106470 Water Pump
About Your Water Pump
The NorthStar water pump is an outdoor agricultural product used
for general purpose water pumping and field irrigation of clear
water only. It is recommended for pumping/spraying non-flammable
liquids such as water. The water pump has a solids capacity that
depends on the model. The technical specifications for the water
pump are provided in the Specifications section of the manual.
Summary of Important Safety Information
It is important to read and understand the Owner’s Manual
completely before using the water pump. Improper use of the water
pump could result in serious injury or illness to the operator or
nearby persons/animals, or could cause damage to the environment.
Follow all safety precautions presented throughout the manual.
Product Usage Instructions
1. Carefully read and understand the Owner’s Manual completely
before using the water pump.
2. Assemble, test, and use only in accordance with the Owner’s
Manual instructions.
3. Wear personal protective gear when filling, using, cleaning,
and servicing the water pump.
4. Do not start the water pump until ready to use in order to
avoid unintentional spray release.
5. This water pump is recommended for use in pumping/spraying
non-flammable liquids such as water. Solids capacity will depend on
model.
6. Keep this owner’s manual with the water pump at all times and
advise all persons who will operate the machine to read it.
7. If renting or loaning the water pump to others, provide
personal instruction on how to safely operate the water pump and be
available to answer any questions a renter/borrower might have.
8. Contact NorthStar Product Support at 1-800-270-0810 for any
questions about the appropriate use of this water pump and/or
optional accessories.
M106470I.1
ITEM NUMBER: 106470, 106471
SERIAL NUMBER: _______________
Owner’s Manual
Original Instructions for Assembly, Testing, Operation, Servicing, and Storage
Water Pump: Outdoor agricultural product used for general purpose water pumping and field irrigation.**
WARNING
READ and UNDERSTAND the Owner’s Manual completely before using this water pump. Assemble, test, and use only in accordance with the Owner’s Manual instructions.
WEAR personal protective gear when filling, using, cleaning, and servicing the water pump. DO NOT START water pump until ready to use in order to avoid unintentional spray release. Improper use of the water pump could result in serious injury or illness to the operator or nearby persons/animals, or could cause damage to the environment.
** This water pump is recommended for use in pumping/spraying non-flammable liquids such as water. Solids capacity will depend on model.
Any Questions, Comments, Problems, or Parts Orders Call NorthStar Product Support 1-800-270-0810
Hazard Signal Word Definitions
2
Table of Contents
About Your Water Pump ……………………………………………………………………………………………… 4 Summary of Important Safety Information ……………………………………………………………………..5
During Assembly During Operation During Storage / Troubleshooting Warning Label Locations………………………………………………………………………………………………..7 Unpacking ……………………………………………………………………………………………………………………………….. 8 Assembly ……………………………………………………………………………………………………………………………………………… 9 Machine Components…………………………………………………………………………………………………………….10 Operation Operation – Preparing the Water Pump for Each Use Step One: Inspect/Repair ………………………………………………………………………………………………… 11 Step Two: Fueling ……………………………………………………………………………………………………………………. 12 Step Three: Attach a suction strainer………………………………………………………………………………………… 13 Step Four: Place the water pump………………………………………………………………………………………………. 13 Operation – Using the Water Pump ………………………………………………………………………………………… 15 Storage …………………………………………………………………………………………………………………………16 Troubleshooting ……………………………………………………………………………………………………………17 Specifications ………………………………………………………………………………………………………………..18 Water Pump Exploded View………………………………………………………………………………………….19 782592 Pump Exploded View ………………………………………………………………………………………..20 782593 Pump Exploded View ………………………………………………………………………………………..21 Limited Warranty …………………………………………………………………………………………………………22 California Proposition 65 Information …………………………………………………………………………..24
3
About Your Water Pump
Thank you for purchasing your NorthStar water pump!
About Your Water Pump This water pump is a machine designed for outdoor, agricultural, general purpose water pumping and field irrigation applications of clear water only.
The technical specifications for your water pump are provided in the “Specifications” section of this manual.
Follow all safety precautions presented throughout this manual. A summary of important safety information can be found at the beginning of the manual.
Contact NorthStar Product Support at 1-800-270-0810 for any questions about the appropriate use of this water pump and/or optional accessories.
Warranty Registration:
Please fill in the warranty registration information and have it on hand when you call in on a warranty claim.
