) Switch 6 – Stand-by dimming level – (Light level in stand-by mode)

WIRING

Suitable cable and power is to be supplied to the point of installation. Depending on the fitting being installed, the cable can be terminated as follows:

Microwave Fittings

Emergency & Microwave Fitting

Fittings With 0(1)-10V Dimming (Without Emergency & Microwave Sensor)

+ Positve (Red) _ Negative (Black)

0-10V Dimming: 2 core cable terminated to a 0-10V dimmer control (if required). Will dim down to OFF.
1-10V Dimming: 2 core cable terminated to a 1-10V dimmer control (if required). Will dim down to 10%. To turn the light OFF a separate switch is required on the mains input.

Fittings With 0(1)-10V Dimming (Without Microwave Sensor)

+ Positve (Red) _ Negative (Black)

Notes: The emergency battery backup fitting can be wired as maintained or non-maintained. The emergency with microwave sensor fitting is maintained only
– Maintained – The LED driver connects to `Switched Live’ with `Unswitched’ permanent live to the emergency inverter. (Luminaire can be switched on/off, but will illuminate at a lower level on power failure)
– Non-maintained – The LED driver is not connected to `Switched Live’ with `Unswitched’ permanent live to the emergency inverter (luminaire only illuminates on power failure).
To enable the fitting to be manually tested an inline keyswitch must be fitted inline with the Permanent Live input in to the driver.

0-10V Dimming When the controller is set at 10V the light output will be at 100%. When the controller is set to the minimum 0V the output will be 0%. The independent mains switch will then allow the light / driver to be turned off.

1-10V Dimming When the controller is set at 10V the light output will be at 100%. When the controller is set to the minimum 1V the output will be 10%. The independent mains switch will then allow the light / driver to be turned off.

INCEPTOR DUO

Installation, Technical & Safety Information Sheet
OXD442-**-* & OXD556-**-* Range Of 230V~ 50Hz Linear IP20 CTA Suspended Linear Lights

GENERAL INFORMATION
PLEASE READ INSTRUCTION BEFORE COMMENCING INSTALLATION AND RETAIN FOR FUTURE REFERENCE.
Electrical products can cause death or injury, or damage to property. If in any doubt about the installation or use of this product, consult a competent electrician.
· Before commencing any electrical work, to prevent the possibility of receiving an electric shock, ensure the mains isolator on the consumer unit is in the `OFF’ position and safely isolated in accordance with Best Practice Guide 3.
· Before commencing installation, ensure the fitting is complete with the fixings required. · The fitting should be mounted on a smooth, flat surface, noting the position of any pipes or wiring behind the fixed surface to prevent the risk of
damage. · The LED light source is 0-10V dimmable with Standard & Emergency ONLY fittings. · The battery contained in the emergency LED light source is is replaceable by professionals only. · If in doubt consult a qualified electrician. The luminaire must be installed in accordance with the latest IET Wiring Regulations, BS7671. · The LED light source is replaceable by professionals only · The light source contained within this luminaire has an energy classification value of E · It may be neccessary to turn the CTA switch to the `OFF’ position to see the EM indicator visibly.

INSTALLATION.

Fig 1. The luminare comes with an accessory packet which contains 3x screws & 3x plugs. Ensure the mains isolator on the consumer unit is turned off before commencing any work.

Fig 2. Install the suspension mount and the ceiling rose mount using the plugs and screws found in the accessory packet.

Fig 3. Please see wiring diagram and wire according to BS7671. Screw the ceiling rose and the suspension cable to the mounts. Use the dual CCT switch to adjust the temperature to the desired level on up and down light source

EMERGENCY INSTALLATION.

Emergency version ONLY

Fig 4. Loosen the screw on the top of the lumiaire (wiring side). Slide the plate to show the EM converter cable and the battery cable.

Fig 5. Connect the EM converter cable to the battery cable. Slide the plate back down and tighten the screw back. Please ensure the cable is NOT in the way of the screw.

DUAL CTA SWITCH
This luminaire contains a dual CTA DIP switch. You can individually control the up & down LEDs to be warm white, cool white, daylight or OFF. WW – 3000K CW – 4000K DL – 6000K OFF – OFF

OFF DL CW WW OFF DL CW WW

EMERGENCY BATTERY BACKUP

On first operation a 24 hour charge will be required to fully charge the batteries.
Failure to provide a permanent live will cause the batteries to power the fitting when it is switched off. This is not recommended as it will reduce the lifetime of the batteries.
This product must be disconnected from the circuit if subjected to any high voltage or insulation resistance testing. Irreparable damage will occur if this instruction is not followed.
Recommended routine emergency test procedure in accordance with BS 5266.
· Daily check – check that the status GREEN LED indicator is illuminated.
· Monthly functional test – simulate a mains supply failure for approx. 30 secs by operation of key switch or switching off a circuit breaker. Ensure normal supply is restored after test and the indicator status LED is illuminated.
· Twice yearly conduct a one hour duration test – simulate a mains supply failure for one hour continuous test by operation of key switch or switching off circuit breaker. Ensure normal supply is restored after test and the indicator status LED is illuminated.
· Annual full three hour duration test – conduct a three hour continuous duration test. Simulate a mains supply failure for three hour continuous test by operation of key switch or switching off circuit breaker. Ensure normal supply is restored after test and the indicator status LED is illuminated.
If the luminaire fails any of the function or duration tests, please contact a qualified electrician.

SPECIFICATIONS:

Total Wattage Dimensions of linear body
Colour Temperature Dimmable
Input Voltage/Frequency
Flicker Free Mounting Height for
Microwave sensor Microwave Detection Range
IP Rating IK Rating Body Material Warranty

36W DOWN & 6W UP, 1200MM LINEAR SUSPENDED

50W DOWN & 6W UP, 1500MM LINEAR SUSPENDED

OXD442-*

OXD442-E-*

OXD442-M-*

OXD442-ME-*

OXD556-*

OXD556-E-*

OXD556-M-*

OXD556-ME-*

42W

43W
