Sewoo Lk-p24 Mobile Printer User Manual

sewoo LK-P24 Mobile Printer User Manual

Features

• Fast Print Speed : 4 ips
• AMC (Advanced Manual Cutter) supproted – By Pushing a button, Easily paper cut
• Excellent compatibility
• NFC for easy Bluetooth pairing
• Durable and resistant to water and dust
• S-MDM (SSM & SCM)
• Accessories : Shoulder Strap, Belt Strap, Car Charger

APPLICATION

SPECIFICATIONS

PRINTER CHARACTERISTICS

• Print Method
  Direct thermal
• Print Speed
  Up to 3.9ips (100mm/sec)
• Print Width
• LK-P24 : Up to 1.8” (48mm)
• LK-P34 : Up to 2.8” (72mm)
• Resolution
  203 dpi (8dots/mm)
• Memory
• LK-P24 : 8MB(Max 64MB), SDRAM 8MB
• LK-P34 : 8MB(Max 64MB), SDRAM 8MB (MAX.16MB)
• Battery Voltage / Capacity
• Rechargeable Li-ion battery
• LK-P24 : 7.4V / 1,450mAh
• LK-P34 : 7.4V / 2,000mAh
• Battery Charge time
• LK-P24 : Max. 1.7Hrs
• LK-P34 : Max. 2.7Hrs
• Standby Time
• LK-P24 : Max. 36Hrs
• LK-P34 : Max. 61Hrs
• Sensor
• LK-P24 : Paper end, Black mark sensor
• LK-P34 : Paper end, Black mark sensor
• Reliability
• TPH life : 50km

 PHYSICAL CHARACTERISTICS

• Dimension (W x D x H)
• LK-P24 : 3.2”×4.77”×1.78”
  (81.5 x 121.4 x 45.3mm)
• LK-P34 : 4.23”×5.70”×2.20”
  (107.5 x 145 x 56mm)
  Weight
• LK-P24 : 0.5lb(264g, With battery)
• LK-P34 : 0.9lb(422g, With battery)

 MEDIA CHARACTERISTICS

• Media Type
  Thermal paper
• Media Width
  LK-P24 : 2.2” (58mm)
  LK-P34 : 3.1” (80mm)
  Paper guide (58mm)
• Media Core Diameter
  0.4” (12.5mm)
• Media Roll Diameter
  1.5” (40mm)
  LK-P24 : ø40
  LK-P34 : ø50
• Thickness
  0.06mm

 OPERATING CHARACTERISTICS

• Operating Temperature
  14~122℉(-10 ~ 50℃)
• Operating Humidity
  10 ~ 80%
• Storage Temperature
  -4~140℉(-20 ~ 60℃)
• Storage Humidity
  10 ~ 90%
• Dust-and Water-resistance Rating
  LK-P24 : IP43
  LK-P34 : IP54
• Drop Rating
  5ft/1.5m (set only) to concrete

 BARCODES

• 1D
  EAN-8, EAN-8(+2+5), EAN-13,
  EAN-13(+2+5), Codabar, Code11,
  Code39, Code93, Code128, ITF,
  LUPC-A(+2+5), UPC-E, UPC-E(+2+5),
  Planet, UPC-A etc
• 2D
  QR, PDF417, MicroPDF417, Maxicode,
  Datamatrix, Aztec, RSS14, TLC39

 CERTIFICATIONS

KC, CE, FCC, IC, UL/cUL, Mfi, UKCA, BCS,CCC

 SOFTWARE

Emulations
ESC / POS, CPCL, ZPL Command compatible
Drivers
Windows Driver(XP ~, Server2003 ~),
Window CE & Mobile Driver & SDK
(CE 4.2~, Mobile 5.0~), Linux Driver,
Mac Driver, OPOS Driver,
JavaPOS Driver, iOS SDK,
Android(6.0 ~) SDK

 ACCESSORIES

• Standard
  LK-P24 : USB cable, Battery pack,
  Thermal roll paper, Belt strap &
  Bracket, Battery Charger (8.4V)
  LK-P34 : USB Cable, Battery pack,
  Thermal roll paper, Belt strap,
  Battery Charger (8.4V)
• Option
  LK-P24 : Set cradle, Leather case +
  Shoulder Strap
  LK-P34 : 4bay cradle, Battery cradle,
  Shoulder Strap, Leather Case

 FONTS / GRAPHICS

• Character Type
  Font A(12×24), Font B(9×17), Asian Font
  (KOR, JPN, CHN-GB2312, CHN-Big5),
  Font0/1/2/4/5/6/7, Resident TTF ,
  Downloadable TTF, FontA~H, FontGS,
  Residnt TTF(Font0), Font 1~8
• Characters per line (CPL)
  LK-P24: Font A(12×24): 32cpl,
  Font B(9×17): 42cpl,
  LK-P34: Font A(12×24): 48cpl,
  Font B(9×17): 64cpl,
• Character set
  95 Alphanumeric, 14 International,
  128 x 18 Graphic

 INTERFACES

• Standard
  USB
• Optional
  Wi-Fi(802.11a/b/g/n),
  Bluetooth Smart Ready
  (Bluetooth4.2+BLE), NFC Tag

Support
