X8 Universal Video Processing
Product Information
The X8 is a video processing platform designed for
high-performance and demanding environments where 4K is the norm.
It comes with the industry-leading X series video processing
platform that takes a massive step into the 8K future. The X8
provides unparalleled multi-signal compositing, sync and switching
with low latency while maintaining and enhancing visual fidelity.
The X8 has a modular design that enables higher up times, ease of
maintenance, and operational efficiencies. The X8 supports 8K
multi-cable ultra-high resolution sources in conventional and
panoramic configurations, as well as standard 4K and 2K signal
formats.
Product Usage Instructions
To use the X8, connect your video sources to the input modules
and connect the output modules to your display devices. The X8
provides unparalleled multi-signal compositing, sync and switching
with low latency while maintaining and enhancing visual fidelity.
Open, switch and transition video layers seamlessly with full sync
even across multiple outputs. Transition between multi-signal,
multi-scene presets, and PIP over background layers, bringing
together 4K and spliced 8K sources on demand. The X8 lets you
process high resolution video without compression or loss. It is
4:4:4 native with wide bandwidth in device to process high-quality
video without compromise. Up-sampling of 4:2:0 and 4:2:2 content to
4:4:4 is also supported.
The X8 comes with RGBlink technologies that ensure high
performance very low latency hardware-based video processing.
Synchronisation and delivery of signals of any resolution across
multiple outputs is tear-free and scaled pixel-to-pixel. You can
leverage RGBlink OpenAPI to connect from almost any platform,
allowing integration capabilities that go way beyond simply
triggering presets or scenes. The X8 also comes with the RGBlink
XPOSE 2.0 control platform built right into it and accessible via a
web browser. You can create entire display systems comprised of not
only multiple resolution displays but also displays of any format
or type.
The X8 supports 8K multi-cable ultra-high resolution sources in
conventional and panoramic configurations, as well as standard 4K
and 2K signal formats. For display, configure ultra large displays
across multiple 4K outputs using multiple video layers. The X8
comes with RGBlink XPOSE 2.0, which provides an industry, intuitive
to use configuration and control platform for advanced RGBlink
processors including X8. Signals can be previewed live, multiple
display system containers built, presets created and managed.
Playback facilities include live and broadcast style as well as
scheduled timeline-based options and more. The X8 accepts
BlackBurst in and can synchronize and Genlock to other devices in a
video system. The dedicated HDMI is configurable for up to 64
windows for the ultimate in local monitoring capability.
Redefining 8K Video Processing
Industry leading X series video processing platform takes a massive step into the 8K future with X8. Designed and built for demanding high performance where 4K is the norm, X8 provides unparalleled multi-signal compositing, sync and switching with low latency while maintaining and enhancing visual fidelity.
· Up to 48 4K Layers
Take advantage of powerful multiple 4K layers output up to 48 scaled layers on a fully configured system across 12 4K outputs, with up to six 4K layers on any output port, On this basis, 2 additional layers can be added (select 2 4K2K signal sources from the existing 6 signal sources).
· Seamless 4K & 8K Switching
Open, switch and transition video layers seamlessly with full sync even across multiple outputs. Transition between multi-signal, multi-scene presets, and PIP over background layers, bringing together 4K and spliced 8K sources on demand.
· 8K Source Management
Splice 4K inputs and outputs for 8K operations fully in sync tear and glitch free, retaining the rich visual content even when scaled.
· Full Color Space
Process high resolution video without compression or loss. X8 is 4:4:4 native with wide bandwidth in device to process high quality video without compromise. Up-sampling of 4:2:0 and 4:2:2 content to 4:4:4 is also supported
· Seamless Synchronization
RGBlink technologies ensure high performance very low latency hardware-based video processing. Synchronisation and delivery of signals of any resolution across multiple outputs is tear-free and scaled pixel-to-pixel.
· Build for Integration
Leverage RGBlink OpenAPI to connect from almost any platform, allowing integration capabilities that go way beyond simply triggering presets or scenes.
· Powerful Display Systems Controls
Unlock unique and extensive device capabilities with the RGBlink XPOSE 2.0 control platform built right into X8 and accessible via a web browser. Create entire display systems comprised of not only multiple resolution displays but also displays of any format or type.
