Fisher Paykel Hc36dtxb2-n Wall Range Hood User Guide

HC36DTXB2-N Wall Range Hood

Product Information:

• Product Name: HC36DTXB2_N Wall Range Hood, 36, Box Chimney
• Series: 7 | Contemporary Stainless Steel and Glass
• Features and Benefits:
  • Quiet and Effective: Four fan speeds for powerful extraction
    and a timer that keeps the vent hood working for up to 15 minutes
    after cooking is finished.
  • Simple Controls: Sleek soft-touch control panel and
    energy-efficient LED lights for bright and warm illumination.
  • Easy Cleaning: Black glass and stainless steel finish that is
    easily wiped clean, along with dishwasher-safe filters.
  • Complementary Design: Sleek stainless steel finish that
    complements any contemporary kitchen and matches Fisher &
    Paykel’s kitchen appliance family.
• Specifications:
  • Accessories (sold separately): Chimney extension, Light bulb,
    Recirculation carbon filter, Recirculation diverter
  • Fan ratings: Maximum sound rating – 67dBA, Speed 3 sound rating
    – 63dBA
  • Air outlet size: 6
  • Ducted and Recirculation options available
  • Fan speeds: 4
  • Filter type: Mesh
  • Power requirements: Rated current – 5.2A, Supply frequency –
    60Hz, Supply voltage – 120V, Total Power – 542W
  • Product dimensions: Depth – 19 11/16, Height – 23 3/4 – 41
    1/16, Width – 35 3/8
  • Control type: Soft-touch button
  • Ventilation features: LED lights
  • Warranty: Parts and labour – 2 years

Product Usage Instructions:

1. Ensure the range hood is properly installed according to the
   installation guide provided.
2. To operate the range hood, use the soft-touch control panel. It
   features buttons for adjusting the fan speed and turning on/off the
   LED lights.
3. Select the desired fan speed (from 1 to 4) based on the
   extraction rate required for your cooking. Higher fan speeds are
   more powerful.
4. For effective odor and steam removal, set the timer to keep the
   vent hood working for up to 15 minutes after cooking is
   finished.
5. The LED lights provide bright and energy-efficient lighting for
   your cooking surface. They can be turned on/off using the control
   panel.
6. To clean the range hood, wipe the black glass and stainless
   steel finish with a soft cloth. The finish is easy to clean and
   maintain.
7. The filters used in this range hood are multi-layered and
   dishwasher safe. To clean them, remove the filters and wash them in
   a dishwasher.
8. If you have purchased any additional accessories such as
   chimney extension or recirculation carbon filter, follow the
   installation instructions provided for those accessories.
9. This range hood is designed to complement contemporary kitchens
   and match other Fisher & Paykel kitchen appliances. It adds a
   sleek and modern touch to your kitchen decor.

QUICK REFERENCE GUIDE > HC36DTXB2_N
Wall Range Hood, 36″, Box Chimney
Series 7 | Contemporary Stainless Steel and Glass
The wall chimney range hood has contemporary styling, extracting steam, grease and cooking odors quietly and efficiently.
With four fan speeds, select the perfect extraction rate for your cooking Energy-efficient LED lighting to illuminate your cooking surface Powerful 600CFM maximum airflow

DIMENSIONS
Height Width Depth

23 3/4 – 41 1/16″ 35 3/8″ 19 11/16″

FEATURES & BENEFITS
QUIET AND EFFECTIVE This vent hood features four fan speeds providing powerful extraction to quickly remove odours and steam. As odors can linger in the kitchen well after cooking is finished, the timer keeps the vent hood working for up to 15 minutes before automatically turning off.
SIMPLE CONTROLS This Fisher & Paykel chimney range hood features a sleek and easy to use soft-touch control panel. This range hood’s LED

Date: 06.07.2023 > 1
lights provide bright, warm, energy efficient lighting ensuring the entire cooktop surface is illuminated.
EASY CLEANING The black glass and stainless steel finish is easily wiped clean. Multi-layered, dishwasher safe filters trap grease effectively and can easily be removed for cleaning.
COMPLEMENTARY DESIGN This wall chimney vent hood’s sleek stainless steel finish will complement any contemporary kitchen and is designed to match the rest of Fisher & Paykel’s kitchen appliance family.
SPECIFICATIONS

Accessories (sold separately) Chimney extension Light bulb Recirculation carbon filter Recirculation diverter

791774 792579 791772 792580

Fan ratings Maximum sound rating Speed 3 sound rating

67dBA 63dBA

Installation and cleaning Air outlet size Dishwasher safe filters Ducted Recirculation

6″ 3
Top extraction Optional – top extraction

Performance Extraction type

Surface

QUICK REFERENCE GUIDE > HC36DTXB2_N
Fan speeds Filter type Number of filters

4 Mesh
3

Power requirements Rated current Supply frequency Supply voltage Total Power

5.2A 60Hz 120V 542W

Product dimensions Depth Height Width

19 11/16″ 23 3/4 – 41 1/16″
35 3/8″

Product information Control type

soft-touch button

Ventilation features Light type

LED

Warranty Parts and labour

2 years

Paykel’s Customer Care Centre to ensure this page correctly describes the model currently available. ? Fisher & Paykel Appliances Ltd 2020

SKU

50084

The product dimensions and specifications in this page apply to the specific product and model. Under our policy of continuous improvement, these dimensions and specifications may change at any time. You should therefore check with Fisher &

Date: 06.07.2023 > 2
Other product downloads available at fisherpaykel.com Service & Warranty Installation & User Guide / Guide d’installation et guide d’utilisation Installation Guide Guide D’Installation Data Sheet Wall Range Hood
A PEACE OF MIND SALE 24 Hours 7 Days a Week Customer Support T 1.888.936.7872 Wwww.fisherpaykel.com
