P-2BPM-01 Heavy-Duty Telescopic Mast with 5-8 Inch Baby Pin
Product Information
The Proaim Heavy-Duty Telescopic Mast w 5/8 Baby Pin (P-2BPM-01)
is a versatile accessory designed to mount a light, monitor, or
another accessory to a Soundchief cart (not included). The mast is
made of durable materials and has a maximum height of 50 inches
when fully extended. It has two sections, with the bottom one
having a diameter of 25mm and the upper one having a diameter of
19mm. The assembly comes with a baby pin that can be inserted into
the center mast bracket of the Soundchief cart, providing a secure
mounting point for your accessories.
Product Usage Instructions
- Inspect the contents of the package to ensure that you have
received everything listed in the box. - Loosen and remove the bolt of the top handle of a Soundchief
cart (not included) using a spanner-12 or 4mm Allen key. Repeat
this process for all bolts of the top handle. - Loosen the knob of the center mast bracket of the Soundchief
cart and insert the baby pin into the center mast bracket. - Tighten and secure the knob of the center mast bracket.
- Adjust the telescopic height of the baby pin by loosening the
quick locking knob. - Attach the VESA Monitor Mount (not included) to the LCD Monitor
(not included). Then, mount the VESA mount on the baby pin (5/8)
matching the main hole, and secure the assembly by tightening the
knob.
With these simple steps, you can use your Proaim Heavy-Duty
Telescopic Mast w 5/8 Baby Pin to mount your accessories to a
Soundchief cart and take your production to the next level.
1
Heavy-Duty Telescopic Mast w 5/8″ Baby Pin (P-2BPM-01)
Assembly Manual
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that is listed below.
Proaim Heavy-Duty Telescopic Mast w 5/8″ Baby Pin
All rights reserved. No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means, electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright
statutes or in writing by the Publisher.
Baby Pin Setup
Loosen & remove the bolt of a top handle of a Soundchief cart (Not Included) using a (spanner-12) or (4mm) Allen key.
Follow the same process to remove all the bolts of the top handle.
Loosen the knob of the center mast bracket of the Soundchief cart (Not Included), and then align and insert a baby pin into the center mast bracket.
After inserting the baby pin, tighten and secure the knob of the centre mast bracket.
Adjust the telescopic height of the baby pin accordingly by loosening the quick locking knob of a baby pin, as shown in the image.
NOTE: The riser has a 5/8″ baby pin on the top and extends from 28 to 50″. It has 2 sections bottom one has a diameter of 25mm, and the upper one has a 19mm diameter.
2
28 to 50″ extends height
3
Attach the VESA Monitor Mount (Not Included) to the LCD Monitor (Not Included). Then, Mount the VESA mount on the baby pin (5/8″) matching the main hole, and secure the assembly by tightening the knob.
NOTE: It is used to mount a light, monitor, or another accessory to Sound chief cart.
YOUR PROAIM HEAVY-DUTY TELESCOPIC MAST W 5/8″ BABY PIN ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
