75006 ESD Cleanroom Booties

Product Information:

The Desco ESD Cleanroom Booties are specially designed for
personnel who need to be grounded via a Flooring/Footwear System
according to ANSI/ESD S20.20 standards. These booties are available
in different sizes to accommodate various shoe sizes.

Features:

Blue texturized polyester with carbon mono-filament nylon upper
surface
3/8″ wide, 18″ long polyester ribbon containing 8 electrically
conductive carbon suffused fibers
1/4″ socket snap for secure closure at the top of the
shoes
Dual-layer rubber material with a black conductive inner layer
and a dark blue dissipative outer layer bottom surface to prevent
scratching or marking of the flooring
Rtt (Tab to Bottom resistance): 5 x 10^4 to 5 x 10^6 ohms
tested per ESD TR53

Product Usage Instructions:

Ensure that the Desco ESD Cleanroom Booties are worn by
personnel who are properly grounded through a Flooring/Footwear
System per ANSI/ESD S20.20.
Place the grounding tab of each bootie inside the person’s shoe
under their foot, with the grounding tab portion at the bottom of
the bootie in contact with the ESD flooring.
Wear the booties on both feet.
Before wearing the booties, test them using a footwear tester
(with a lower limit of 50 kilohms and an upper limit of 35 megohms)
according to ESD TR53.
Compliance verification should be performed prior to each use,
such as at the start of each day or shift change, to ensure proper
functionality.
If the foot grounders are worn outside the ESD protected area,
consider testing them for functionality before re-entering the ESD
protected area.

Note: Specifications and procedures are subject to change
without notice. For more information and support, please refer to
the contact details provided.

View Fullscreen

B C

Item 75006 75007

Description Cleanroom Bootie, Small, 6 – 7-1/2 Cleanroom Bootie, Medium, 8 – 9-1/2

75008 Cleanroom Bootie, Large, 10 -11 75009 Cleanroom Bootie, XLarge, 11-1/2 – 12-1/2

75010 Cleanroom Bootie, 2XLarge, 13 – 14 75011 Cleanroom Bootie, 3XLarge, 14-1/2 – 15-1/2

Because the actual outside dimensions of shoes vary within a size, the above sizing is approximate.

Unless specified tolerance ±10%

Description
Desco ESD Cleanroom Booties are designed to be worn by personnel grounded via a Flooring/Footwear System per ANSI/ESD S20.20.
“ESD protective flooring, used with approved footwear, may be used as an alternative to the wrist strap system for standing operations.” [ANSI/ESD S20.20 section 6.2.2.2] Desco ESD Cleanroom Booties are to be worn with grounding tab placed in the person’s shoe under their foot with grounding tab portion at bottom of the Bootie in contact with ESD flooring. Booties are to be worn on both feet, and while worn should be tested per ESD TR53 using a footwear tester (with lower limit of 50 kilohms and 35 megohms upper limit). It is a suitable ESD footwear component in ANSI/ESD S20.20 Flooring/Footwear System tested per ANSI/ESD STM97.1. A
Components:
A. Blue texturized polyester with carbon mono-filament nylon upper surface. B. 3/8″ wide, 18″ long polyester ribbon contains 8 electrically conductive carbon suffused
fibers. C. 1/4″ socket snap allows the bootie to be securely closed at top of shoes.
D. Dual layer rubber material, black conductive inner layer, and dark blue dissipative outer layer bottom surface. Designed not to scratch or mark flooring.

NOTE: “Compliance verification should be performed prior to each use (daily, shift change, etc.). The accumulation of insulative materials may increase the foot grounder system resistance. If foot grounders are worn outside the ESD protected area testing for functionality before re-entry to the ESD protected area should be considered.” [ESD SP9.2 APPENDIX B – Foot Grounder Usage Guidance] Tab to Bottom resistance:
Rtt: 5 x 104 to 5 x 106 ohms tested per ESD TR53

Specifications and procedures subject to change without notice.
CLEANROOM BOOTIE
DESCO WEST: 3651 WALNUT AVE., CHINO, CA 91710 WEB SITE: Desco.com PHONE (909) 627-8178 DESCO EAST: ONE COLGATE WAY, CANTON, MA 02021-1407 PHONE (781) 821-8370

Made in the United States of America

DRAWING NUMBER
75006

DATE: December
2022