Attention: All Rental Companies and Private Owners who loan this equipment to others!
All persons to whom you rent/loan this water pump must have access to and read this manual. Keep this owner’s manual with the water pump at all times and advise all persons who will operate the machine to read it. You must also provide personal instruction on how to safely operate the water pump and be available to answer any questions a renter/borrower might have.
4
Summary of Important Safety Information
WARNING
Read and understand this owner’s manual completely before using the water pump.
Improper use of the water pump could result in serious injury or illness for the operator or nearby persons/animals, or cause damage to the environment.
LISTED BELOW is a summary of safety information of particular importance. See individual sections of this owner’s manual for more details.
————————————- BEFORE OPERATION——————————-
· Read manual. Do not allow anyone to operate the water pump who has not read the Owner’s Manual or has not been instructed on the safe use of the water pump.
· Review safety rules. Before starting this water pump, review the instructions for safe operation. · Know how to stop. Be thoroughly familiar with all controls and with the proper use of the equipment. Know
how to stop the water pump.
————————————– DURING ASSEMBLY —————————
· CHECK and TEST completed assembly as directed in this manual. Serious injury could result from water leaks if water pump is improperly assembled.
· DO NOT MODIFY water pump design.
—————————- DURING FUELING/REFUELING ———————
· Fuel outdoors. Fill fuel tank outdoors never indoors. Gasoline vapors can ignite if they collect inside an enclosure. Explosion can result.
· Use approved container. Never pump fuel directly into engine at gas station. Static charge can build and ignite fuel. Use an UL approved fuel container to transfer gas to the engine.
· Running / hot engine. A running engine is hot enough to ignite fuel. Never add fuel or remove gas cap if engine is running or still hot. Stop the engine and allow it to cool, at least two minutes before adding fuel.
· Heat / flames / sparks. Stay away from sources of heat, flame, or sparks while adding fuel.
· Don’t overfill. DO NOT overfill the gas tank. · Replace cap. Replace gas cap securely before starting engine. · Spills. Clean up fuel spills immediately. Move water pump away from spilled
fuel on the ground. Wipe fuel off engine and wait 5 minutes for excess fuel to evaporate before starting engine. Gas soaked rags should be disposed of properly. · On skin / clothes. If gasoline is spilled on your skin or clothes, change clothes and wash skin immediately. · Gasoline storage. Store gasoline in a cool, dry place in an UL approved, tightly sealed container.
————————————- DURING OPERATION ——————————
· INSPECT and PREPARE water pump before each use as directed in this manual. · DO NOT USE flammable or corrosive chemicals in the water pump. · DO NOT RUN water pump while unattended. · FOLLOW INSTRUCTIONS for SAFELY FUELING/REFUELING THE ENGINE. Gasoline is
flammable and can explode. Always use caution when handling gasoline. · DO NOT START water pump until ready to use in order to avoid unintentional release. · SEE Troubleshooting section of this manual before attempting any repairs. Wear personal protective
equipment and follow safety instructions. · Hot muffler. If you are starting a warm engine, stay clear of muffler. It may still be hot enough to burn you. · Unattended. Never leave the machine unattended while the engine is running.
5
Summary of Important Safety Information
· Under the influence. Never operate, or let anyone else operate, the water pump while under the influence of alcohol, drugs, or medication.
· Adjusting/Repairing. Turn off engine and remove spark plug cap before cleaning, inspecting, or servicing the water pump.
· Carbon monoxide. The running engine gives off carbon monoxide, a poisonous gas that can kill you. You CANNOT smell it, see it, or taste it. If you start to feel sick, dizzy, or weak while using the water pump, shut off the engine and get to fresh air RIGHT AWAY. See a doctor. You may have carbon monoxide poisoning.
· Other exhaust dangers. Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. Avoid inhalation of exhaust.
————————————- AFTER OPERATION ——————————
· Let engine cool before storing. Let engine cool for at least five minutes before storing. A hot engine can be a fire hazard.
· Storage location. Store the water pump in a location away from sources of heat, open flames, sparks or pilot lights such as water heaters, space heaters, furnaces, clothes dryers, or other gas appliances. Even if the water pump’s gas tank is empty, residual gasoline vapors could ignite.
· Gasoline storage. Store extra gasoline in a cool, dry place in an UL approved, tightly sealed container. Gasoline vapors can ignite if they collect inside an enclosure.