· Native IP Streaming
Stream H.264 video sources via the LAN port providing live previews in browser connected XPOSE 2.0 configurations, presets and playlists.
· Lower TCO
Fit modules and components to the X8 system without unneeded overhead or bloat. Hot swap and exchange input and output modules without powering down the overall system. The modular design enables higher up times, ease of maintenance, and operational efficiencies.
· World Leading Development
RGBlink designs, develops and manufactures in house, with unique capabilities and draws from the extensive RGBlink IP pipeline and experience in creating the advanced capabilities in the X8 processing platform.
Live Virtual Control
RGBlink XPOSE 2.0 provides an industry, intuitive to use configuration and control platform for advanced RGBlink processors including X8.
Signals can be previewed live, multiple display system containers built, presets created and managed. Playback facilities include live and broadcast style as well as scheduled timeline-based options and more.
· High Performance Backplane
Maintaining full 4K60 4:4:4 for all signals, the X8 backplane and cross-point offers extreme bandwidth to ensure pixel perfect delivery at every resolution and format.
· Genlock Sync
Synchronise and Genlock to other devices in a video system, with X8 accepting BlackBurst in.
· Configurable Preview
The dedicated HDMI is configurable for up to 64 windows for the ultimate in local monitoring capability.
· Extreme Resolutions
X8 supports 8K multi-cable ultra-high resolution sources in conventional and panoramic configurations, as well as standard 4K and 2K signal formats. For display, configure ultra large displays across multiple 4K outputs using multiple video layers
· Seamless Video Switching
All switching is seamless with no black frames and is glitch/tear free across multiple outputs. Switch between presets with fades and cuts, as well as using transition effects.
· Audio Support
Select embedded audio from any source for re-embedded to any display output.
· Low Latency Cross Conversion
With the best up-down processing engine in the industry, RGBlink offers the widest signal support capabilities and supports unique custom configured resolutions allowing even more video to be controlled, synchronised and delivered to any display.
2
1
Back8gKround
3
4
4K Window
· 8K Workflow Support
Manage multiple 8K sources and output displays combining with other content as needed.
· Multiple 4K Canvas
Splice multiple 4K inputs in any configuration including for landscape or panoramic arrangements.
1 2 3 4
4 3 2 1
4K Source
8K Source
· True 4K Multi-Layer Windowing
Each output slot in X8 supports eight 4K60 layers which maybe assigned freely across outputs, including as eight 4K layers on single 4K output.
Ultra wide canvas
….
4KSignal
4KSignal
4KSignal
4KSignal
Quality without Compromise
Maintain the highest fidelity of source signals without compression or loss with 4:4: YUV/RGB colour space.
Manage video chroma sub-sampling and up-sampling of 4:2:0 and 4:2:2 sources for maximum flexibility.
Flexible Canvas Assignment
The ultimate in flexibility, create layouts in pixel space canvas, mapping sources as layers across positioned displays.
Save and recall layouts and presets on demand for visually engaging experiences powered at the edge with RGBlink X8.
