BN126C CoreLine Batten Emergency Light
Product Information: – Product Name: CoreLine Batten BN126C
Emergency – Type: LED Light – Life: L80B50 50K hrs – Voltage: 220V
50Hz 240V 60Hz – IP Rating: IK04 IP20 Product Usage
Instructions: 1. Installation: – The luminaire should be
installed by a qualified electrician and wired according to the
latest IEE electrical regulations or national requirements. –
Choose the desired mounting option: – Surface Mounted (2.1) –
Suspended Mounted (2.2) – Mounted on a BESA (2.3) – Plug all BESA
holes in the housing. 2. Wiring: – Choose the wiring option: –
Wiring from end hole (side) (3) – Use H05RN-F wires with a diameter
of 7-12mm. – Wiring from back entry (3.1) 3. Optional Features: –
TW/Loop in/Light-line creation (4) – Light-line creation (5) –
TW/Loop in/Light-line creation (6) 4. Maximum Number of Connected
Luminaires: – Refer to the Inrush current table for the maximum
number of connected luminaires. 5. Power Cord: – The power cord is
not included in the luminaire. 6. Maintenance Instructions: – To
maintain the lighting quality, follow these instructions: – Do not
stare into the LED light beam. – The luminaire should be installed
by a qualified electrician and wired according to the latest IEE
electrical regulations or national requirements. – Avoid high
concentrations of sulfur, as it can affect the product’s useful
lifetime and cause color changes. 7. Battery Information: – Battery
Unit: TrustSight 6,4V 4cell 3000 mAh battery LFP – Technology: LFP
– Capacity: 3000 mAh – Power: 4.8 W – Duration: 3 h – Nominal
Voltage: 6.4 V Note: For detailed installation and maintenance
instructions, refer to the complete user manual.
14/14
4x
4x
1x
1x
2x
CoreLine Batten
BN126C Emergency
indoor Life L80B50 50K hrs
220V 50Hz 240V 60Hz
TYPE
BN126C LED41S/840 PSU ELB3 L1200 BN126C LED52S/840 PSU ELB3 L1500 BN126C LED80S/840 PSU ELB3 L1500
IK04 IP20
P cW
D
36
D
44
D
64
18
Max
35 Mini 0
Ta 25
System light output (Lm)
4100 5200 8000
System light output Emerygency mode (Lm)
480 500
500
1.45 1.70 1.75
Unit: mm
L
65
IP40
65
IP20
Fixed or Suspension Mounting Holes
36 4-5
36
15.2 5.2
A: Mounting distance-L1200aL1500a
15
798 605
302.5
© 08/2022 Signify Holding. All rights reserved
1/14
or
-The luminaire shall be installed by a quali ed electrican and wired in accordance with the latest IEE electrical regulations or the national requirements.
– The light source of this luminaire is not replaceable; when the light source reaches its end of life the whole luminaire shall be replaced. – Luminaire must not be used or stored in corrosive environment where hazardous materials such as sulphur,chlorine, phthalates,etc,are present. – Water entering into IP20 luminaire is strictly prohibited. IP20 luminaire is not protected against wet condition, water ingress may cause electrical failure or unsafe conditions. – Luminaire is rated at IP40 from the front (part 1) and IP20 for a complete housing (part 2).
1: Luminaire opening
1
2
Part 1
Part 2
2.1:Surface Mounted
2.2:Suspend Mounted
Plug all BESA holes in the housing
3x
2x
2x
2x
2x
2.3:Mounted on a BESA
BESA 3x L1200/ L1500
2/14
3 : Wiring from end hole (side)
Optional
3.1: Wiring from back entry
H05RN-F
Min. 3 1,0mm Max. 3×2,5mm
7-12mm
4: TW/ Loop in
/ Light-line creation (Optional)
5: Light-line creation (Optional)
1x 2x nx
max. number of connected luminaire(see Inrush current table)
6: TW / Loop in / Light-line creation (Optional)
The power cord is not included in the luminaire
Last one
7
The end face of the rst luminaire and the last luminaire
3/14
8
T20
1 3
x2
2
The batteries have a life time expectancy of 4 years. Do not touch electronic components! Electronic components may be under high
9 voltage.
Light intensity distribution curves Emergency mode
A T T E N T I O N OBSERVE
PRECAUTIONS FOR HANDLING
ELECTROSTATIC SENSITIVE DEVICES
Service data for battery change:
Emergency flux: 484lm
Battery Unit
Manufacturer
Philips
Unit:
TrustSight 6,4V 4cell 3000 mAh battery LFP
Technology
LFP
Capacity
3000 mAh
Power
4,8 W
Duration
3 h
Nominal voltage
6,4 V
4/14
Maintenance instructions
To assure the lighting quality of this unique LED lighting concept there are only a few instructions regarding the maintenance of this LED luminaire:
* Do not stare into LED light beam. * The luminaire shall be installed by a qualified electrician and wired in accordance with the latest IEE electrical regulations or the national requirements. * Above average concentracion of sulfur effects the useful lifetime of the product.
E.g: Light color changes from w hite to blue. Typically in chicken & pig farms.
$IWHULQVWDOODWLRQDQGSRZHUXSWKHGULYHUZLOOGHWHFWWKHEDWWHUDQGVWDUWWKHDXWRPDWLFGHWHFWLRQ SURFHVV -‘XULQJDXWRPDWLFGHWHFWLRQWKHLQGLFDWRU/(‘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’HVLJQLQJXLGH7KHODWHVWYHUVLRQLVDYDLODEOH RQOLQH
5/14
8
max. number of connected luminaire(see Inrush current table)
Vertical
Inrush current I mains(A)
I max
max/2
Tref
I nom. Time(us)
L1200
L1500
LED41S LED52S LED80S
11.6 10.6 10.6
499
527 527
19
19 11
13
13 13
24
24 13
38
38 22
Optional
Installation Mode 12NC Description Short EOC
Suspension 911401776802 BN126Z SC 36574999
Suspension Wire: 1m See step 2.2 for installation
2x 2x 2x
3x
Signify Holding. All rights reserved. This document contains information relating to the product portfolio of Signify which information may be subject to change. No representation or warranty as to the accuracy or completeness of the information included herein is given and any liability for any action in reliance thereon is disclaimed. The information presented in this document is not intended as any commercial offer and does not form part of any quotation or contract.Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V.. All other trademarks are owned by Signify Holding or their respective owners.
Signify Holding. The Netherlands
6/14