· Periodic maintenance. Perform periodic maintenance as directed in this manual to keep the water pump in safe working condition.
——————- DURING STORAGE / TROUBLESHOOTING ——————
· PREPARE THE WATER PUMP FOR STORAGE according to the instructions in this manual. · SELECT a well-ventilated STORAGE AREA away from sources of heat, flame, or sparks. Gasoline
vapors can ignite and cause a fire. · READ and FOLLOW the safety rules for troubleshooting / servicing the water pump.
6
Warning Label Location
106471 Only
Call North Star Product Support at 1-800-270-0810 to order new labels. Order Part No. 784261 Warning, priming plug 791213 – Warning decal 781120 – Pump decal 795272-Priming decal
7
Unpacking
Closely inspect all contents in the shipping carton. Note that some parts are shipped inside the manual bag.
· If you have missing or damaged components, please contact NorthStar Product Support at 1-800-270-0810.
The following items are found in the manual bag.
#82010 1/4″ x 1″ BOLT
(QTY 4)
#82222 1/4″ NYLOC NUT
(QTY 4)
#2215 RUBBER FEET
(QTY 4)
8
Assembly
Attach rubber feet to the base. 1. Using a 3/8″ and 7/16″ socket, attach the rubber feet to the base with the bolt and nut.
Base Base
Nut Rubber Foot
Bolt
9
Machine Components 7
7
1 7
2
6
FIG106470_3
3
4 5
7
1. Prime Port: Fill the priming port to prime the pump. 2. Discharge Fitting: Connect the discharge hose to the discharge fitting. 3. Suction Fitting: Connect the suction hose to the suction fitting. 4. Drain Port: Drain the liquid in the pump through the drain port. 5. Pump: The pump moves the liquid. 6. Engine: The air-cooled engine powers the pump. 7. Lifting Points: Lift the machine from these points when transporting.
10
Operation Preparing the Water Pump for Each Use
Step One: Inspect/Repair
If the water pump has been used previously, it must be prepared BEFORE EACH SUBSEQUENT USE.
WARNING
Read instructions below carefully for inspecting and preparing the water pump. Damaged or clogged equipment could result in leaks or uncontrolled spray.
Important safety rules: · Turn off engine. Turn off engine and remove spark plug cap before cleaning, inspecting, or servicing the water pump. · Keep a fire extinguisher rated “ABC” nearby · Guards / shields. Make sure all guards and shields are replaced after servicing the water pump. · Replacement parts. If a part needs replacement, only use parts that meet the manufacturer’s specifications. Replacement parts that do not meet specifications may result in a safety hazard or poor operation of the water pump.
1. Ensure water pump casing is empty
Ensure the water pump has been thoroughly flushed with clean water and drained from prior use.
2. Clean suction strainer
Clean the suction strainer of any material residue. It is important to clean the suction strainer of debris before each use, to ensure it is not clogged.
3. Inspect & repair
Inspect and test the water pump thoroughly
a. Inspect fittings for cracks and leaks. Replace all damaged fittings with original NorthStar parts.
b. Check to be sure all nuts, bolts, and screws are tight.
c. Check oil level in engine. See engine owner’s manual.
d. Check for fuel leaks. Any fuel leak is a fire hazard. Fix any fuel leaks before starting engine.
11
Operation Preparing the Water Pump for Each Use
Step Two: Fueling
WARNING
Gasoline is highly flammable and explosive. You can be burned or seriously injured when handling fuel. Use extreme care when handling gasoline. 1. Engine off / cool The engine must be off and allowed to cool at least two minutes before adding
fuel. WARNING: A running engine is hot enough to ignite fuel. Never add fuel or remove gas cap if engine is running or still hot.
2. Outdoor location Fill fuel tank outdoors never indoors. WARNING: Gasoline vapors can ignite if they collect inside an enclosure. Explosion can result.
