2 Wire Door Phone System
Order ref: 350.010UK
User Manual
This door phone system allows you to talk to visitors before opening the door. There is also an additional function to allow the opening of an electronic lock. Great for use in the home and in apartments, or for the elderly and less mobile.
Specification:
| Power Supply | 12Vac, 1000mA |
| Dimensions: Outdoor Unit | 160 x 113 x 68mm |
| Dimensions: Indoor Unit | 210 x 85 x 60mm |
| Weight: Outdoor Unit | 350g |
| Weight: Indoor Unit | 340g |
Features:
- Intercom with sharp clear audio
- 16 different ringer options
- Weatherproof outdoor unit (IP44 rated) with a backlit nameplate
- Maximum distance of 100m (using 2 x 0.75mm² cable)
- Supplied with adaptor and wall mount brackets
- Note: Cable not supplied
In the Box:
- Outdoor unit
- Indoor unit
- UK power supply
- Unit fixing brackets
Warning:
- For reasons of electrical safety, this device must never be immersed in water, exposed to damp conditions, or excessive force.
- Do not use this device if you find that it is damaged in any way.
- Only use the power supply provided by the manufacturer.
- When not in use for long periods, disconnect the power supply from the mains.
- Do not attempt to repair this device or take it apart under any circumstances, as this will invalidate your warranty.
This product is classed as Electrical or Electronic equipment and should not be disposed of with other household or commercial waste at the end of its useful life. The goods must be disposed of according to your local council guidelines.
Errors and omissions excepted.
