RS220121L6 Vanity Light Fixture
Product Information: 3-Light Vanity Fixture
The 3-Light Vanity Fixture is a high-quality lighting solution
designed to enhance your home. The product comes with a
pre-assembled mounting unit, mounting screws, and wire nuts that
make installation easy. The fixture requires a Phillips
screwdriver, flat blade screwdriver, pliers, and wire strippers for
installation. The product comes with a one-year warranty that
covers any defects in materials or workmanship.
Product Usage Instructions: Installation
- Before starting installation of this fixture or removing a
previous fixture, disconnect the power by turning off the circuit
breaker or by removing the fuse at the fuse box. - Inspect the wire insulation for any cuts, abrasions, or exposed
copper that may have resulted during shipping. If there is a defect
in the wire, do not attempt installation. Please call Hampton Bay
Customer Service at 1-855-HD-HAMPTON. - Secure the pre-assembled mounting unit with the provided
mounting screw. - Connect the black (positive) wire to the power wire and the
white (neutral) wire to the neutral wire with the provided wire
nuts (CC) and secure with electrical tape (not included). If the
wires from the fixture are of the same color, attach the side with
markings or letters to the black (positive) wire and the other to
the white (neutral) wire. - Secure the light fixture to the mounting unit (AA).
Product Usage Instructions: Operation
- To turn the light on, simply flip the switch connected to the
circuit breaker or fuse box.
Product Usage Instructions: Care and Cleaning
To clean the 3-Light Vanity Fixture, turn off the power and
allow the fixture to cool. Use a soft, damp cloth to wipe down the
fixture. Do not use abrasive cleaners or cloths, as they may damage
the fixture’s finish.
Product Usage Instructions: Troubleshooting
| Problem | Possible Cause |
|---|---|
| The bulb will not light. | The bulb is burned out. The power is off. There is a faulty wire connection. |
| The fuse blows or circuit breaker trips when the light is turned on. | The circuit breaker is off. There are crossed wires or the power wire is grounding out. |
Item# 1000644212 Model# RS220121L3
USE AND CARE GUIDE
3-Light Vanity Fixture
Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service
8 a.m. – 7 p.m., EST, Monday-Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HOMEDEPOT.CA THANK YOU
We appreciate the trust and confdence you have placed in Hampton Bay through the purchase of this light fxture. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for
your home improvement needs. Thank you for choosing Hampton Bay!
Table of Contents
Table of Contents ……………………………………………………………………..2 Safety Information ……………………………………………………………………2 Warranty …………………………………………………………………………………2 Pre-Installation ………………………………………………………………………..3
Planning Installation ……………………………………………………………3 Tools Required …………………………………………………………………..3
Hardware ………………………………………………………………………….3 Package Contents ………………………………………………………………4 Installation ………………………………………………………………………………5 Operation ………………………………………………………………………………..6 Care and Cleaning ……………………………………………………………………6 Troubleshooting ……………………………………………………………………….6
Safety Information
´ Consult a qualified electrician if you have any electrical
questions.
CAUTION: Inspect the wire insulation for any cuts, abrasions, or exposed copper that may have resulted during shipping. If there is a defect in the wire, do not attempt installation. Please call our Customer Service Team at 1-855-HD-HAMPTON.
WARNING: Before starting installation of this fixture or removal of a previous fixture, disconnect the power by turning off the circuit breaker or by removing the fuse at the fuse box.
