WB-1410110-2 Screen Printing Kit

Product Information:

The product is a screen printing kit with the model number
WB-1410110-2. The kit includes various accessories such as plastic
and wood scrapers, wood sticks, silver masking tape, ink spatulas,
screen printing frames, and inkjet transparency films. The kit is
designed to provide users with a comprehensive set of tools
required for screen printing. The kit is ideal for beginners or
people who want to do screen printing at home.

Accessories List:

No.	Name	Quantity	Main application	Picture
1	Plastic Scraper	2pcs	The function of plastic scraper is the same as wood screen printing squeegee, helping print to print smaller image.
2	Wood Sticks	10 pcs	Wood sticks can help to mix and transfer the ink, as well as the emulsion.
3	Silver Tape	1 roll	Masking tape
4	Wood Squeegee	1 roll	N/A
5	A4 Size Inkjet Transparency Film	5pc	Widely used in screen printing, they can help you transfer the design you want.
6	Stainless Steel Spatulas	1pc	This easy-to-clean ink spatula also helps you mix ink as needed without any problems even after prolonged use.
7	Screen Printing Frames	2pcs	Two kinds of aluminium screen printing frames with 2 kind of screen printing squeegees, must be the great work partner with this screen printing frames to meet your different printing needs, (10×14 & 8×10) with 110 white mesh.

Product Usage Instructions:

STEP 1: Prepare the image

(This step would use transparency film from this kit)

1. Use transparency film and inkjet printer to print out the image
   you want, make sure the image is in black to achieve a better
   opaque effect, it is better to use tape to overlap the 2-3 same
   films together.
2. Print on the non-smooth side of the film, if you print on the
   glossy uncoated side, the ink will not dry because it is not
   absorbed by the coating.

STEP 3: Preparing the Screen for Exposure

(This step would use screen printing frame and transparency film
from this kit)

1. When your screen is dry, take your screen out of its cool dark
   place(but still in a dim area).
2. Place the screen on black fabric or other black things, it can
   help reduce reflection. Turn the screen with the emulsion back
   up.
3. Place your image onto the screen IN REVERSE.
4. Place a clean piece of glass over the image to hold it tight
   against the screen.

STEP 4: Exposing the Screen

(This step would use screen printing frame and transparency film
from this kit)

Turn your UV exposure unit on. The time of expose your image
will depend mostly on your light source. There is an example for
reference: 10 x 14 inch screen with 150W bulb and 12 inches height
needs 10 minutes exposure.

STEP 5: Washing the Screen

(This step would use screen printing frame from this kit)

1. Use a sprayer or hose to spray water at the screen. After a few
   minutes, the emulsion will start to dissolve.
2. Rub both sides of the screen with a soft brush or sponge until
   the image appears.
3. Rinse the screen with water and let it dry.

Technical Support and E-Warranty Certificate www.vevor.com/support
SILK SCREEN FRAME ACCESSORIES LIST AND APPLICATION INSTRUCTIONS
We continue to be committed to offering tools at competitive prices. “Save Half”, “Half Price”, or any other similar expressions used by us only represent an estimate of savings you might
benefit from buying certain tools with us compared to the major top brands and do not necessarily mean to cover all categories of tools offered by us. You are kindly reminded to verify carefully when placing an order with us if you are saving half in comparison with the top
major brands.

Accessories list and application instructions

Product modelWB-1410110-2

No. Name

Quantity Main application


Plastic

1

2pcs

Scraper

The function of plastic scraper is the same as wood screen printing squeegee, helping print to print smaller image.

Wood 2
Sticks

10 pcs

Wood sticks can help to mix and transfer the ink, as well as the emulsion.

3

silver tape 1 roll

Masking

4

1 roll

tape

The function of this tape ensure unwanted ink will not leak out from all the edges of screen, which have stronger stickiness and higher temperature resistance than ordinary tapes. Masking tape can be quickly peeled off and torn after use, and is almost traceless, protecting your design from interference, so it is perfect for paint printing projects. The function of this tape ensure unwanted ink will not leak out from all the edges of screen, which have stronger stickiness and higher temperature resistance than ordinary tapes.