3. Check engine oil Check engine oil level as specified in the engine manual. level
4. Remove gas cap Remove gas cap. 5. Add gasoline Add gasoline through fill opening from a UL-approved container.
Important Safety Instructions: · Use approved container. NEVER pump fuel directly into engine at gas
station. Static charge can build and ignite fuel. Use a UL approved fuel container to transfer gas to the engine. · With the engine stopped and on a level surface, remove the fuel filler cap and check the fuel level. Refill the tank if the fuel level is low. · Don’t overfill. DO NOT overfill the gas tank. Wipe up spilled fuel before starting the engine. · Heat / flames / sparks. Stay away from sources of heat, flame, or sparks while adding fuel. 6. Spills / splashes Clean up fuel spills /splashes immediately. Move water pump away from spilled fuel on the ground. 1. Wipe fuel off engine and wait 5 minutes for excess fuel to evaporate before
starting engine. 2. Gas soaked rags are flammable and should be disposed of properly. 3. If gasoline is spilled on your skin or clothes, change clothes and wash skin
immediately. 7. Replace gas cap Replace gas cap securely before starting engine.
8. Gasoline storage Store gasoline in a cool, dry place in a UL approved, tightly sealed container.
12
Operation Preparing the Water Pump for Each Use
Step Three: Attach a suction strainer
WARNING
This pump is design to pump water only. Never use the water pump to pump flammable liquids.
1. Attach suction strainer
A suction strainer should be attached to the suction hose. A suction strainer has holes or slots small enough to prevent large debris from working through and damaging the pump.
2. Keep the strainer Keep the strainer clean.
clean
If possible, suspend the strainer to keep it from working into sediment.
-OR-
A) Prepare a bed of large stones on which the strainer will rest.
B) Tie the strainer inside a basket or pail.
Step Four: Place the water pump
1. Place the water Place the water pump on a level surface in a location as near to the liquid surface as
pump near liquid possible, this will ensure proper pump suction. Refer to Lifting Points on Machine
surface
Components diagram when placing or transporting unit.
All hoses must be kept as straight as possible, avoid sharp bends.
NOTE: 23ft (7m) is the maximum height of suction head.
13
Operation Preparing the Water Pump for Each Use
2. Environment conditions
Ambient Operating Temperature Range. +5 °F to +104 °F (-15 °C to +40 °C). If operating pump below +32 °F (0 °C) drain pump after use to prevent damage from freezing.
Humidity. 95% max. If possible, avoid any area with high humidity. Humidity promotes rust and corrosion.
Altitude. If operation of the engine is always at altitudes HIGHER than 6,000 feet (1828.8m) above sea level, have an authorized Honda Engine dealer perform carburetor modifications. At high altitude, the standard carburetor air/fuel mixture will be excessively rich. Performance will decrease while fuel consumption will increase.
NOTICE: Operation of the engine at an altitude LOWER than the carburetor is modified for may result in reduced performance, overheating, and serious engine damage caused by an excessively lean air/fuel mixture.
2. Use flexible hose Use at least 12″ (30.5 cm) of flexible hose to make plumbing connections to the pump body. Rigid piping may put stresses on the pump, causing damage.
3. Place unit on secure footing
Always be sure the unit is on a secure footing. Keep the immediate pump area free of all unauthorized personnel. If the water pump is sitting beside a pit, be sure it is well anchored so that it does not fall in.
4. Do not run the pump dry
Do not run the pump dry. Always fill the pump body with water before starting. It is not necessary to drain the pump body after each use, unless there is danger of freezing, settling of solids, or crystallization.
5. Fill the pump with water
Fill the pump with water utilizing the priming port on the top of the pump. (The pump self primes only when it is first filled with priming water.)
All hoses and pipe connections must be airtight.
14
Operation Using the Water Pump
Operate the water pump
Do not run the water pump unattended.
WARNING
1. Review safety information
Review the “Operation Important Safety Information” provided in this manual.
2. Priming
Using the priming port on the top of the pump, completely fill the pump chamber with water before starting the engine.
3. Engine operation precautions
4. Start engine
Heed the following safety rules with regard to running the water pump engine:
· Hot muffler. If you are starting a warm engine, stay clear of muffler. It may still be hot enough to burn you.
· Hot exhaust. Hot exhaust fumes from engine can cause fire. Position muffler at least 7′ (2.1 m) from combustible objects during operation.
· Fire extinguisher. Have a Class B fire extinguisher available as a precautionary measure when operating the water pump engine in dry areas.
