DESK-M051MB Black Compact Crank Height Adjustable Desk Frame

Product Information: Black Compact Crank Height Adjustable Desk
Frame

SKU: DESK-M051MB

The Black Compact Crank Height Adjustable Desk Frame is a sturdy
and durable desk frame that can be adjusted to different heights
for comfortable use. The frame has a weight capacity of 154lbs
(70kg) and comes with a product warranty. The package includes all
the necessary hardware and tools for assembly.

Package Contents:

(x1) Telescopic Crossbar
(x1) Leg
(x2) Foot
(x1) Sync Rod
(x1) Crank Handle Sync Rod Extension
(x1) Leg with Gearbox
(x2) Side Bracket
(x1) Crank Handle
(x1) Crank Handle Sync Rod
(x4) M6x25mm Screw
(x4) M6x10mm Screw
(x8) M6x35mm Screw
(x2) ST4.2x16mm Rounded Head Screw
(x10) ST4.2x16mm Screw
(x1) 2.5mm Allen Wrench
(x1) 4mm Allen Wrench
(x1) 5mm Allen Wrench
(x1) Wrench

Tools Needed:

Phillips Screwdriver
Drill
Level

Product Warranty:

For the most up to date details on your product’s warranty,
please visit the product’s listing on our website or reach out to
customer support. vivo-us.com/products/desk-m051mb

Product Usage Instructions:

Before you begin assembly, please ensure that you have all the
necessary hardware and tools listed above. If any parts are missing
or damaged, please contact customer support at [email protected] or
309-278-5303 within 30 days of product delivery.

Step 1: Pre-Assembly

Read through the instruction manual carefully and make sure you
understand the directions before starting assembly. If you have any
doubts about the safety of the installation, please call a
qualified technician. Check carefully to make sure there are no
missing or defective parts. Improper installation may cause damage
or serious injury. Do not use this product for any purpose that is
not explicitly specified in this manual. Do not exceed weight
capacity. We cannot be liable for damage or injury caused by
improper mounting, incorrect assembly, or inappropriate use.

Step 2: Assembly

Extend the Telescopic Crossbar (A) by loosening the screws
using the 4mm Allen Wrench (T-B).
Attach one Leg (B) to each end of the Telescopic Crossbar (A)
using the M6x35mm Screws (S-C) and the Leg with Gearbox (C) using
the M6x25mm Screws (S-A).
Attach the Foot (E) to each Leg (B) using the ST4.2x16mm
Rounded Head Screws (S-D).
Attach the Side Brackets (D) to the Leg with Gearbox (C) using
the M6x10mm Screws (S-B).
Attach the Sync Rod (F) to the Leg with Gearbox (C) using the
ST4.2x16mm Screws (S-E).
Attach the Crank Handle Sync Rod Extension (I) to the Crank
Handle Sync Rod (H).
Attach the Crank Handle Sync Rod (H) to the Sync Rod (F) using
the Crank Handle Sync Rod Extension (I).
Attach the Crank Handle (G) to the Leg with Gearbox (C).
Tighten all screws and bolts using the appropriate tools.

Contact Customer Support:

If you have any questions or concerns about assembly or usage of
the Black Compact Crank Height Adjustable Desk Frame, please
contact customer support at [email protected] or 309-278-5303. Our
friendly and knowledgeable product support team is available
Monday-Friday from 7am-7pm CST to assist you with any issues you
may have.

View Fullscreen

Black Compact Crank Height Adjustable Desk Frame SKU: DESK-M051MB
Instruction Manual
ASSEMBLY VIDEO AVAILABLE: Follow along step-by-step with our video walk through by scanning the QR code with your mobile device or by following the product link: vivo-us.com/products/desk-m051mb [email protected] 309-278-5303 www.vivo-us.com

PERSONABLE CUSTOMER SUPPORT
7AM – 7PM
Monday-Friday

Give us a Call: 309-278-5303

Chat Us: www.vivo-us.com

Email Us: [email protected]

We’re Here for You!
Our customer-minded support team is here for YOU, Monday-Friday 7am-7pm CST.
We offer immediate assistance with rapid response times from customer service agents and product techncians to
help you every step of the way!

Missing a Part?
If any parts are received damaged / defective OR you are missing a part, please reach out to us within 30 days of
product delivery to have it replaced at no cost. We are happy to replace parts to ensure you have a fully
functioning product

PRE-ASSEMBLY | BEFORE YOU BEGIN

If you do not understand these directions, or if you have any

doubts about the safety of the installation, please call a qualified

technician. Check carefully to make sure there are no missing

or defective parts. Improper installation may cause damage or

serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. Do not exceed weight capacity. We

cannot be liable for damage or injury caused by improper mounting, incorrect

assembly or inappropriate use.

WARNING: CHOKING HAZARD
SMALL PARTS – NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS
REQUIRED.

ELECTRICAL WARNING :
THIS PRODUCT IS POWERED BY ELECTRICITY. IN ORDER TO AVOID BURNS, FIRE AND ELECTRIC SHOCK, PLEASE READ THE FOLLOWING INSTRUCTIONS CAREFULLY. · DO NOT CLEAN PRODUCT WHILE POWER IS CONNECTED. · DO NOT DISASSEMBLE OR REPLACE COMPONENTS WHILE POWER IS CONNECTED. · NEVER OPERATE THE SYSTEM WITH A DAMAGED CORD OR PLUG. PLEASE CONTACT YOUR
SELLER TO REPLACE DAMAGED PARTS. · NEVER OPERATE SYSTEM IN DAMP ENVIRONMENTS OR IF ANY ELECTRICAL COMPONENTS HAVE
MADE CONTACT WITH LIQUIDS. · ALTERATIONS OF THE GIVEN POWER UNIT ARE NOT ALLOWED. · OUTDOOR USE IS PROHIBITED.

