Product Information

The portable generator model 201160 by Champion Power Equipment
is a high-powered generator with a starting wattage of 15000 and a
running wattage of 12000. It features a powerful Milwaukee Series
V-Twin Engine with a displacement of 717cc. The generator runs on
gasoline and has a fuel capacity of 11 gallons. It is equipped with
an electric start that includes a battery, allowing for easy
push-button starting. The generator also comes with a 5-MODE
display for convenient monitoring.

The generator is designed to provide up to 9 hours of run time
on a full tank of gasoline. It has a noise level of 78 dBA,
ensuring quiet operation. The generator is equipped with covered
outlets to protect them from the elements. It also features a VOLT
GUARD system that protects against power surges. Additionally, the
generator has a COLD START feature, making it easy to start in cold
weather conditions.

The generator has multiple receptacles for different power
needs. It includes a 50 AMP 120/240 V outlet (14-50R), a 30 AMP
120/240 V outlet (L14-30R), a 30 AMP outlet, and two 20 AMP GFCI
outlets. The generator is UPC certified with the code
817198025766.

The generator comes with a warranty of 3 years, providing peace
of mind to the users. It meets EPA III emissions standards, making
it environmentally friendly. The specifications of the generator
include an electric start, a voltage of 120/240 V, an AC voltmeter
with Power Meter (Intelligauge), and a low oil shut-off feature.
The recommended oil type is 5W-30, and the oil capacity is
specified as 1400/47.3 fl. oz./mL.

Product Usage Instructions

Before using the generator, ensure you have the following
items: gasoline, wrench/socket set, pliers, and a Phillips
screwdriver.
Place the generator in a well-ventilated area, away from
flammable materials.
Check the fuel level and add gasoline as needed. Use the
recommended oil type and fill it to the specified capacity.
Connect any necessary equipment or appliances to the
appropriate outlets on the generator.
Ensure that the generator’s circuit breaker is in the OFF
position before starting.
If using the electric start, ensure the battery is properly
installed and charged.
Turn the engine switch to the ON position.
If using the electric start, press the push-button start to
initiate the starting sequence. If using the recoil start, pull the
starter cord firmly and briskly.
Once started, allow the generator to warm up for a few minutes
before connecting any sensitive equipment.
Monitor the generator’s performance using the 5-MODE display
and adjust load as necessary to prevent overloading.
After use, turn the engine switch to the OFF position and
disconnect any connected equipment.
Allow the generator to cool down before refueling or
storing.
Perform regular maintenance as outlined in the operator’s
manual to ensure optimal performance and longevity of the
generator.

View Fullscreen

PORTABLE
GENERATOR

15000 12000

STARTING WATTS

RUNNING WATTS

RUN TIME 9 hrs.

NOISE LEVEL 78 dBA

Model 201160

5-MODE display
ELECTRIC START
Push-button start includes BATTERY
COVERED OUTLETS
PROTECT outlets from the elements
VOLT GUARD
Protects against POWER SURGES
COLD START
Easy starts in COLD WEATHER
Receptacles

UPC 817198025766

M I LWAU K E E S E R I E STM
Warranty 3 Years

50 AMP 120/240 V,
14-50R

30 AMP 120/240 V, L14-30R

30 AMP

20 AMP GFCI 20 AMP GFCI

120 V, L5-30R 120 V, 5-20R 120 V, 5-20R

Specifications

START TYPE VOLTAGE (V) AC VOLTMETER ENGINE SIZE (cc) FUEL TYPE GASOLINE CAPACITY (gal.) OIL TYPE OIL CAPACITY (fl. oz./mL) LOW OIL SHUT-OFF EMISSIONS

Electric 120/240 Intelligauge w/ Power Meter 717 Gasoline 11 5W-30 1400/47.3 Yes EPA III

Our powerful 12,000-watt generator provides up to 9 hours of run time on a full tank of gasoline. The massive 717cc Milwaukee Series V-Twin Engine with battery-included electric start features Intelligauge and has all the power you need and more for home backup during an outage or your next project.

Inside the box

GENERATOR WHEEL KIT BATTERY

OPERATOR’S MANUAL OIL FUNNEL ENGINE OIL

What You Need

GASOLINE WRENCH/SOCKET SET

PLIERS PHILLIPS SCREWDRIVER

*Specifications, descriptions and illustrations are subject to change without notice.

PACKAGE (gross)
Weight: 358 lb. Size: 33.3 x 27.2 x 33.1 in.

PRODUCT (net)
Weight: 328.7 lb. Size: 33 x 33.7 x 33.1 in.