· Carbon monoxide. The running engine gives off carbon monoxide, a poisonous gas that can kill you. You CANNOT smell it, see it, or taste it. ONLY run the water pump engine OUTDOORS and at least 20 feet (6.1m) from the home, away from windows, vents and air intakes, to allow proper ventilation. NEVER run the water pump engine inside homes, garages, sheds, or other semi-enclosed spaces. These spaces can trap poisonous gases, EVEN if you run a fan or open windows. If you start to feel sick, dizzy, or weak while using the water pump, shut off the engine and get to fresh air RIGHT AWAY. See a doctor. You may have carbon monoxide poisoning.
Consult the engine Owner’s Manual for starting the engine.
5. Throttle control When operating the water pump much higher than the water surface, you may need to speed up the engine, using the throttle. When the pump is near the water surface, a slower engine speed can be used. This will save engine fuel and life.
6. Secure flexible hose
Consult the engine Owner’s Manual for throttle location. Never allow a vehicle to run over the flexible hose. This sudden shut off pressure can cause “hydraulic shock”.
7. Keep pump from freezing
8. Flush the pump
If your flexible hose must be laid across a high traffic area, it is advised to protect the flexible hose with planking. Never allow water to freeze in the pump. Freezing water can be extremely dangerous to the pump, always drain the water from the pump if freezing temperatures are a factor. Flush the pump with clean water after each use is advised. Some liquids being pumped may leave a solid or sticky residue. This may shorten the life of your pump.
15
Storage
Prepare the water pump for end-of-season storage by running clean water through the system. This will flush out any contaminants and clean the water pump internals. After the water pump has been flushed with clean water, completely drain the water pump of all water to protect from freezing.
WARNING
Gasoline vapors can ignite and cause a fire. Select a well-ventilated storage area away from sources of heat, flame, or sparks.
CAUTION
The water pump will be damaged if it freezes. Protect the water pump from freezing during storage by following the instructions below.
Preparing for storage:
1. Flush the pump
Flush the pump with clean water after each use is advised. Some liquids being pumped may leave a solid or sticky residue. This may shorten the life of your pump.
2. Drain the water pump
3. Engine storage
Using the water pump drain plug, drain the water pump completely of water to prevent freezing.
Refer to the engine manual for proper engine storage instructions. – Always disable the engine for storage by unplugging the spark plug wire.
CAUTION: Gasoline will oxidize and deteriorate in storage. Old gasoline in the engine will cause hard starting and leave gum deposits that can clog the fuel system. Deterioration problems may occur within a few months, or even less if gasoline was not fresh when you filled the fuel tank.
Short-Term Storage: Consider adding a fuel stabilizer to extend fuel storage life.
Long Term Storage: (between infrequent uses and at end of season) Drain the fuel tank and carburetor as instructed in the engine owner’s manual.
Important Safety Instructions: · Always drain fuel from tank in outdoor, well-ventilated area. · Stay away from sources of heat, flame, or sparks while handling fuel. · Clean up fuel spills/splashes immediately.
4. Water pump storage location
Store the water pump in a location away from corrosive material, sources of heat, open flames, sparks or pilot lights.
WARNING: Never store water pump inside where there is a source of heat or an open flame, spark, or pilot light as on water heaters, space heaters, furnaces, clothes dryers, or other gas appliances EVEN IF the water pump’s gas tank is empty.
5. Gasoline storage
Store gasoline in a cool, dry place in a UL approved, tightly sealed container.
WARNING: Gasoline vapors can ignite if they collect inside an enclosure and an explosion can result.
16
Troubleshooting
WARNING
Before troubleshooting or attempting to service, read the following safety rules.
Before attempting to service the water pump:
1. Review troubleshooting table
2. Flush the pump 3. Drain the water
pump 4. Disconnect
power 5. Perform repairs
Review the Troubleshooting Table below for the type of problem you are experiencing. However, DO NOT attempt to repair until the steps listed below are followed. Pump clean water briefly through the pump to remove any debris/solids.. Drain the water pump completely of water using the water pump drain plug, to prevent freezing. Switch off the engine and unplug the spark plug wire.
Follow the directions provided in the troubleshooting table to repair the water pump.
