0010 Portable Paint Booth
Product Information
The Portable Paint Booth is a product offered by VEVOR. It comes
in two models, 0010 and 0011, with different dimensions and
materials. The product is made of Oxford-fabric 210D and is
available in white color. It features a ventilation window and
8.5mm pole. The package contents include Portable Paint Booth,
Pole, Stake, Storage Bag, Plastic Wrap, and User Manual.
Product Usage Instructions
- Safe Instructions: Before operating the
product, carefully read all instructions and procedures for safe
operations. - Installation Instruction: Follow these steps
to install the Portable Paint Booth:- Unfold the tent and spread it out on a clean and level surface
with the opening oriented towards the front. - Lay out two of the long poles and interlock all segments.
- Insert poles through the tent sleeves, forming an X shape on
the sides of the tent. - Insert the four ends of the two poles into the bottom of the
four corners of the tent, as shown in the picture. - Attach frame clips located in the tent section to the tent and
clip them into place. - Tie a bow on the side of the tent where the two poles form an
X. - If you need to use the tent on grass, please fasten the tent
with stakes at the bottom loops and corners.
- Unfold the tent and spread it out on a clean and level surface
- Storage: Follow these steps to store the
Portable Paint Booth:- Take out the four corners of the stakes.
- Untie the knot in two places.
- Release clips (16pcs).
- Take out all four corners of the poles, as shown in the
picture. - Pull the two poles out of the tent.
- Put the combination rod away as shown in the figure and put it
into the storage bag. - Lay the tent flat and fold it as shown in the picture.
- Roll the bagging poles and tent together and load into the
large storage bag as shown in the picture.
- Operation Guide: Follow instructions provided
in the user manual for proper operation of the product. - Troubleshooting, Maintenance, and Repair:
Contact [email protected] for any product-related queries
or technical support.
Support and E-Warranty Certificate https://www.vevor.com/support
PORTABLE PAINT BOOTH USER MANUAL
We continue to be committed to offering tools at competitive prices. “Save Half”, “Half Price”, or any other similar expressions used by us only represent an estimate of savings you might
benefit from buying certain tools with us compared to the major top brands and do not necessarily mean to cover all categories of tools offered by us. You are kindly reminded to verify carefully when placing an order with us if you are saving half in comparison with the top
major brands.
MODEL:0010/0011
Portable Paint Booth
NEED HELP? CONTACT US! Have product questions? Need technical support? Please feel free to contact us:
[email protected]
This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won’t inform you again if there are any technology or software updates on our product.
1
1.SAFE INSTRUCTIONS
Warning: 1. Spray paints and solvents can be dangerous if inhaled. Ensure you have good ventilation at all times. 2. Keep away from heat, sparks, and open flames when painting. Don’t smoke. 3. When painting, make sure to keep the ventilation. 4. Paint is harmful to the body. Avoid contact with eyes and skin. Please take good protection. 5. When painting, avoid prolonged exposure to the sun. 6. When painting, lighting and electrical devices must be properly protected to avoid accidents or personal injury. 7. For best results, avoid painting in hot, humid weather. 8. Recycle the used paint cans to avoid environmental damage.
CAUTION: Carefully read instructions and procedures for safe operations.
2
2.PRODUCT INTRODUCTION
SPEC. Size Material Color
Model
Ventilation window
Pole
0010
90*62*62 in Oxford-fabric 210D
White 60*40cm 8.5mm
0011
120*84*72 in Oxford-fabric 210D
White 60*40cm 8.5mm
3.PACKAGE CONTENT
Parts
Model
Portable Paint Booth
Pole
Stake
Storage Bag
Plastic Wrap
User Manual
0010
×1 ×2 ×6 ×1 ×1 ×1
3
0011
×1 ×2 ×6 ×1 ×1 ×1
4.PRODUCT DIAGRAM
10010
No.
Item
Qty
1
Portable Paint Booth
1
2
Pole
2
3
Clip
16
4
Rope
2
5
Front Gauze Curtain
1
6
Foot Clasp
4
7
Ventilation Window
1
4
20011
No.
Item
Qty
1
Portable Paint Booth
1
2
Pole
2
3
Clip
16
4
Rope
2
5
Front Gauze Curtain
1
6
Foot Clasp
4
7
Ventilation Window
1
5
5.INSTALLATION INSTRUCTION
1. Unfold the tent and spread it out on a clean and level surface with the opening oriented towards the front.
2. Lay out two of the long poles and interlock all segments.
3. Insert poles through the tent sleeves, forming an “X” shape on the sides of the tent.
4.Insert the four ends of the two poles into the bottom of the four corners of the tent, as shown in the picture.
Attach frame clips located in the tent section to the tent and clip them into place.
Tie a bow on the side of the tent where the two poles form an “X”.
7. If you need to use the tent on grass, please fasten the tent with stakes at the bottom loops and corners.
6
Storage Take out the four corners of the stakes.
2. Untie the knot in two places.
Release clips (16pcs)
Take out all four corners of the poles, as shown in the picture.
Pull the two poles out of the tent.
Put the combination rod away as shown in the figure and put it into the storage bag.
Lay the tent flat and fold it as shown in the picture.
Roll the bagging poles and tent together and load into the large storage bag as shown in the picture.
7
6.OPERATION GUIDE
Step 1. Assemble the portable paint booth. Step 2. Roll up the front gauze curtain. Step 3. Cover the bottom with the plastic wraph. Step 4. The portable paint booth is ready for use. AttentionThis product is not waterproof. Please do not use it outdoor in rainy days. For larger furniture, it is recommended to paint the front and top first and then dry the bottom and back. 2) For Small furniture, it is recommended to configure a rotating tray, small furniture placed on the rotating tray spray paint.
7. TROUBLESHOOTING, MAINTENANCE, AND REPAIR
1. To remove stains, clean with cold water and use mild remover if necessary. Do not use a strong stain remover to avoid damage to the fabric or local fading. 2. Do not use a washing machine or dryer to clean the tent to avoid causing fabric damage. 3. After cleaning, please spread the tent indoors or outdoors in a cool place to dry; Do not expose it to the sun to avoid damage to the fabric. 4. Check the tent regularly to see if there is any damage. If there is any damage, please repair it in time. You can use a waterproof repair subsidy to repair the damaged parts.
8
5. After each use, check whether the nail is damaged or bent. If it is damaged, replace it in time. If it is bent, straighten it with a hammer. 6. Check the pole after each use. If damaged, replace it in time. 7. Please store the tent in a dry and cool place, away from direct sunlight and damp places. 8. When the tent is stored, try to let it loose naturally, which can extend the service life of the tent, and put some desiccant to moisture-proof. Manufacturer: Zhejiang Roy Industrial Co., Ltd Add: No.8, Juhai Second Road, Qujiang District, Quzhou City, Zhejiang Province
9