1

Wood

5

1pc

squeegee

This is the basic tool for your printing job. The size is 18cm.

A4 Size

Inkjet

6

5pc

Transpare

ncy Film

Widely used in screen printing, they can help you transfer the design you want.

Stainless

7

steel

1pc

spatulas

2 sizes

screen

8

2pcs

printing

frames

This easy-to-clean ink spatula also helps you mix ink as needed without any problems even after prolonged use.
Two kinds of aluminium screen printing frames with 2 kind of screen printing squeegees, must be the great work partner with this screen printing frames to meet your different printing needs, (10×14″ & 8×10″) with 110 white mesh.

Multiple Use: You can print patterns on T-shirts, canvas tote bags, and tank tops with this screen printing starter kit. This is a great family activity for beginners or people that’s doing it at home.

INSTRUCTIONS Screen Printing Kit STEP 1: Prepare the image
2

(This step would use transparency film from this kit) 1. Use transparency film and inkjet printer to print out the image you want, make sure the image is in black to achieve a better opaque effect, it is better to use tape to overlap the 2-3 same films together. 2. Print on the non-smooth side of the film, if you print on the glossy uncoated side, the ink will not dry because it is not absorbed by the coating.
STEP 2: Applying Photo Emulsion to the Screen (This step would use screen printing frame and screen printing squeegee from this kit) 1. Do this step in a dark room since the photo emulsion reacts to light, spread a small amount of the photo emulsion on one side of the screen bottom. 2. Use the scoop coater or squeegee to spread a thin layer of the emulsion across the screen(both side), until the whole screen are covered with emulsion. Place your finished screen in a cool dark place for a few hours or overnight to let it dry.
3

STEP 3: Preparing the Screen for Exposure (This step would use screen printing frame and transparency film from this kit) 1. When your screen is dry, take your screen out of its cool dark place(but still in a dim area). 2. Place the screen on black fabric or other black things, it can help reduce reflection. Turn the screen with the emulsion “back” up. 3. Place your image onto the screen IN REVERSE. 4. Place a clean piece of glass over the image to hold it tight against the screen.
STEP 4: Exposing the Screen (This step would use screen printing frame and transparency film from this kit) Turn your UV exposure unit on. The time of expose your image will depend mostly on your light source. There is an example for reference: 10 x 14 inch screen with 150W bulb and 12 inches height needs 10 minutes exposure.
STEP 5: Washing the Screen (This step would use screen printing frame from this kit) 1. Use a sprayer or hose to spray water at the screen. After a few minutes the
4

screen will start to open up and the image areas will start washing away leaving your “stencil.” 2. Dry the screen with newspaper or a towel (Do not rib in case the emulsion is still wet) and leave it to dry off. If the areas do not wash away you may have overexposed the screen, and you will need to use the “emulsion remover”(not include in this kit) to clean the screen and start the process over, exposing it for much less time.
STEP 6: Tape the screen perimeter (This step would use screen printing frame and masking tape from this kit) During the printing process, unwanted ink sometimes leaks through the edges of the frame and seeps onto the substrate. To prevent this, use masking tape to cover all the inside edges of youro screen to prevent any ink from leaking through.
STEP 7: Printing (This step would use screen printing frame, screen printing squeegee and wood sticks from this kit) 1. Place your screen flat onto the fabric that you are preparing to print (if it is a T-shirt make sure to place a piece of cardboard inside to prevent ink from soaking
5

to the other side). Apply a small glob of ink at the top of side of the image. 2. Use wood sticks transfer the ink onto the screen and pull the ink down the screen with the squeegee. Y During the printing process, unwanted ink sometimes leaks through the edges of the frame and seeps onto the substrate. To prevent this, use masking tape to cover all the inside edges of youro screen to prevent any ink from leaking through.
STEP 8: Finished work display After you finished the screen painting work, please clean the wooden frame and mesh, and put it to dry location, which is convenient for your next use.
6

Technical Support and E-Warranty Certificate www.vevor.com/support