PROBLEM Pump doesn’t revolve Pump fails to prime
Low capacity
CAUSE 1. Engine will not turn over 2. Rusting/Sticking of impeller 1. Priming chamber not full enough 2. Air leaks on suction line joints 3. Quick coupling gaskets worn 4. Loose or broken hose clamps 5. Priming chamber is over heated 6. Engine speed is too slow 7. Worn or broken volute or impeller 8. Worn or broken mechanical seal 1. Clogged suction hose 2. Dirty suction strainer 3. Flow restriction due to hose kinks 4. Suction lift too high 5. Engine speed too low 6. Worn or broken mechanical seal 7. Reduced engine performance 8. Clogged impeller 9. Worn impeller
SOLUTION See engine owner’s manual Disassemble and clean Add more water to priming chamber Check for loose screws or broken hoses Replace gaskets Tighten or replace hose clamps Pour cold water in chamber or let cool Increase engine speed Replace worn or broken component Replace mechanical seal Clear obstruction Clear suction strainer Straighten suction and discharge hoses Move pump closer to water surface Increase engine speed Replace mechanical seal See engine owner’s manual Remove clog Replace impeller
17
Engine Suction & Discharge Size Maximum Flow Maximum Suction Head Maximum Total Head Maximum Pressure Passable Solid Size Mechanical Seal Overall Dimensions (L x W x H) Dry Weight Noise Level (dB)
Specifications
106470 2″ High Pressure Honda GX160 2″ NPT 8,120 gal/hr (30738 L/hr) 23 ft (7 m) 214 ft (65.2 m) 94 psi (6.48 bar) Clear Water Only Silicon Carbide 20″ x 16″ x 16″ (50.8 x 40.6 x 40.6 cm) 60 lbs (27.2 kg) 100 dB
Engine Suction & Discharge Size Maximum Flow Maximum Suction Head Maximum Total Head Maximum Pressure Passable Solid Size Mechanical Seal Overall Dimensions (L x W x H) Dry Weight Noise Level (dB)
106471 3″ High Pressure Honda GX270 3″ NPT 10,550 gal/hr (39936 L/hr) 23 ft (7 m) 263 ft (80.2 m)
116 psi (8 bar) Clear Water Only Silicon Carbide 26″ x 18″ x 21″ (66.0 x 45.7 x 53.3 cm) 80 lbs (36.3 kg) 92 dB
The manufacturer reserves the right to make improvements in design and/or changes in specifications at any time without incurring any obligation to install them on units previously sold.
Any Questions, Comments, Problems or Parts Orders Call NorthStar Product Support 1-800-270-0810
18
106470/106471 Exploded View Rev. I.1
1
2 5
3
FIG106470_4
4
Item 1
2 3 4 5
Part # 60590 39115 782592 782593 804086 804035 2215
804206
804208
Description GX160 Honda Engine GX270 Honda Engine 2″ High Pressure Pump 3″ High Pressure Pump
Frame
Bumper (Rubber Foot) 2″ Branding Decal 3″ Branding Decal 19
Model
Qty.
106470 106471
1
106470 106471
1
106470 106471
1
ALL
4
106470 1
106471
782592 Pump Exploded View
Item 1 2 3 4 5 6 7 8 9 10 11 12 13
Description Pump Cover Sealing Washer & M8 x 35 Hex Bolt Kit Mechanical Seal Large O-ring Impeller Volute Small O-ring Pump Body M8 x 30 Hex Bolt M8 Hex Nut Plug O-ring & Drain/Prime Plug Kit
Part # Qty.
782970
1
782971
4
782972
1
782973
1
782974
1
782975
1
782976
1
782977
1
782978
6
782979
6
782980
2
Item 14 15 16 17 18 19 20 21 22 23 24
Description Inlet Check Valve Inlet Flange Outlet Seal Outlet Flange M8 x 25 Hex Bolt M8 x 20 Hex Bolt Strainer Key Spacer Shaft Bolt O-ring
Part # Qty.
782981
1
782982
1
782983
1
782984
1
782985
4
782986
6
782987
1
783018
1
783019
1
783020
1
783021
1
20
782593 Pump Exploded View
Item 1 2 3 4 5 6 7 8 9 10
11
Description Pump Cover Nylon Washer M8 x 50 Hex Bolt Mechanical Seal Impeller Large O-ring Volute Small O-ring Pump Body N/A M8 x 25 Hex Bolt (set of 5)
Part # Qty.