WEIGHT CAPACITY
DO NOT EXCEED WEIGHT CAPACITY. Failure to do so may result in serious injury.

154lbs (70kg)

Product Warranty For the most up to date details on your product’s warranty, please visit the product’s listing on our website or reach out to customer support. vivo-us.com/products/desk-m051mb
Returns | Product Didn’t Work Out? We offer a hassle-free 30 day return on all products. Contact customer support at 309-278-5303 or [email protected]. Please note: For items ordered in error or no longer needed, the return shipping charges will be at the buyer’s expense.

TOOLS NEEDED: |

Phillips Screwdriver

Drill

Level

DIFFICULTY LEVEL

PACKAGE CONTENTS
Please consult the parts list below and ensure you have everything you need to assemble your product. If parts are missing or damaged, please contact us.

A (x1) Telescopic Crossbar

B (x1) Leg

E (x2) Foot

F (x1) Sync Rod

I (x1) Crank Handle Sync
Rod Extension

C (x1) Leg with Gearbox

D (x2) Side Bracket

G (x1) Crank Handle

H (x1) Crank Handle Sync
Rod

S-A (x4) M6x25mm
Screw

S-B (x4) M6x10mm
Screw

S-C (x8) M6x35mm
Screw

S-D (x2) ST4.2x16mm Rounded Head
Screw

S-E (x10) ST4.2x16mm
Screw

T-A (x1) 2.5mm Allen
Wrench

T-B (x1) 4mm Allen
Wrench

T-C (x1) 5mm Allen
Wrench

T-D (x1) Wrench

NOTE: SOME HARDWARE INCLUDED MAY NOT BE USED

ASSEMBLY STEPS
STEP 1: Extend the Crossbar

Loosen the screws on Telescopic Crossbar (A) using 4mm Allen Wrench (T-B) and extend the

sides.

T-B

A Telescopic Crossbar

T-B 4mm Allen
Wrench

STEP 2: Install the Crossbar to Legs

Attach Telescopic

Crossbar (A) to Leg (B)

and Leg with Gearbox (C)

using M6x25 mm Screws

(S-A). Tighten with 4mm

Allen Wrench (T-B).

T-B C

S-A B

B (x1) Leg

C Leg with Gearbox

S-A M6x25mm Screw

T-B 4mm Allen
Wrench

STEP 3: Mount Side Brackets
Assemble Side Brackets (D) to the frame assembly using M6x10mm Screws (S-B) and 5mm Allen Wrench (T-C).

S-B

T-C

D Side Bracket

S-B M6x10mm Screw

STEP 4: Assemble Feet
Mount Feet (E) to Leg (B) and Leg with Gearbox (C) using M6x35mm Screws (S-C) and 4mm Allen Wrench (T-B).

T-C 5mm Allen
Wrench
E T-B
S-C

B C

S-C

T-B

Foot

M6x35mm Screw

4mm Allen

Wrench

STEP 5: Adjust Frame Length
Extend Telescopic Crossbar (A) to fit the desktop. Retighten the screws on Telscopic Crossbar (A) using 4mm Allen Wrench (T-B).
T-B
A

T-B 4mm Allen
Wrench

STEP 6: Attach Desktop

Secure the frame assembly to

the desktop using ST4.2x16mm

Screws (S-D) and a Phillips

screwdriver.

NOTE: If using the provided

screws to secure your desktop,

S-D

ensure the desktop thickness is

3/4″ (19mm) or greater.

S-D ST4.2x16mm Rounded
Head Screw
7

STEP 7: Install the Sync Rod
Loosen the knob on Sync Rod (F) and insert the rod into Leg (B). Extend Sync Rod (F) onto Leg With Gearbox (C). Tighten both knobs on Sync Rod (F) using Wrench (T-D).

3
T-D
C

4
B F

F Sync Rod
8

T-D Wrench

STEP 8: Mount the Crank
Loosen the set screw on Crank Handle Sync Rod (H) using 2.5mm Allen Wrench (T-A) to extend the rod into Leg With Gearbox (C). Assemble Crank Handle (G) to Crank Handle Sync Rod (H) making sure Crank Handle Sync Rod (H) sits inside of the recess on the plastic mounting bracket on Crank Handle (G). Retighten the set screw on Crank Handle Sync Rod (H). NOTE: Leave at least 1.5″ (40mm) of space from the mounting holes on Crank Handle (G) to the edge of the desktop, which will allow the crank to be fully pushed in.

1 H

T-A

Handle Sync Rod Extension (I).

If the desktop is too wide,

replace the hex rod inside Crank

Handle Sync Rod (H) with Crank

1.5″

S-D

G Crank Handle

H Crank Handle Sync Rod

T-A 2.5mm Allen Wrench

STEP 9: Adjusting the Height
Turn Crank Handle (G) counter clockwise to raise the desk, and clockwise to lower. Slide Crank Handle (G) in and flip the handle around to store it when not in use.