Warranty
The manufacturer warrants this lighting fixture to be free from defects in materials and workmanship for a period of three (3) years from date of purchase. This warranty applies only to the original consumer purchaser and only to products used in normal use and service. If this product is found to be defective, the manufacturer’s only obligation, and your exclusive remedy, is the repair or replacement of the product at the manufacturer’s discretion, provided that the product has not been damaged through misuse, abuse, accident, modifications, alterations, neglect, or mishandling. This warranty shall not apply to any product that is found to have been improperly installed, setup, or used in any way not in accordance with the instructions supplied with the product. This warranty shall not apply to a failure of the product as a result of an accident, misuse, abuse, negligence, alteration, faulty installation, or any other failure not relating to faulty material or workmanship. This warranty shall not apply to the finish on any portion of the product, such as surface and/or weathering, as this is considered normal wear and tear. The manufacturer does not warrant and specially disclaims any warranty, whether express or implied, of fitness for a particular purpose, other than the warranty contained herein. The manufacturer specifically disclaims any liability and shall not be liable for any consequential or incidental loss or damage, including but not limited to any labor / expense costs involved in the replacement or repair of said product.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit homedepot.ca.
2
HOMEDEPOT.CA
Please contact 1-855-HD-HAMPTON for further assistanc.e.
Pre-Installation
PLANNING INSTALLATION
´ Read all instructions before installation. ´ To avoid damaging this product, assemble it on a soft, non-abrasive surface, such as carpet or cardboard. ´ Keep your receipt and these instructions for proof of purchase.
TOOLS REQUIRED
Ladder
Safety glasses
HARDWARE INCLUDED
Electrical tape
Phillips screwdriver
Flat blade screwdriver
NOTE: Hardware not shown to actual size.
Pliers
Wire strippers
___________AA
___________BB ___________CC
Part
Description
AA
Mounting unit (pre-assembled
with light fixture)
BB
Mounting screw
CC
Wire nut
Quantity 1
2 3
3
HOMEDEPOT.CA
Please contact 1-855-HD-HAMPTON for further assistance..
Pre-Installation (continued)
PACKAGE CONTENTS
A
Part
Description
A
Light fixture
Quantity 1
4
HOMEDEPOT.CA
Please contact 1-855-HD-HAMPTON for further assistance. .
Installation
1 ATTACHING THE MOUNTING UNIT TO THE JUNCTION BOX ´ Remove the pre-installed socket ring from the socket of lamp base (A) and put them in a safe location. Attach the mounting unit (AA) to the junction box (not included) with the mounting screws (BB).
AA
2 MAKING THE ELECTRICAL CONNECTIONS
´ Connect the copper wire from the light fixture (A) to the
mounting unit (AA) by securing it with the pre-installed ground screw.
´ Connect the black to black (power), the white to white
(neutral) and copper wire to ground wire with the wire nuts (CC) and secure with electrical tape (not included).
NOTE: If the wires from the fixture are the same color, attach the side with markings or letters to the black (positive) wire and the other to the white (neutral) wire.
CC BB
3 SECURING THE LIGHT FIXTURE
´ Secure the light fixture (A) by placing it over the mounting unit (AA) and securing it with the previously removed socket ring.
4 INSTALLING THE LIGHT BULBS ´ Install three 60-watt max. medium-base incandescent bulbs or compatible CFL bulbs (not included).
A
A
5
HOMEDEPOT.CA
Please contact 1-855-HD-HAMPTON for further assistance..
Operation
1 TURNING THE LIGHT ON
´ Turn the light switch on to activate the fixture.
Care and Cleaning
´ Clean the lamp with a soft, dry cloth. ´ Do not use any cleaners with chemicals, solvents, or harsh abrasives.
Troubleshooting
Problem The bulb will not light.
The fuse blows or circuit breaker trips when the light is turned on.
Possible Cause The bulb is burned out. The power is off. There is a faulty wire connection. The circuit breaker is off. There are crossed wires or the power wire is grounding out.
Solution Replace the light bulb. Ensure the power supply is On. Check the wiring. Ensure the circuit breaker is in the On position. Check the wire connections. Contact a qualified electrician or call the Customer Service Team at 1-855-HD-HAMPTON.
6
HOMEDEPOT.CA
Please contact 1-855-HD-HAMPTON for further assistance.
Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service
8 a.m. – 7 p.m., EST, Monday-Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