782988
1
782989
4
782990
4
782991
1
782992
1
782993
1
782994
1
782995
1
782996
1
N/A
N/A
798516
1
Item 12 13 14 15 16 17 18 19 20 21
22
23
Description 31.5 x 3.55 O-ring & Plug Kit Inlet Check Valve Inlet Flange Outlet Seal Outlet Flange M8 x 70 Hex Bolt Suction Strainer Shaft Bolt Washer
Key
M8 x 30 Hex Bolt (set of 8)
Part # Qty.
782999
2
783000
1
783001
1
783002
1
783003
1
783004
4
783005
1
783022
1
783023
1
783024
1
798515
1
+
21
Limited Warranty
Dear Valued Customer:
The NorthStar Product you just purchased is built with the finest material and craftsmanship. Use this product properly and enjoy the benefits from its high performance. By purchasing a NorthStar product, you show a desire for quality and durability. Like all mechanical equipment this unit requires a due amount of care. Treat this unit like the high quality piece of machinery it is. Neglect and improper handling may impair its performance. Please thoroughly read the instructions and understand the operation before using your product. Always contact NorthStar Product Support at 1-800-270-0810 prior to having any service or warranty work performed, as some services performed by parties other than NorthStar approved service centers may void this warranty. This warranty is in lieu of any other warranty expressed or implied and NorthStar assumes no other responsibility or liability outside that expressed within this warranty.
Limited Warranty
NorthStar shall warranty any piece of equipment manufactured, or parts of equipment manufactured, to be free from defects in material or workmanship for a period of:
NorthStar Warranty
Item #
Consumer Warranty Period
106470 106471
2 years from date of purchase by user
Commercial Warranty Period 2 years from date of purchase by user
Engine Warranty
Item #
Consumer Warranty Period
106470 106471
3 years from date of purchase by user
Commercial Warranty Period 3 years from date of purchase by user
“Consumer use” means personal residential household use by a consumer. “Commercial use” means all other uses, including use for commercial, income producing or rental purposes or when purchased by a business.
This warranty applies to the original purchaser of the equipment (verification of purchase, in the form of a receipt, is the responsibility of the buyer), is non-transferable, and covers parts and labor. Parts will be replaced or repaired at no charge, except when the equipment has failed due to lack of proper maintenance. If a part is no longer available, the part may be replaced with a similar part of equal function. Any misuse, abuse, alteration or improper installation or operations will void warranty. Determining whether a part is to be replaced or repaired is the sole decision of NorthStar. NorthStar will not provide for replacement of complete products due to defective parts. Any costs incurred due to replacement or repair of items outside of a NorthStar approved facility is the responsibility of the buyer and not covered under warranty. Transportation costs to and from service center is the responsibility of the customer.
In addition to the normal warranty, NorthStar shall warrant any normal wear item from defects in material or workmanship for a period of 90 days from the date of purchase by user. Normal wear items include, but are not limited to, valves, seals, hoses, springs, O-rings, and strainers.
This warranty specifically excludes the following; failure of parts due to damage caused by accident, fire, flood, windstorm, acts of God, applications not approved by NorthStar in writing, corrosion caused by chemicals, use of replacement parts which do not conform to manufacturer’s specifications, damage related to rodent and/or insect infestation and damage caused by vandalism. Additional exclusions: loss of running time, inconvenience, loss of income, or loss of use, including any implied warranty of merchantability of fitness for a specific use. Also, Outdoor Power Equipment needs periodic parts and service to perform well, and this warranty does not cover instances when normal use has exhausted the life of a component or the engine.
This warranty does not cover any personal injury or damage to surrounding property caused by failure of any part. Repair or replacement of parts does not extend the warranty period.
The engine warranty is covered under the terms and conditions as outlined by the engine manufactures warranty contained herein and is the sole responsibility of the engine manufacture. Normal engine maintenance such as spark plugs, air filters, adjustments, fuel system cleaning and obstruction due to build up is not covered by this NorthStar warranty.
Please fill in the following information and have it on hand when you call in on a warranty claim.
Customer Number: ______________________________________________________________
Date of Purchase: _______________________________________________________________
NorthStar Serial Number: _________________________________________________________
Item Number: __________________________________________________________________
22
23
WARNING: This product can expose you to chemicals including
gasoline engine exhaust, which is known to the State of California to cause cancer, and carbon monoxide, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Manufactured by Northern Tool + Equipment Co., Inc.
Burnsville, MN 55306 NorthernTool.com
24
P65Warnings.ca.gov