Source 1 Tian
Background 1
Source 2 Ming
Source 3 Lee
Player 1
Player 2
Background 2
Specification
Conncetors Input
Output
PVW Communication
Control Power
Performance Input Resolutions
Output Resolutions
Power Environment Physical
Bandwidth Grey level Color Space HDCP
Input Voltage Max Power Temperature Humidity Weight Dimension
6 input slots,up to 24 inputs
Select from
4K HDMI Module
DP 1.2 Module
12G SDI Module
8K Module(Preliminary)
6 output slots,up to 12 outputs
Select from
4K HDMI Module
DP 1.2 Module
4×HDMI-A 4×DisplayPort 4×BNC 1×HDMI-A + 1×DisplayPort
2×HDMI-A 2×DisplayPort
PVW
1×HDMI-A
USB 3.0
1×USB-A
CTL HDMI
1×HDMI-A
RS 232
1×RJ11
LAN
1×RJ45
Genlock/Sync
2×BNC (1 In | 1 Loop)
LAN Serial Port
1×RJ45 1xRS232
2 slots,up to 2 power inputs
2×IEC(standard configuration comes with 1, another is optional)
Select from below or configure customized HDMI
SMPTE
[email protected]/24/25/29.97/30/50/59.94/60 | [email protected]/24/25/29.97/30/50/59.94/60 | [email protected]/24/25/50/59.94/60
VESA
1024×768@60/75/85 | 1280×768@50/60 | 1280×800@50/60 | 1280×1024@60 | 1360×768@60 | 1400×900@60 |1400×1050@60 | 1600×1200@60 | 1680×1050@60 | 1920×1080@60 | 1920×1200@60 | 2048×1152@60 | 2560×812@60 | 2560×816@60 | 2560×1600@60 | 3840×1080@60 | 3840×2160@50/60 | 4096×2160@60 | 7680×1080@60 | 7680×4320@60 | User Customized Resolution
12G SDI SMPTE
720p@50/60 | 1080p@50/60 | 2160p@50/60
DP SMPTE
VESA
[email protected]/24/25/29.97/30/50/59.94/60 | [email protected]/24/25/29.97/30/50/59.94/60 | [email protected]/24/25/50
1024×768@60/75/85 | 1280×768@50/60 | 1280×800@50/60 | 1280×1024@60 | 1360×768@60 | 1400×900@60 | 1400×1050@60 | 1600×1200@60 | 1680×1050@60 | 1920×1080@60 | 1920×1200@60 | 2048×1152@60 | 2560×812@60 | 2560×816@60 | 2560×1600@60 | 3840×1080@60 | 3840×2160@50 | 4096×2160@60 | 7680×1080@60 | 7680×4320@60 | User Customized Resolution
Select from below or configure customized
HDMI 2.0
SMPTE
1080p@25/29.97/30/50/59.94/60 | 2160p@25/29.97/30/50/59.94/60
VESA
640×480@60 | 800×600@75 | 1280×768@50/60 | 1280×1024@60 | 1360×768@60 | 1600×1200@60 | 1920×1080@60 | 2048×1152@60
| 2560×812@60 | 2560×816@60 | 2560×1600@60 | 3840×1080@30/60 | 3840×2160@30/50/60 | 4096×2160@60 | 7680×1080@60 |
User Customized Resolution
DP1.2 SMPTE
VESA
[email protected]/24/25/29.97/30/50/59.94/60 | [email protected]/24/25/29.97/30/50/59.94/60 | [email protected]/24/25/50 1024×768@60/75/85 | 1280×768@50/60 | 1280×800@50/60 | 1280×1024@60 | 1360×768@60 | 1400×900@60 | 1400×1050@60 | 1600×1200@60 | 1680×1050@60 | 1920×1080@60 | 1920×1200@60 | 2048×1152@60 | 2560×812@60 | 2560×816@60 |
2560×1600@60 | 3840×1080@60 | 3840×2160@50 | 4096×2160@60 | 7680×1080@60 | User Customized Resolution
18Gbps 3840×2160@50 10bit HLG | 3840×2160@30 10bit HDR (for HDMI 2.0 output) RGB/YUV444 | YUV422 2.2 AC 100V-240V, 50/60Hz 1200W 050 10%~90% 37.9kg(Net) | 44kgPackage 522mm×484mm×355.6mm(Net) |610mm×720mm×700mm(Package)
Dimension
442
484
522
482
355.6
522
Order Codes
Product Code 310-0008-01-0 190-0008-01-0 190-0008-02-0 190-0008-03-0 190-0008-04-0 190-0008-21-0 190-0008-22-0
Item
X8
Quad HDMI 2.0 Input Module Quad DP 1.2 Input Module
Quad 12G SDI Input Module 8K Input Module Dual HDMI 2.0 Output Module Dual DP 1.2 Output Module
* Schedule leadtime : Jun. 1st 2022 Schedule leadtime : Jun. 15st 2022 Schedule leadtime : Jul. 1st 2022
Proudly designed and manufactured in Xiamen Hi Technology Zone, China WEB: www.rgblink.com EMAIL: [email protected] PHONE: +86 592 5771197
